STOVE GUARD
SGEL-SN-1
MAI N MA NUA L
Installation and Operating Instructions
1
INSTALLATION P. 4-13
For indoor use only.
Do not use in a professional kitchen.
The Control Unit must be installed by an authorised electrician.
SGEL-SN-1-UserManual-A1
2
USER GUIDE P. 14-23
3
TECHNICAL SPECIFICATIONS
P. 24-28

Advertisement

Table of Contents
loading

Related Manuals for FireAngel Stove Guard SGEL-SN-1

Summary of Contents for FireAngel Stove Guard SGEL-SN-1

  • Page 1 STOVE GUARD SGEL-SN-1 MAI N MA NUA L Installation and Operating Instructions INSTALLATION P. 4-13 USER GUIDE P. 14-23 TECHNICAL SPECIFICATIONS P. 24-28 For indoor use only. Do not use in a professional kitchen. The Control Unit must be installed by an authorised electrician. SGEL-SN-1-UserManual-A1...

  • Page 2: Table Of Contents

    Disposal The operating instructions, accessories and stickers must accompany the product. Follow the safety guidance for Declaration of conformity safe use of Stove Guard. If you have questions about the product, ask a specialist or refer to FireAngel.co.uk Cooker connection...

  • Page 3: Installation

    INSTALLATION I N STA L L ATIO N O F TH E I NTE L L IG E NT HE AT SE NSO R The best place to install the Intelligent Heat Sensor is horizontally, on the cooker hood, directly above the centre of the cooker hob. The Sensor can also be mounted on a wall with an angle bracket or on the ceiling.
  • Page 4 COOKER HOOD HO RIZO NTA L I N STA L L ATI O N U N DE R C O O KE R H O O D Allow the Heat Sensor to reach room temperature before use. The power to the cooker must be switched off (at the consumer unit). See the table below for the mounting location and follow instructions 1-4.
  • Page 5 WALL WAL L MO U NTI NG WITH B R AC KE T Allow the Heat Sensor to reach room temperature before use. See the table below and follow instructions 1-5. Select the required mounting location and mount the Mount the Heat Sensor Starting the Sensor Set sensitivity level bracket...
  • Page 6 CEILING See the table below for the mounting location and follow instructions 1-5. Replace lens Select the mounting Mount the Heat Sensor Starting the Sensor Set sensitivity level location Carefully lift the lens with a Attach the mounting plate while Remove the red battery Set the Sensor's sensitivity level according to the mounting height (as screwdriver.

  • Page 7: Installation Of Control Unit

    CONTROL UNIT FUNCTION TEST IN STA L L ATI O N O F C O NTRO L U NIT The installation is completed when the test has been passed. The Sensor will then give an alarm. The operating instructions, accessories and stickers should be left with the product for future reference.
  • Page 8 surina. LIESIVAHTI SGK510 LIESIVAHTI SGK510 OPAS KÄYTTÄJÄLLE OPAS KÄYTTÄJÄLLE Vikamerkkiäänet Vikamerkkiäänet Matalat asennuskorkeudet Matalat asennuskorkeudet Merkkiääni Merkkiääni Tarkoittaa Tarkoittaa Toimi näin Toimi näin en aiheutti normaali ti normaali Ohjainyksikkö: Ohjainyksikkö: Automaattinen Automaattinen Käännä lieden säätimet ensin Käännä lieden säätimet ensin GETTING STARTED Älylämpöanturi alle 90 cm lieden yläpuolella Älylämpöanturi alle 90 cm lieden yläpuolella...

  • Page 9: Avoiding False Alarms

    READ BEFORE Action in the event of an alarm The cooker will automatically be ready for use after the Stove Guard has detected that the hazardous situation is over, and all the switches are set to “0”. U S I NG STOVE G UARD See the alarm overview below for actions.

  • Page 10: Other Settings

    OTHER SETTINGS Checking the Sensor’s Reset the sensitivity to sensitivity setting the factory setting 1. Remove the Sensor from the 1. Remove the Sensor from the mounting plate. (The Sensor mounting plate. (The Sensor gives 4 Change the Sensor’s sensitivity settings gives 4 “beeps”...

  • Page 11: Carbon Monoxide / Smoke Alarm Detection

    Carbon monoxide / smoke / heat alarm detection Optional features – sound detection problem situations The carbon monoxide / smoke / heat alarm must be placed within The Control Unit did not identify the alarm signal of the Carbon monoxide, heat or smoke alarm. 5 metres of the Control Unit.

  • Page 12: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS 1. I cannot turn on the cooker, and there is no Make sure that the Heat Sensor is The Heat Sensor takes different cooking situations The test is recommended when retrofitting the ANSWER 1: Note! signal from the Control Unit. firmly attached to the mounting plate and that it is into account, including high-temperature cooking, cooker and ceiling-mounted Sensor.

  • Page 13: Technical Specifications

    TECHNICAL SPECIFICATIONS O F THE STOVE GUARD Intelligent Heat Sensor Front of alarm unit should face towards user Solar cells Signal LED Temperature Sensor Cover The entire cover is a button that can be pressed in. The signal light turns green when pressed.

  • Page 14: Warranty

    Warranty EU Declaration of Conformity In addition to the statutory warranty from the retailer, this product has a As the product's manufacturer, we declare under our sole responsibility, 5-year manufacturer’s warranty covering defects in materials or execution. that this product corresponds to: The warranty applies from the date of purchase.

  • Page 15: Cooker Connection

    100 ms at 4 x load. Distributed by Sprue Safety Products Ltd Sprue Safety Products Ltd, Vanguard Centre, Coventry CV4 7EZ For more information on FireAngel Stove Guard contact Technical Support 0800 171 2009 or visit www.fireangel.co.uk.
