Page 1 AQUARAY ® Solid State Lighting Systems...
Page 2 INPUT-100-240VAC 50-60Hz 0.3A OUTPUT 1-19.5VDC 0.7A OUTPUT 2-19.5 VDC 0.7A Caution: Do not use any other power supply unit with an AquaRay lamp unit as the lamp unit may not work and this may cause irreparable damage to the lamp unit.
Page 3 1. Power supply unit (PSU) - with single or twin DC outlets. 2. Mains power supply cord with UK, European or USA plug configuration. 3. AquaBeam/GroBeam lamp unit - double or single lamp units with 3m (10ft) cable complete with matching plug connector to the DC outlet from the PSU.
Page 4 Caution: Do not attempt to control or regulate in any way the DC supply from the PSU to the AquaRay lamp unit. Any attempt to do so may invalidate the 5 year guarantee on your AquaRay lamp unit.
Page 5: Troubleshooting
Therefore it is recommended that:- a. The lens face of the AquaRay lamp unit is cleaned periodically with a warm, damp cloth. b. The heat sink on the rear of the unit is kept free of large particles of salt and other films or deposits which might obstruct the free movement of air around the vanes of the heat sink.
Page 6 ™ Tropical Marine Centre, Solesbridge Lane, Chorleywood, Herts WD3 5SX Technical Information Lines: Tel: +44 (0)1923 284151 Fax: +44 (0)1923 285840 Email: tmc@tropicalmarinecentre.co.uk www.tropicalmarinecentre.co.uk v.7/2010...
