24VDC
DIMMABLE
DRY LOCATION
SAFETY & WARNINGS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Install in accordance with national and local electrical code
regulations.
2. This product is intended to be installed and serviced by a
qualified, licensed electrician.
3. Do not modify or disassemble this product beyond instructions
or the warranty will be void.
4. Do not use if there is any damage to the fixture or wiring.
Inspect periodically.
5. Do not install near areas with exposure to salt water or
chlorinated water.
6. Do not install in direct sunlight or damage to the LED phosphor
will occur.
7. Do not attempt to fix this product in the field.
8. Failure to follow safety warnings, and installation instructions
will void the warranty for this product.
ETERNALUX
LED Light Bar INSTALLATION GUIDE
®
ETERNALUX

QUICK SPECS / MODELS

Input
Power
Ambient Temp* -4° - 122°F (-20° - 50°C)
Environment**
* Do not install product in environment outside listed
temperature.
**NOT FOR USE WITHIN POOLS, CHLORINATED WATER,
OR SALT WATER ENVIRONMENTS.
1 OF 6
LED LIGHT BAR
24VDC Constant Voltage
6.26W/ft.
Indoor/Damp Location
IG051418-1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUCHDIAL DI-RF-WMT-RGBW and is the answer not in the manual?

Questions and answers

Summary of Contents for DIODE LED TOUCHDIAL DI-RF-WMT-RGBW

  • Page 1 ETERNALUX LED LIGHT BAR ™ ® INSTALLATION GUIDE 24VDC DIMMABLE DRY LOCATION SAFETY & WARNINGS QUICK SPECS / MODELS READ AND FOLLOW ALL SAFETY INSTRUCTIONS Input 24VDC Constant Voltage Power 6.26W/ft. 1. Install in accordance with national and local electrical code regulations.
  • Page 2 ETERNALUX LED LIGHT BAR ™ INSTALLATION GUIDE INSTALLATION REQUIRED TOOLS TURN POWER OFF AT CIRCUIT BREAKER SHOCK HAZARD! May result in serious injury or death. Turn power OFF at circuit breaker prior to installation. 1. Phillips-head Screwdriver 2. Ruler (Recommended) 3.
  • Page 3 ETERNALUX LED LIGHT BAR ™ INSTALLATION GUIDE INSTALLATION (CONT.) MOUNT ETERNALUX LED LIGHT BAR ATTACH DRIVER AND LIGHTING ™ CONTROL. *Note: 3M VHB adhesive tape included with ETERNALUX LED Light ™ Bar is intended for indoor installation only. Refer to INSTALLATION Verify a compatible driver is installed.
  • Page 4 ETERNALUX LED LIGHT BAR ™ INSTALLATION GUIDE INSTALLATION OPTIONS INSTALLING NEAR WATER OR INDOOR INSTALLATION OUTDOORS Press 3M VHB adhesive tape to back of ETERNALUX LED Light Bar, then remove ™ Connect ETERNALUX LED Light Bar to power ™ protective covering. supply within wet location rated junction box.
  • Page 5 ETERNALUX LED LIGHT BAR ™ INSTALLATION GUIDE SYSTEM DIAGRAMS The following diagrams are provided as example system designs. For information regarding larger systems or systems not pictured below, please see our web page or contact technical support. Always review each component installation guide for detailed and up-to-date wiring instructions.
  • Page 6 ETERNALUX LED LIGHT BAR ™ INSTALLATION GUIDE VOLTAGE DROP CHARTS For best performance and lumen output, ensure proper wire gauge is installed to compensate for voltage drop of low voltage circuits. 24V Voltage Drop & Wire Length Distance Chart Wire 10 W 20 W 30 W...
