Summary of Contents for Aobost AO-L70AV Plus
-
Page 1: User Manual
AO-L70AV Plus Cell Phone Signal Booster User Manual 1 / 10 ... -
Page 2: Safety Warnings
Introduction With the popularity of mobile communications, people want to make a call anytime, anywhere, so the coverage requirement of communication network is higher and higher, but the reality is not so, sometimes mobile phone signal is not very good, you want to make a smooth call, even in some places cell phone cannot dial out. -
Page 3: Package Contents
PACKAGE CONTENTS 1. 1Pcs AO-L70AV Plus Booster with SMA Female connectors. 2. AC/DC Power Adaptor. 3. Screws Mounting Kits. 4. User manual (this document). -
Page 4: Installation Instructions
5.21db @698-894MHz cable with N male connector Notes：The above model antennas are suitable for AO-L70AV Plus booster . Warning： Unauthorized antennas， cables and/or coupling devices are prohibited by FCC rules. Please contact FCC for details：1-888-CALL-FCC The antenna, cables, and other accessories of the booster kits shall not be modified without the approval of the AOBAO company, otherwise it shall be deemed invalid. - Page 5 Testing the signal strength received from outdoor antenna mounted in site by mobile phone: Please select the top of building to install the outdoor antenna if total floors are less than 7 floors, and shall try your best to select places like balcony or platform lower than 7 floor for outdoor antenna if the buildings are over 7 floors, because the mobile signals are clean at less than 7...
- Page 6 As shown in the below illustration, the booster the downlink signal from the tower and send to the indoor antenna hereafter. If the distance between outdoor antenna and indoor antenna is less than the required distance, the amplified signal will go back from indoor antenna to outdoor antenna.
-
Page 7: Booster Installation
indoor antenna must be operated at a fixed location inside a building. Notes： （3）Booster Installation Do not place the equipment in direct sunlight or in an area that has abrupt temperature and humidity changes . it is suggested that the booster is installed in a cool，dry and ventilated room without erosive gas and smoke. - Page 8 It Usually means that the booster is self-oscillated, please make the Mobile phone distance between the indoor and outdoor antenna as far as possible, it is can receive full better to use a wall or metal to Separate the indoor antenna and the out signal, but can door antenna.
-
Page 9: Warranty
authorization for use of a particular booster model on behalf of all subscribers of individual providers. Alternatively, a provider may specify a testing protocol that if satisfied would result in licensee consent to specific booster models. A subscriber may also seek a licensee’s express consent to operate a signal booster, e.g., by phone call or e-mail The following selected information about wireless providers’... - Page 10 on your invoice or sales receipt is the date of installation unless AOBAO or your reseller informs you. This warranty does not cover the following: Failure resulting from misuse, accident, modification, unsuitable physical or operating environment, or improper maintenance by you; The warranty is voided by removal or alteration of identification labels on the Machine or its parts.
