Simplicity 1694296 Illustrated Parts List page 5

Body & Rotor Group
REF NO. PART NO.
1 1723219
2 1917356
3 1917372
4 1916965
5 176012
6 1723309
7 1921333
8 1924940
9 1713424
10 1931348
11 1923325
12 1921959
13 1923358
14 1717472
15 106653
16 1928721
17 1935048
18 172278
19 173934
20 172279
21 1676632
22 151040
23 1721842
24 1923362
25 106774
26 1925205
27 1919326
28 1921332
29 1716532
30 1716531
31 *
32 *
33 1716540
34 1717591
35 1916950
36 1717136
Footnotes:
Not a Service Part.
The above parts group applies to the following Mfg. Nos.:
1694296 Single Stage Snowthrower, 46"
TP 400-3541-00-AT-SMA
QTY.
1 BODY & FRAME ASSEMBLY, 46"
5 LOCKWASHER, 5/16
5 NUT, Hex, 5/16-18
4 LOCKWASHER, 3/8
1 PIN, Safety
1 PIN, Clevis
1 CAPSCREW, Hex Head, 5/16-18 x 1
4 WASHER, 5/16
2 SKID & WEAR ASSEMBLY
4 CARRIAGE BOLT, 3/8-16 x 3/4
6 CAPSCREW, Hex Head, 5/16-18 x 7/8
8 CAPSCREW, Hex Head, 1/4-20 x 5/8
8 NUT, Hex Centerlock, 1/4-20
1 BLADE, Scraper, 46"
1 SPROCKET
1 SCREW, Set, Square Head, Cup Point 5/16-18 x 1/2, G8
6 NUT, Hex Flange Lock, 5/16-18
2 FLANGE, Bearing
2 BEARING
2 FLANGE, Bearing
1 PLATE, Side
1 KEY
1 ROTOR ASSEMBLY, 46"
2 NUT, Hex Centerlock, 5/16-18
1 DEFLECTOR
4 CAPSCREW, Hex Head, 5/16-18 x 5/8
2 WASHER
2 CAPSCREW, Hex Head, 5/16-18 x 3/4
1 DECAL, Danger Auger
1 DECAL, Caution
1 DECAL, Model Number & Serial Number, Not Serviced
1 DECAL, OPEI, Not Serviced
1 DECAL, Caution, Rear Wheel Weights Required
1 GUIDE, Cable
4 NUT, Hex, 3/8-16
1 DECAL, Caution, Spring Tension
DESCRIPTION
5
