- Page 1 CI981 Integrated Washer Dryer 8 + 6kg 1400 spin Installation, use and maintenance www.cda.eu...
-
Page 2: Table Of Contents
Contents: Important information 5 - 6 Safety warnings Recommendations Before first use Detergents and additives Eco note and loading the appliance Control panel and programmes Programme table Programme details Starting a wash programme & features Choice of detergent Care and maintenance Cleaning the filter Detergent drawer 26 - 28... - Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
-
Page 4: Important Information
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. -
Page 5: Safety Warnings
Safety warnings • If the plug or cord is damaged, do not connect the appliance to the mains power supply. If the cord is damaged it should be replaced by the manufacturer or appointed service agent in order to avoid a hazard. - Page 6 Warnings To avoid the risk of fire, electric shocks, injury or damage when using your machine, please take the following precautions: • Please read all the instructions before using the machine. • Do not wash items that have previously been cleaned, washed, soaked or treated with petrol, solvents for dry cleaning, other inflammable substances or explosives, as they produce fumes that could catch fire or explode.
-
Page 7: Recommendations
Important: Ensure that the transit bolts have been removed prior to using the machine (see page 32). Recommendations • Residues of detergent or softener left in the detergent drawer for long periods will dry and stick to the detergent drawer. To prevent this put the detergent and softener into the detergent drawer just before washing. -
Page 8: Before First Use
Before first use When your machine has been correctly installed, we recommend that you pre-clean the machine. This is to check that the installation, the connections and the drainage are all correct, and to thoroughly clean the inside of the machine before any wash programmes are run. - Page 9 • Fasten all zips and buttons. • Turn garments, such as knitted fabrics, inside out. • Before placing the clothes in the drum, make sure all the pockets are empty. Any small objects may block the drain pump. • We recommend loading the machine to its full capacity for best water and energy efficiency.
-
Page 10: Detergents And Additives
Detergents and additives Your machine’s detergent dispenser has three sections as shown in figure 1. Add the required amount of detergent and fabric softener into the specific sections of the 1 - Pre wash detergent dispenser before 2 - Main wash starting the wash programme. - Page 11 • How heavily the clothes are soiled. • The hardness of the water (Information on water hardness in your area can be obtained from your local water board). We recommend the use of a decalcifying product if the water hardness is high in your area. Eco note The use of more detergent than necessary will not improve your washing results.
- Page 12 Control panel Fig. 2 Programme selector dial Display Delay timer button Temperature selection button Spin speed button Dry level button On/off button Start/pause button Programmes Fig. 3...
-
Page 13: Programme Details
Programme listing The table below shows the extra functions and temperatures available for each wash programme. Load(kg) Features Softener/ Default time Default speed Default temp Delay Prewash Conditioner (Hrs) (Rpm) (°C) Wash Dry Programme 1:07 Cotton eco 1:48 Cotton intensive 2:40 1400 Cotton... - Page 14 Cotton Standard cotton program with a long duration, adjustable temperatures and intensive cleaning. Quick This programme is suited for light loads with light soiling and which you would like to be cleaned quickly. Colours This programme is suited for coloured garments. The default temperature is cold.
- Page 15 Delicate This programme is suited for delicate garments. The intensity of the wash and drum rotation speed is gentler than other main cycles. Mixed This programme is suited for mixed fabric loads that require a more intense cleaning cycle. Ensure label warnings on garments are conformed to.
-
Page 16: Starting A Wash Programme & Features
Customisable dry cycle. Load weight and moisture affects duration. See page 18 for more information on dry levels. This function is available with some wash cycles (see page 13). IMPORTANT: NEVER DRY CLOTHING OR FABRICS CONTAINING RESIDUES OF SETTING LOTIONS, HAIRSPRAYS, NAIL SOLVENTS OR SIMILAR SOLUTIONS. - Page 17 When a wash programme is in progress, the programme can be paused by pressing the ‘Start / pause’ button at any time (unless key lock is active - page 19). To resume the programme, press the ‘Start / pause’ button again. Programme selection To select a programme, turn the ‘Programme selector dial’...
- Page 18 Delay timer A delay of up to 24 hours can be added to the end time in half hour increments to allow the wash programme to finish at a convenient time. To set the delay timer: • Press the ‘Delay timer button’ (written ‘start delay’). •...
- Page 19 running, the indicator light stays on. If this is pressed again while the machine is running a programme the washer will pause and the indicator light will flash. Key lock The lock function ensures that the programme will not be affected if any buttons are pressed accidentally.
- Page 20 EN60456 testing details Energy label program settings: 1. “Cotton Eco + 60°C + Max speed” The eco 60° cotton programme and dry only standard drying programme are suitable to clean normally soiled cotton laundry and they are the most efficient programmes in terms of combined energy and water consumption.
-
Page 21: Choice Of Detergent
Choice of detergent Detergent / Additive Programme Universal Colour Delicate Special Softener Wool Synthetic Hygiene Cotton Delicate Symbol Detergent / Additive Temperature Range (°C) Liquid 0 - 60 Powder 40 - 90 Optional Not applicable Notes: The delayed start option is not recommended when using liquid detergent. -
Page 22: Care And Maintenance
Care and maintenance Before beginning any care or maintenance you should always disconnect the appliance from the electricity supply, and also turn off the water supply. If a programme has been run recently, wait for the water in the appliance to cool down to prevent risk of scalding. - Page 23 Fig. 6 Fig. 7 Pump filter The pump filter system helps to prevent the ingress of lint or foreign objects into the drain pump, reducing the risk of damage. The pump filter should be cleaned regularly, every two to three months at least. To avoid injury, do not carry out this operation when the wash water is at a temperature over 30ºC.
- Page 24 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12 Fig. 13...
-
Page 25: Detergent Drawer
Detergent drawer Detergents may cause residue build up in the detergent drawer and the drawer housing over time. The drawer should be cleaned regularly to remove these residues. We also recommend you leave the appliance door and dispenser drawer open for a while after each wash. Fig. - Page 26 Cleaning the machine exterior The exterior of the washing machine should be cleaned with warm soapy water or a gentle cleaning agent. Do not use abrasive cleaning products or solvents. It should then be dried thoroughly with a soft cloth. Please note - wipe any detergent spills immediately to minimise the risk of damage to the machine exterior.
-
Page 27: Practical (Cleaning) Information
Practical information Alcoholic beverages: The stain should first be washed with cold water, then wiped with glycerine and water and be rinsed with water mixed with vinegar. Shoe Polish: The stain should be slightly scratched without ruining the cloth, rubbed with detergent and rinsed. In case it is not eliminated, it should be rubbed with 1 part of pure alcohol (96 degrees) mixed in 2 parts of water and then washed with lukewarm water. - Page 28 table-spoons of ammonia in 4 litres of water) for 30 minutes. Cream, ice-cream and milk: Soak the item in cold water and rub the stained area with detergent. If the stain has still not disappeared, apply diluted lye on the fabric. (Do not use lye on coloured clothes.) Mould: Mould stains should be cleaned as soon as possible.
-
Page 29: Display And Failure Codes
Restart the appliance. Restart the appliance and try again. If this code still Other shows please contact CDA Customer Care to arrange a service visit. Contact details are on the rear cover of this manual. Should any of the above potential solutions not resolve the fault;... -
Page 30: Troubleshooting
• Unplug the machine. • Close the water tap. • Contact CDA Customer Care. Fault Probable cause Methods of elimination The machine will not It is unplugged. - Page 31 Machine is not drying Heater has failed or thermal over- Leave appliance, off, to cool for a while load has been activated. before trying again. If still not drying per- formance, contact CDA Customer Care.
-
Page 32: Installation (Including Transit Bolt Information)
Installation This install is to be carried out by a minimum of two competent personnel. Always wear adequate PPE (Personal Protective Equipment) such as gloves and safety boots and familiarise yourself with your environment’s hazards. Transit bolts, located at the rear of the appliance, must be removed prior to using the appliance to prevent damage. -
Page 33: Levelling
floor or a well-fitting riser, ensuring the machine is unable to fall when subjected to the typical vibrations generated by a machine. The machine must not be fitted near heat sources, nor near combustible materials such as coal or gas. Ensure that the power cord is not trapped in any way. -
Page 34: Connecting To The Mains Water Supply
Connecting to the mains water supply • Fit the seal included in the hose packing at the end of the water inlet hose on the tap side. • Connect the water inlet hose to a 3/4” BSP water tap. Then securely tighten the connecting nut by hand. -
Page 35: Electrical Information
The drain hose must be securely fastened to the outlet to prevent any risk of the drain hose becoming detached and causing flooding. Once the appliance is connected to the water supply and the drain connection, ensure that the water inlet and drain hoses are not folded, twisted, crushed or elongated by stretching when moving the appliance into position. - Page 36 How to connect an alternative plug If the fitted plug is not suitable for your socket outlet, then it should be cut off and disposed of safely to prevent the risk of electric shock. A suitable alternative plug of at least 13 Amp rating to BS 1363 should be used.
-
Page 37: Fitting The Appliance
Fitting the appliance 600mm 580mm 825mm 152.5mm 17.5mm Fig. 19 Fitting template Fig. 20 Position the fitting template on the door accordingly so that you can mark it based on the cupboard and machine height (see page 38). -
Page 38: Fitting The Furniture Door
Fitting the furniture (decor) door The machine is supplied with a fitting template that aligns with the top of the décor door and has arrows cut out of it that point toward the door top. NOTE: If this template is aligned with the top of the décor door, the resultant position will align the décor door top with the top of the machine fascia. - Page 39 Drill the hinge and catch holes as per the diagram on the bottom of page 38. The sides that these holes shall need to be drilled will depend upon the style of the decor door and the side that you wish for it to be hinged upon.
- Page 40 Fig. 22 Fig. 23 Fig. 24...
-
Page 41: Final Installation Checks
Final installation checks Run a quick test cycle to make sure the appliance fills, turns, drains etc. with no issues. If you encounter any issues, ensure that the install is as close to the below images as possible, depending on the install. Ensure that no hoses are kinked, water is on and sink spigots are cut, if applicable. -
Page 42: Technical Specifications
Technical specifications Maximum dry laundry capacity (kg) Recommended loading (kg) See ‘Programme List’ (page 13) Height (cm) 82.5 Width (cm) 59.5 Depth (cm) 56.5 International washing symbols Washing Do not wash in a Lukewarm iron Medium hot iron temperature washing machine Hot iron Do not iron Do not tumble... -
Page 43: Energy Efficiency Information
Noise level of washing 54dB (A) Noise level of spinning 78dB (A) Noise level of drying 62dB (A) E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice. - Page 44 For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.eu Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 F: 01949 862 003 E: customer.care@cda.eu www.cda.eu...
