EMH XC-RACK Instructions For Use Manual

Digital 4-quadrant-/combi meter

Advertisement

EMH metering
GmbH & Co. KG
Neu-Galliner Weg 1 • 19258 Gallin
GERMANY
Tel.
+49 38851 326-0
Fax
+49 38851 326-1129
E-Mail info@emh-metering.com
Web
www.emh-metering.com
Tel.
+49 38851 326-1930 (Technical Support)
E-Mail support@emh-metering.com
Digital 4-Quadrant-/Combi meter
Scope of delivery .................................................................................... 2
Important notes....................................................................................... 2
Target group........................................................................................ 2
Intended Use ...................................................................................... 2
Maintenance and warranty instructions .............................................. 2
Care and disposal instructions............................................................ 3
Basic safety notes............................................................................... 3
Technical data......................................................................................... 4
Housing, display and operating elements............................................... 5
Nameplate .......................................................................................... 6
Display ................................................................................................ 7
Installation and commissioning............................................................... 9
Mounting an connection ................................................................... 10
Installation check register C.86.0 (optional) ..................................... 14
Error register F.F ............................................................................... 15
Abbreviations ........................................................................................ 16
EU Declaration of Conformity ............................................................... 17
Edition: 27.06.2018 Technical specifications are subject to change!
XC-RACK-BIA-E-1.70

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XC-RACK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EMH XC-RACK

  • Page 1: Table Of Contents

    EMH metering GmbH & Co. KG Neu-Galliner Weg 1 • 19258 Gallin GERMANY Tel. +49 38851 326-0 +49 38851 326-1129 E-Mail info@emh-metering.com www.emh-metering.com Tel. +49 38851 326-1930 (Technical Support) E-Mail support@emh-metering.com XC-RACK Digital 4-Quadrant-/Combi meter Instructions for use Scope of delivery ..................2 Important notes..................
  • Page 2: Xc-Rack

    Scope of delivery Please check the content of the package, before starting with the instal- lation and commissioning. • 1 XC-RACK device • 1 Instructions for use If the content is incomplete or damaged, please contact your source of supply. Store, use and transport the meter such, that it is protected from moisture, dirt and damage.
  • Page 3: Care And Disposal Instructions

    extreme temperatures and weather conditions) and any inappropriate or improper use or handling. Only authorised personnel are allowed to break the sealing! Care and disposal instructions DANGER! Contact of parts under voltage is extremely dangerous! When cleaning the housing of the meter, the conductor to which the meter is connected must be de-energized.
  • Page 4: Technical Data

    • Choose the conductor cross section corresponding to the maximum current loading. • Provide flexible wires with ferrules. Technical data Voltage, current, frequency see nameplate Inputs S0-input maximum number: 1, max. 27 V DC, 27 mA (not potential-free) low voltage maximum number: 8, 18...40 V DC or system voltage maximum number 8, 58...240 V AC...
  • Page 5: Housing, Display And Operating Elements

    Housing, display and operating elements 203 mm Nameplate LC display Call-up sensor (optical) Test-LED (continuously lit-up = no energy consumption or incor- rect flow direction) Reset button (sealable) Call-up button Optical data interface (D0) with magnetic fixing for the optical communication head Sealable transformer plate...
  • Page 6: Nameplate

    Nameplate Registered quadrants Type designation Voltage, current, frequency Safety and instruction notes Conformity and approval mark Temperature class according to IEC 60721-3-3 Call-up sensor (optical) Test-LED Accuracy class 10 Type key Serial number 12 Model year 13 OBIS-index of the most important registers 14 Manufacturer address 15 Contact sequence number 16 Space for ownership inscription...
  • Page 7: Display

    (optical or electrical) or the display flashes when the parameterisation status is active. At a XC-Rack with LMN-interface the Display lights up in irregular intervals, because it communicated intern, to provide the...
  • Page 8 4. The phase display signalises connection of the individual phase voltages. With an incorrect rotating field all three symbols flash. 5. The unit is displayed corresponding to the measured energy type or the displayed measured value. 6. In the additional cursor field operation conditions of the meter are represented.
  • Page 9: Installation And Commissioning

    Installation and commissioning DANGER! Contact of parts under voltage is extremely dangerous! When installing or changing the meter, the conductor to which the meter is connected must be de-energized. • Remove the relevant back-up fuses, for two-sided supply on the mains side as well as on the generation side.
  • Page 10: Mounting An Connection

    Mounting an connection The meters are suitable for mounting in a 19″ racks. DANGER! Low voltage inputs are separated from hazardous live voltages only by basic insulation. Therefore the low voltage inputs should not be accessible under normal operational conditions. DANGER! Contact of parts under voltage is life endangering! S0-inputs are not potential-free.
  • Page 11 Transformer connected meter for connection at current and voltage transformers in three-wire systems (Aron circuit). The terminals of the meter are at the back. Following variants for con- necting the meter are available: a) Meter with Essailec-plug-in system Communica- Optical fibre interface tion interface...
  • Page 12 The configuration of the contacts is variable and can be set by the customer. For example: Contact Meaning Contact Meaning RS485 B+ A+ GND RS485 A- A+ Pulses RS485 GND R+ Pulses R+ GND A- Pulses MPA+ A- GND MPA- R- Pulses R- GND Contact...
  • Page 13 c) Meter with Phoenix screw-type terminals Ethernet interface Optical fibre interface LLS The configuration of the contacts is variable and can be set by the customer. For example: Contact Meaning Contact Meaning Current phase 1 In Current phase 1 Out Current phase 2 In Current phase 2 Out Current phase 3 In...
  • Page 14: Installation Check Register C.86.0 (Optional)

    Installation check register C.86.0 (optional) The installation check register C.86.0 registrates installation errors. Normally, it is shown in the scrolling list or can be called up via the call- up list. Not used Wrong phase sequence Phase failure Negative energy direction Current interruption Max.
  • Page 15: Error Register F.f

    Event Value Meaning Undervoltage Undervoltage L1 (U < 80 %) Undervoltage L2 Undervoltage L3 Overvoltage Overvoltage L1 (U > 115 %) Overvoltage L2 Overvoltage L3 Error register F.F The meter has 32 error flags which are represented by a 8 digit Hex- code.
  • Page 16: Abbreviations

    Abbreviations Deutsches Institut für Normung e.V. (German Institute for standards) European standards Ground International Electrotechnical Commission Ingress Protection L1, L2, L3 External conductor Liquid Crystal Light Emitting Diode OBIS Object-Identification-System Active power Positive active power (customer imports from utility) Negative active power (customer exports to utility) Printed Circuit Board Reactive power Positive reactive power...
  • Page 17: Eu Declaration Of Conformity

    EU Declaration of Conformity The current EU Declaration of Conformity can be found in the download area of www.emh-metering.com.
