KNOW YOUR SIMPLICITY SEWING MACHINE

FRONT VIEW

O
FACE COVER
1
Opens to provide access to the light bulb and the
presser foot pressure regulator.
O
REVERSE LEVER
2
Press this lever down and hold in place to sew in
reverse.
O
BOBBIN WINDING TENSION DISC
3
Used to wind a bobbin when threading the
machine.
O
THREAD TENSION DIAL
4
Controls the upper thread for proper stitch formation.
O
STITCH WIDTH DIAL
5
Sets the width of a stitch.
O
STITCH SELECTOR DIAL
6
Turn the dial in either direction to select a stitch.
O
STITCH SELECTOR WINDOW
7
The letter of the selected stitch appears in this
window.
O
BOBBIN WINDER SPINDLE
8
Winds thread on a bobbin for lower threading.
O
HAND WHEEL
9
Turn the hand wheel toward you to raise the
needle up and down.
O
STITCH LENGTH DIAL
10
Sets the length of the stitch.
O
FREE-ARM COVER
11
Provides a flat surface for most sewing. Remove
it to convert to free-arm sewing.
O
NEEDLE PLATE
12
Supports the fabric while sewing. Has seam guide
markings on right side.
O
FEED TEETH
13
The metal teeth under the needle plate that push
or feed the fabric through the machine.
O
PRESSER FOOT
14
Holds the fabric firmly against the feed teeth for
proper stitch formation.
O
PRESSER FOOT HOLDER
15
Holds the snap-on presser foot in sewing position.
The presser foot holder is removed when using
screw-on feet.
O
PRESSER FOOT THUMB SCREW
16
Secures the presser foot or presser foot holder to
the presser foot bar.
O
BUILT-IN NEEDLE THREADER
17
Threads the eye of the needle, front to back.
O
BUTTONHOLE LEVER
18
Pull this lever down when using the one-step
buttonhole foot.
O
NEEDLE CLAMP SCREW
19
Loosen to remove a needle; tighten to secure a
needle in position.

BACK VIEW

O
CARRY HANDLE
20
Simply lift to carry the Simplicity sewing
machine from one place to another.
O
PRESSER FOOT LEVER
21
Lift to raise the presser foot and release the thread
tension; lower to lower the presser foot and engage
the thread tension.
O
THREAD CUTTER ON NEEDLE BAR
22
Use to cut threads after completing a seam.
O
POWER CORD RECEPTACLE
23
Connect the three-prong power plug here.
O

MAIN SWITCH

24
Turns the main power and built-in sewing light
on or off.
O
STRETCH STITCH ADJUSTMENT SCREW
25
Adjust this screw if stretch stitches (color-coded
red) are not forming properly.
O
RETRACTABLE SPOOL PINS
26
Raise the spool pin to hold the spools of thread.
