KNOW YOUR SIMPLICITY SEWING MACHINE

FRONT VIEW

O
FACE COVER
1
Opens to provide access to the light bulb and the
presser foot pressure regulator.
O
BOBBIN WINDING TENSION DISC
2
Used when threading machine for bobbin winding.
O
THREAD TENSION DIAL
3
Controls the upper thread tension for proper stitch
formation.
O
REVERSE LEVER
4
Press this lever down and hold in place to sew in
reverse.
O
STITCH WIDTH SELECTOR DIAL
5
Sets the width of a stitch.
O
BOBBIN WINDER SPINDLE
6
Winds thread on a bobbin for lower threading.
O
HAND WHEEL
7
Turn the hand wheel toward you to raise the
needle up and down.
O
STITCH LENGTH DIAL
8
Sets the length of the stitch.
O
FREE-ARM COVER/ACCESSORY STORAGE
9
Provides a flat surface for most sewing. Remove
it to convert to free-arm sewing.
O
FEED TEETH (FEED DOGS)
10
The metal teeth under the needle plate that push
or feed the fabric through the machine.
O
PRESSER FOOT
11
Holds the fabric firmly against the feed teeth for
proper feeding.
O
PRESSER FOOT HOLDER
12
Holds the snap-on presser foot in sewing position.
The presser foot holder is removed when using
screw-on feet.
O
NEEDLE PLATE
13
Supports the fabric while sewing. Has seam guide
markings on right side.
O
PRESSER FOOT THUMB SCREW
14
Secures the presser foot or presser foot holder to
the presser foot bar.
O
NEEDLE CLAMP SCREW
15
Loosen to remove a needle; tighten to secure a
needle in position.

BACK VIEW

O
CARRY HANDLE
16
Simply lift to carry the Simplicity sewing
machine from one place to another.
O
PRESSER FOOT LEVER
17
Lift to raise the presser foot and release the thread
tension; lower to lower the presser foot and engage
the thread tension.
O
POWER CORD RECEPTACLE
18
Connect the three-prong power plug here.
O

MAIN SWITCH

19
Turns the main power and built-in sewing light
on or off.
O
RETRACTABLE SPOOL PINS
20
Raise the spool pins to hold the spools of thread.
5
