Important recommendations
Never interfere with the product when connected
to a power source;
Avoid direct contact with water;
Regularly check the state of the product;
Respect the current norms;
Wear protected glasses to avoid injury during the
drilling phase;
Chance the factory code;
General remarks
Radio
The materials and the technology used have made it
possible to create a system functioning on the 433,05 -
434,790 MHz frequency band, used by LPD equipments
and therefore subject to european radio and
electromagnetic compatibility regulations (CE).
Rolling Code
In order to guarantee your safety and the total
inviolability of the communication between transmitter
and receiver, the code sent out by the transmitter
changes every time the equipment is used and is
recognised by the receiver only, thanks to an
unfalsifiable code-setting calculation. The system thus
conceived avoids all risk of being recording or of the
code being copied (268 million combinations).
Composition of the receiver
See fig. 1 of the enclosed "Installation phases"
Item Description
1 Receiver
2 Antenna wire
3 Assembly screws
4 Plugs

Declaration of Conformity

Hereby, CDVI Wireless Spa, declares that the radio equipment
type EVR/R500 is in compliance with directive 2014/53/EU. The
full text of the EU declaration of conformity is available at the
following internet address: www.gfa-elektromaten.co.uk
Pag. 2
Q.ty
1
1
4
4
Characteristics
Receiver
Local oscillator freq.
Power supply
Modulation
Number of memorizable users 507
Number of relays
Type of output contact
Commutable power
Maximum relay voltage
Absorbtion
Housing protection
Operating temperature
Dimensions (Fig 1)
Weight
Transmitter
Frequency
Power supply
Modulation
Number of functions
Coding type
Number of combinations
E.r.p.
Absorbtion
Range in open space with
receiver with antenna
Operating temperature
Dimensions
Weight
Battery type
Compatibility
The receiver can operate correctly with the corresponding
transmitters according to following table:
Receiver Transmitter
EVR/R500 VR/TF2E
( AM/ASK) VR/TF4E
EVR/TMASTER 2 Channel MASTER
6,6128 MHz
12/24 Vac/dc
AM/ASK - FM/FSK
2
1 NO, 1 NO/NC
24 VA
60 V
95 mA (relay excited)
IP 40
from -10°C to +55°C
180x140x68mm
330gr
433,92 MHz
12 Vdc
AM/ASK
2 or 4
Rolling Code
100 - 200 µW
18 mA
100-200 meters
-10°C to +55°C
82x48x16 mm
32gr
Alkaline - 23A
2 Channel
4 Channel
