Action Sports Equipment Pty Ltd. S000462 Owner's Manual Assembly Instruction

Wooden 3 ride gymset
Hide thumbs

Advertisement

Quick Links

Download this manual
Action Sports Equipment Pty Ltd.
72 Silverwater Rd, Silverwater, NSW, Australia, 2128
Parts & Service Enquiries: 1800 465 070 (Australia); 09 488 4750 (New Zealand)
WOODEN 3 RIDE GYMSET
MODEL#S000462
OWNER`S MANUAL ASSEMBLY INSTRUCTION
THIS PRODUCT PICTURE IS FOR REFERENCE ONLY
!
WARNING
YOU MUST THOROUGHLY READ AND UNDERSTAND
INSTRUCTIONS IN THIS MANUAL BEFORE ASSEMBLING
AND USE THIS SWING SET
SAVE THIS MANUAL FOR FUTURE REFERENCE.
THE UNIT DESIGNED FOR A MAXIMUM OF FOUR (4) CHILDREN BETWEEN THE AGES OF
THREE (3) AND EIGHT (8) YEARS OF AGE
DO NOT ALLOW YOUNG CHILDREN TO USE UNLESS SUPERVISED BY AN ADULT.
ACTION SPORTS EQUIPMENT PTY LIMITED
Page:1

Advertisement

loading

Related Manuals for Action Sports Equipment Pty Ltd. S000462

Summary of Contents for Action Sports Equipment Pty Ltd. S000462

  • Page 1 Action Sports Equipment Pty Ltd. 72 Silverwater Rd, Silverwater, NSW, Australia, 2128 Parts & Service Enquiries: 1800 465 070 (Australia); 09 488 4750 (New Zealand) WOODEN 3 RIDE GYMSET MODEL#S000462 OWNER`S MANUAL ASSEMBLY INSTRUCTION THIS PRODUCT PICTURE IS FOR REFERENCE ONLY WARNING...
  • Page 2 Dear Customer, Thank you for purchasing this product, we hope that you will enjoy it and have fun with friends and family. Please note this is a natural product and as such should be checked for any rough surfaces before use, if required these should be lightly sanded in order to prevent injury.

  • Page 3: Your Child`s Safety Depends On You

    WARNING! Please read this instruction manual before you start to assemble or use this swing set. You must follow all of the safety instructions while using this equipment. Be absolutely sure that the surface on which this swing set is set up on is properly surfaced with fine sand, wood chips or double shredded bark mulch .Do not use this swing set on hard packed soil ,concrete or any other kind of hard surface.
  • Page 4 Failure to assemble and maintain this item as per these instructions may cause injury to the user. DO NOT orientates the swing directly towards the sun. Packaging materials are not toys. Please remove all packaging and packing tags / wires before giving this toy to your child.
  • Page 5 hardware store and installed under the bolt head. Be sure to reuse or replace your lock washers. If over-tightening has caused the bolts threads to protrude beyond the wood surface, replace the bolt with a shorter one that will not protrude. These bolts are standard items and can be purchased at your local hardware store.

  • Page 6: Before You Begin Assembly

    AT LEAST 2 ADULT ASSEMBLY！ ！ ！ WARNING BEFORE YOU BEGIN ASSEMBLY!!! Take a complete inventory of components using the parts list. Sort and lay out the wood pieces. Label each piece of wood for easy reference. For easy identification during the assembly process, write the board’s letter on masking tape and adhere to each piece of the wood.
  • Page 7 COMPLETE EXPLODED DIAGRAM ACTION SPORTS EQUIPMENT PTY LIMITED Page:7...

  • Page 8: Part List

    PART LIST ACTION SPORTS EQUIPMENT PTY LIMITED Page:8...

  • Page 9: Hardware List

    HARDWARE LIST 0.7cmX5.1cm 0.8cmX6.4cm 4 PCS 4 PCS 0.7cmX7.6cm 4 PCS 0.8cmX8.9cm 12 PCS 0.8cm X9.2cm 1cmX9.2cm 8 PCS 2 PCS 0.6cmX3.7cm 4 PCS 0.6cmX 5.7cm 0.8cmX2.2cm 2 PCS 0.6cm X5cm 2 PCS 0.8cmX17.8cm 2 PCS 4 PCS 0.6cmX8.9cm 2 PCS 2 PCS 0.9cm 1.3cm...
  • Page 10 G 3 2 P C S Y 2 P C S Z 4 2 P C S G 1 1 P C S H 4 P C S G 2 1 P C S G 5 2 P C S 4 P C S G 7 2 P C S F 2 P C S...
  • Page 11 STEP 1 1.1. ATTACH THE LEGS (D, D1) ON PILLAR (B), UISNG FLAT WASHERS (R2), SPRING WASHERS (S) SCREWS (O) AND NUTS (J). 1.2. ATTACH THE LEGS (D, D1) ON THE CROSS BAR (A), USING FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (N) AND NUTS (L). 1.3.
  • Page 12 STEP 2 2. ATTACH THE TRIANGLE METAL SHEET (H) ON THE PILLAR (B), USING FLAT WASHERS (R2), SPRING WASHERS(S), SCREWS (P) AND NUTS (J). ACTION SPORTS EQUIPMENT PTY LIMITED Page:12...
  • Page 13 STEP 3 3. ATTACH THE ANOTHER TRIANGLE METAL SHEET (H) ON THE ANOTHER PILLAR (B), USING FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (P) AND NUTS (J). ACTION SPORTS EQUIPMENT PTY LIMITED Page:13...
  • Page 14 STEP 4 4.1. ATTACH THE LEGS (D, D1) ON PILLAR (B), UISNG FLAT WASHERS (R2), SPRING WASHERS (S)， SCREWS (O) AND NUTS (J). 4.2. ATTACH. THE LEGS (D, D1) ON THE CROSS BAR (A), USING FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (N) AND NUTS (L). 4.3.
  • Page 15 STEP 5 5. ATTACH THE TRIANGLE METAL SHEET (H) ON THE PILLAR (B), USING FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (P) AND NUTS (J). ACTION SPORTS EQUIPMENT PTY LIMITED Page:15...
  • Page 16 STEP 6 6. ATTACH THE ANOTHER TRIANGLE METAL SHEET (H) ON THE ANOTHER PILLAR (B), USING FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (P) AND NUTS (J). ACTION SPORTS EQUIPMENT PTY LIMITED Page:16...
  • Page 17 STEP 7 7.1. ATTACH THE SWING BEAM (E) ON THE PILLAR (B), UISNG FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (M) AND NUTS (J). 7.2. ATTACH THE SWING BEAM (E) ON THE TRIANGEL METAL SHEET (H), USING FLAT WASHERS (R2), SPRIGN WASHERS (S), SCREWS (O) AND NUTS (J).
  • Page 18 STEP 8 8.1. ATTACH THE SWING BEAM (E) ON THE PILLAR (B), UISNG FLAT WASHERS (R2), SPRING WASHERS (S), SCREWS (M) AND NUTS (J). 8.2. ATTACH THE SWING BEAM (E) ON THE TRIANGLE METAL SHEET (H), USING FLAT WASHERS (R2), SPRIGN WASHERS (S), SCREWS (O) AND NUTS (J).
  • Page 19 STEP 9 9.1 INSERT SWING SEAT CHAIN ITON (F) ONTO THE “U” STYLE (I). 9.2 ATTACH “U” STYLE (I) ON SWING BEAM (E), USING NUTS (K), FLAT WASHERS (R2) AND NUTS (J). ACTION SPORTS EQUIPMENT PTY LIMITED Page:19...
  • Page 20 STEP 10 10. ATTACH THE METAL PANEL (G1) ON THE SWING BEAM (E), USING FLAT WASHERS (R3), SPRING WASHERS (S1), SCREWS (N1) AND NUTS (J1). ACTION SPORTS EQUIPMENT PTY LIMITED Page:20...
  • Page 21 STEP 11 11. ATTACH THE METAL PANEL (G2) ON THE METAL SHEET (G1) WITH METAL SHEET (Y), USING FLAT WASHERS (R), SPRING WASHERS (S), SCREWS (Z) AND NUTS (J). ACTION SPORTS EQUIPMENT PTY LIMITED Page:21...
  • Page 22 STEP 12 12.1. ATTACH TUBE (G6) ON TUBE (G4), USING NUTS (Z7), (R1) & (S) & （Z6）, AND SCREWS (Z0). 12.2. INSERT (G3) ONTO THE TOP OF TUBE (G4). ACTION SPORTS EQUIPMENT PTY LIMITED Page:22...
  • Page 23 STEP 13 13. INSERT (G3) ONTO THE TOP OF TUBE (G4), USING (Z4) ACTION SPORTS EQUIPMENT PTY LIMITED Page:23...
  • Page 24 STEP 14 14. ATTACH THE TUBE (G4) ON THE METAL SHEET (G2), USING SPRING WASHERS (S), SCREWS (Z5) AND NUTS (Z7). ACTION SPORTS EQUIPMENT PTY LIMITED Page:24...
  • Page 25 STEP 15 15. A TTAC H THE ROMAN SEAT (G5) ON THE TUBE (G6), USING SPRING WASHERS (S), SCREWS (Z8) AND NUTS (Z7). ACTION SPORTS EQUIPMENT PTY LIMITED Page:25...
  • Page 26 STEP 16 16. ATTACH THE FOOT REST (G7) ON THE TUBE (G4), USING SCREWS (Z9), FLAT WASHERS (S) AND NUTS (Z7). IP: AFTER FINISHING ALL STEPS ABOVE, GO OVER ALL THESE STEPS AND TIGHTEN ALL BOLTS. ACTION SPORTS EQUIPMENT PTY LIMITED Page:26...
  • Page 27 STEP 17 ANCHORING 17.1 FOR SAFETY REASONS, T HE SWING MUST BE LOCATED ON THE LEVEL GROUND BY STAKES. 17.2 USE ONE HAMMER TO INSTALL SAFETY STAKES (E1) IN THE LOCATIONS.POUND THE STAKES INTO THE GROUND UNTIL THE SCREW HOLES OF THE STAKES ALIGNED WITH THE HOLES IN THE BOTTOM ENDS OF LEGS (D &...
  • Page 28 WARRANTY INFORMATION ACTION BRANDON 3UNIT WOODEN SWING SET IMPORTANT Please read and retain this manual as it will assist with identification for parts and service. ------------------------------------------------------------------------------------------------------------ ACTION BRANDON 3UNIT WOODEN SWING SET Limited Warranty ACTION SPORTS warrants its ACTION BRANDON WOODEN SWING to be free from defects in material and workmanship under normal use and service conditions for a period of 1 Year from the date of purchase of this article.
