Assembly, Installation, Care, Maintenance and Use Instructions
Bonus pieces. These
can be substituted for
other pieces on the
swing section:
Please read and RETAIN this manual as it will assist with identification for parts and service.
Read this manual prior to assembling and using this Play Fort.
- This play fort is for family domestic use only.
- This play fort is designed for use by children 3-9 years of age weighing no more than 34kgs.
- This play fort has a maximum total user weight limit of 320 kgs.
- Children of all ages must be supervised by an adult at all times when using this play fort.
- Adult assembly of this play fort is required.
ACTION SPORTS EQUIPMENT PTY LIMITED
Action Fort Playset
Model: S000090
Manual depicts typical installation
IMPORTANT
This Product is for Domestic Use Only.
- Warning -
STANDARD UNIT SET UP
Page: 1
