Channel Vision Central C-0501 Installation Instructions

Network Hub Distribution Module
Termination blocks for the CAT-5 cables, Ethernet hubs/routers. Bring the internet
DSL/CATV modems to any room in the home, or create a home data network.
Installation Instructions:
Step 1: Install 8 Cat 5 cables to 8 wallplate locations.
Step 2: Use 110 tool (J-110) or (1017) to punch down 8 locations on C-0501
Module.
Step 3: Connect (C-0409-3') or (C-0408-01') interconnects from C-0501
Module to Hub, or Router to Hub, depending on system
requirements.
Installation Instructions:
Channel Vision Technology will repair or replace any defect in material or workmanship which occur during normal use of
this product with new or rebuilt parts, free of charge in the USA, for two years from the date of original purchase. This is a
no hassle warranty with no mail in warranty card needed. This warranty does not cover damages in shipment, failures
caused by other products not supplied by Channel Vision Technology, or failures due to accident, misuse, abuse, or
alteration of the equipment. This warranty is extended only to the original purchaser, and a purchase receipt, invoice, or
other proof of original purchase date will be required before warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-0288 toll free. A return Authorization number
must be obtained in advance and can be marked on the outside of the shipping carton.
This warranty gives you specific legal rights, and you may have other rights (which vary from state to state). If a problem with
this product develops during, or after, the warranty period, please contact Channel Vision, your dealer, or any factory-
authorized service center.
©
2002, CHANNEL VISION™
C-0501
Channel Vision

Limited Warranty
