USER GUIDE
RFID LOCKER LOCK
(model : ZP200WR)
Version 1.20
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZP200WR and is the answer not in the manual?

Questions and answers

Related Manuals for Passtech ZP200WR

Summary of Contents for Passtech ZP200WR

  • Page 1 USER GUIDE RFID LOCKER LOCK (model : ZP200WR) Version 1.20 - 1 -...

  • Page 2: Table Of Contents

    Table of Contents 1. Understanding ZP200WR RFID locker lock ......3 1.1 What is the RFID Locker lock? ................3 1.2 Card Type and Functions ..................3 2. Type of Lock Operation ............4 2.1 Free Selection (Day Use) ..................4 2.2 Fixed Mode (Pre-Assigned Mode) ................

  • Page 3: Understanding Zp200Wr Rfid Locker Lock

    1. Understanding ZP200WR RFID locker lock 1.1 What is the RFID Locker lock? ZP200WR RFID locker lock is the cabinet lock operated by 13,56 Mhz RF keys such as card, tag, key ring or wristband. It has the wireless online communication feature that provide the central controlling and remote monitoring ( See Esmart ultra user manual ) 1.2 Card Type and Functions...

  • Page 4: Type Of Lock Operation

    2. Type of Lock Operation ZP200WR lock is designed to work for the various operation requirements by simple set up process. Following operation modes can be programmed before or after lock installation. 2.1 Free Selection (Day Use) - User can select any empty locker.

  • Page 5: Basic Operation Of The Lock

    3. Basic operation of the Lock Once settings of ZP200WR locks are completed by Setup card, Key, Owner card, Master cards and Clear card are saved in the memory of each lock. Starting the Lock : Press the “Touch” Button, and put the RF card (key) on the front body.

  • Page 6: Replacing Old Master Cards With New Master Cards

    3.2.2 Replacing old Master cards with New Master cards There are two ways to delete the lost Master card and register new Master card in the lock. (1) Using Time/Master Change Card Read the master cards (all Master cards to be used in a lock) to register in each lock at Time/master change menu in LOS program (or LIS program).

  • Page 7: How Do I Add New Master Card

    Master card can open this specific group of locks only. Master card registration is made by Setup card when Locker is installed or Master Card Change card during locker operation (please refer to 3.2 for Master card change). How do I add new Master card? 3.2.5 The procedure to add new Master card is same as 3.2.1.

  • Page 8: Fixed Mode (Pre-Assigned Mode)

    ☞ In free selection mode, lock and card needs to read and write the each other’s information. So please do not sway the card until the latch is moved. 3.3.2 Fixed Mode (Pre-Assigned Mode) The initial status of the lock in Fixed Mode is closed status (bolt out) - Open and close the lock - Press “Touch”...

  • Page 9: Low Battery Warning And Battery Change

    3.4 Low Battery warning and battery change The RFID lock uses 4 pieces of 1.5V AA alkaline batteries (6V). When battery reaches to low voltage ; Beep sounds five times. Red LED lights Low battery is recorded in the memory of the User Card (Operator can know the low battery of the lock when the card is read at operator’s Program).

  • Page 10: Open In Emergency

    3.6 Open in Emergency In case User forget his(her) password, Operator can open the lock by Master Card. Once Master card is used to open the lock, the lock reverts to default position (i.e. lock will stay open for Free Selection, and default code of 1234 for Fixed Selection mode.).

  • Page 11: Annex A Beep & Led Table

    ANNEX A Beep & LED Table Beep Description 1 x short beep 1 x Green(2sec) 2 x short beep 1 x Red(2sec) Operation Error 3 x short beep 1 x Red & Green in Time over turn(2sec) Do-Re-Mi Melody 1 x Red & Green in Successful Set up / mode turn(2sec) change / Time setting...

  • Page 12: Annex B Troubleshooting

    Annex B Troubleshooting 1) Master card registration should be followed after deleting old Master card in the lock by Master card registration in the lock Owner card. was failed. 2) Put Master card on the lock before waiting time is out after Owner card. Cannot open the lock with Master Master card is not registered in the lock.
  • Page 13 Should you have any questions, please contact your local distributor or our technical support. Version 1.20 - 13 -...
