- Page 1 USER GUIDE RFID LOCKER LOCK (model : BLE100) - 1 - 2010-10-06 Version 1.2...
- Page 2 Table of Contents 1. BLE Module Spec ......................3 1.1 Overview ......................3 1.2 Composition ..................... 3 1.3 Specification ....................4 1.4 Communication Protocol And Packet .............. 4 - 2 - 2010-10-06 Version 1.2...
- Page 3 1. BLE Module Spec Overview This module performs the function of connecting the locks by Passtech with BLE 4.1 or its more recent versions. Composition - 3 - 2010-10-06 Version 1.2...
-
Page 4: Specification
Specification Operating Frequency : 2.4~2.4835Ghz -93dBm sensitivity in Bluetooth® low energy mode : BLE 4.1 250 kbps, 1 Mbps, 2 Mbps supported data rates TX Power -20 to +4 dBm in 4 dB steps RSSI (1 dB resolution) ARM® Cortex™-M0 32 bit processor 256 kB embedded flash program memory 16 kB RAM Serial Wire Debug (SWD) - Page 5 BLE Phone use 2) Packet Format DATA 0x02(1) DATALEN(1) CMD(1) DATA(LEN) 0x03(1) 0xHH(1) STX (1) : 0x02 LEN (1) : 0x00~0xFF CMD (1) : Command Code DATA (LEN) : Data ETX (1) : 0x03 BCC (1) : STX ~ ETX 까지 ^ (Exclusive OR) Value 3) IC Control Command ADVERTISING START CMD (1) : I...
- Page 6 BLE CHIP POWER ON/OFF CMD (1) : P DATA (2) TEXT CMD (1) STATE (1) STATE (1) - ON "1" OFF "2" BLE SETTING CMD CMD (1) : S DATA (3) TEXT CMD (1) 종류 (1) STATE (1) 종류 : A STATE (1) - T (stop) 4) Card Data Command CARD REGISTER REQUEST...
- Page 7 CARD REGISTER RESPONSE CMD (1) : r DATA (17) TEXT CMD (1) 폰 시리얼(16) CARD DATA REQUEST CMD (1) : O DATA (15) TEXT CMD (1) 0x20 (14) DATA (15) TEXT CMD (1) OK/NG (2) Locker ID (5) 0x20 (7) - 7 - 2010-10-06 Version 1.2...
- Page 8 Version 1.2...
- Page 9 Version 1.2...
