- Page 1 Inflatable Shelter TECHNICAL MANUAL HEAVY-DUTY INFLATABLE SHELTER SYSTEM SW-SII 2015...
- Page 2 ..................................................................
-
Page 3: Table Of Contents
TABLE OF CONTENT Section Page SECTION 1 - TENT COMPONENTS Tent diagram Features SECTION 2 - TENT ASSEMBLY Preparation of the ground and assembly of the levelling floor Tent assembly Inner insulating liner assembly and disassembly Sunshade assembly and disassembly ..................2-8 Dust mat assembly and disassembly ................... - Page 4 FIGURES Figure Page SW-SII tent diagram Checklist Inflation valve closing Simultaneous inflation kit diagram Connecting the tube to the inflator Pressing the tube into the inflation valve. Unblocking spacer rod (Purlin) clamp Spacer rod (Purlin) engagement by means of union joint Spacer rod (Purlin) installed Stake and guy line arrangement for SW-SII arches tent Insulation liner diagram...
-
Page 5: Section 1 - Tent Components
SECTION 1 TENT COMPONENTS TENT DIAGRAM etw tal Figure 1.1 – SW-SII 4 arches 2 doors tent diagram. -
Page 6: Features
FEATURES Dimensions of the assembled tent Width 18'5'' Length (3-arches tent) 16'11'' Length (4-arches tent) 24'9'' Length (5-arches tent) 32'8'' Height (roof) 9'2'' Height (gutter) 6'10'' Working pressure 4.35 psi Working temperature range -25°F +120°F Waterproofing rain - snow Wind resistance (on ground of average consistency) ≤... -
Page 7: Section 2 - Tent Assembly
SECTION 2 TENT ASSEMBLY PROCEDURE PREPARATION OF THE GROUND AND ASSEMBLY OF THE LEVELLING FLOOR A - Identify the area where to erect the tent so as to optimize positioning of the floor. Make sure that there are no depressions on the ground. A space of approximately 28' x 43' is required for erecting a “4 arch” tent, including extended entrance module, sunshade and guy lines. - Page 8 ILLUSTRATED PROCEDURE FOR SHELTER DEPLOYMENT...
-
Page 11: Simultaneous Inflation Kit Diagram
RAPID SHELTER INFLATION A - After unfolding the tent completely, fix the four corners to the ground by means of stakes. CAUTION! DRIVE THE STAKES INTO THE GROUND TO A DEPTH SO THAT THE GUY LINE HOOKS ARE FLUSH WITH THE GROUND. - Page 12 ILLUSTRATED PROCEDURE FOR SHELTER INFLATION...
-
Page 13: Spacer Rod (Purlin) Installed
Figure 2.5 - Unblocking spacer rod clamp. Figure 2.6 - Spacer rod engagement by means of union joint. Figure 2.7 - Spacer rod (PURLIN) installed. Part Component Q.ty x tent Cross-shaped stakes Guy lines L=16'4'' Base braids L=3'3'' Guy lines L=16'4'' (optional) Figure 2.8 - Stake and guy line arrangement for TAG NG 4 arches tent. -
Page 14: Inner Insulating Liner Assembly And Disassembly
INNER INSULATING LINER ASSEMBLY AND DISASSEMBLY Part Component Q.ty x tent Front insulation liner Central insulation liner Rear insulation liner Modules joint Figure 2.9 - Insulation liner diagram. NOTE: THE FOLLOWING INSTRUCTIONS ARE VALID IN CASE OF THE LINER IS NOT ALREADY PRE-INSTALLED ON THE TENT. IN THIS CASE ASSEMBLY THE INNER INSULATING LINER ONCE TENT IS INFLATED BUT BEFORE INSTALLING SPACER RODS (purlins). A - Install the front section by connecting the frogs of the liner to the studs of the arch structure (fig. 2.10 step 1); B - Install the internal section as described above, joint the front and central sections by means of the Velcro tape (fig. - Page 15 Figure 2.10 - Assembly sequence of inner insulating liner for TAG NG 4 arches tent.
-
Page 16: Sunshade Assembly And Disassembly
SUNSHADE ASSEMBLY AND DISASSEMBLY NOTE: ASSEMBLY THE SUNSHADE BEFORE INFLATING THE TENT. A - After fully unfolding the tent, arrange the pneumatic spacers in the specific engagements on the tent at the slope. The spacers are connected to the eyelets on the tent by means of wing bolts using the system show in figure 5.2. B - Inflate the pneumatic spacers to working pressure. -
Page 17: Installed Sunshade Diagram
at Figure 2.12 - Installed sunshade diagram. Figure 2.13 - Noose and knot on guy rod diagram. -
Page 18: Dust Mat Assembly And Disassembly
DUST MAT ASSEMBLY AND DISASSEMBLY Take the four larger rolls inside the tent and unroll them. Arrange them starting from the two middle ones using the center of the door as a reference. Arrange the other two external rolls under the base of the arches (refer to fig. 2.14). Figure 2.14 - Dust mat diagram. -
Page 19: Electric System Diagram
WARNING: CHECK THAT ALL ELEMENTS ARE CORRECTLY CONNECTED BEFORE CONNECTING TO THE POWER NETWORK. (EUROPEAN SYSTEM) Figure 2.15 - Electric system diagram. NOTE: REVERSE THE PROCEDURE TO DISASSEMBLE. CLEAN THE COMPONENTS BEFORE PUTTING THEM BACK IN THE PACKAGE. Figure 2.16 - Switch on ceiling light. -
Page 20: Air Ventilation Tube
AIR VENTILATION TUBE The tent is provided with an internal tube made of fireproof material arranged on the roof for uniformly distributing air from the A/C system. The tube consists of two parts: - a straight tubular pipe with a closed end provided with two side mesh bands from which air from the A/C system is issued. The width of the side bands increases towards the closed end;... -
Page 21: Entrance Module
ENTRANCE MODULE A - The first step in erecting the entrance module is to insert all the eyes on the water guard edge over the stays. B - Identify the stay at the apex of the module and fix it to the apex of the door edge by passing the fixing line through it. C - Next insert the stays for the module into respective eyes in the door edge and thread the line through until you reach the bases. -
Page 22: Connecting Corridor
CONNECTING CORRIDOR Tents can be connected both end-to-end and side-to-end. These connections are formed using special corridors. To assemble these corridors we recommend proceeding as follows: A - Pass all the eyes in the water guard edge over the stays. B - Identify the stay at the apex of the corridor and fix it to the apex of the door edge by passing the fixing line through it. C - Next insert the stays for the module into respective eyes in the door edge and thread the line through until you reach the bases. -
Page 23: Connecting Corridor Pole Assembly Diagram
End-to-end connection Front-to-end connection Side-to-side connection Figure 2.19 -Connecting corridor pole assembly diagram... -
Page 24: 2.10 Use Configurations Of The Windows
2.10 USE CONFIGURATIONS OF THE WINDOWS The tent is provided with six windows, three on each side. Each window consists of an opening with six holes protected by a fly screen, a clear panel and a curtain. The fly screen, the transparent panel and the curtain may be kept taut and fastened with Velcro strips and reinforced eyelets/loops on the edge of the window and alternatively may be rolled up (either separately or together) and held by means of button cords welded to the outside of the liner. -
Page 25: Section 3 - Disassembly And Folding Of The Tent
SECTION 3 DISASSEMBLY AND FOLDING OF THE TENT DEFLATING THE TENT The tent is obviously disassembled by reversing the assembly operation. A - Firstly disassemble the internal accessories (dust mat, electric system). The insulation liners and the air distribution system can remain fitted inside the tent. Then clean the bottom of the tent. B - Remove the sunshade as shown in paragraph 2.3 and put it back in its bag after folding it properly. -
Page 26: Folding The Tent
FOLDING THE TENT NOTE: TWO PEOPLE ARE REQUIRED FOR THIS OPERATION. O - After deflating the tubes, close the inflation valves and the protective flaps. The pressure relief valves must stay open. P - When deflating the arches, make sure that the arches at the end of the deflating procedure assume the longitudinal position shown in figure 3.3. -
Page 27: Second Fold (Overlapping)
Figure 3.5 - Second fold (overlapping). V - Fold in the direction of length rolling the tent up from the rear side to obtain a compact package sized 50''x28''x33'' (fig. 3.6). Figure 3.6 - Rolling. W - Spread the bag by the side of the tent and roll up the package previously compacted using a belt in the middle of the bag (fig. -
Page 28: Section 4 - Inspections And Overhauls
SECTION 4 INSPECTIONS AND OVERHAULS FOREWORD An inspection is an operation consisting in verifying the presence of all the accessories and the correct packaging in the corresponding bags. It also includes visually checking the integrity of the material. An overhaul is an operation consisting in verifying the actual functionality of the material and repairing any damage. The tent and the corresponding accessories must be inspect and/or overhauled by the scheduled terms shown below: - INSPECTION PRIOR TO DELIVERY To be performed on the premises of the... - Page 29 D - Test arch integrity as follows: - Take the arch to working pressure (4.35 psi). - Check and restore initial pressure if required after one hour. - After four hours, check that the pressure has not dropped to less than 4.06 psi. Otherwise, proceed as shown in step 4.2.
-
Page 30: Section 5 - Tent Repairs
SECTION 5 TENT REPAIRS The tent is provided with a plastic repair kit in turn contained in the inflation system bag. The contents of the repair kit are shown below: Component Quantity Scissors 2 pcs PVC fabric patches for cover liner (24''x20'') 1 pcs PVC fabric patches for pneumatic arches (4''x4'') 10 pcs PVC fabric patches for footprint (4''x4'') 10 pcs Pressure relief valve caps 2 pcs... -
Page 31: Repaired Pneumatic Arch Test
E - Prepare the EV/C2 two-component glue. Add catalyzer to the base component in a proportion of 5% by volume or 8% by weight. F - Having joined the two components, shake hard to mix them well. Use the glue by 2 hours. CAUTION! OBSERVE THE SAFETY RULES AND REGULATIONS IN FORCE FOR APPLYING GLUE, SPECIFICALLY READ THE GLUE INSTRUCTIONS CAREFULLY. -
Page 32: Inflation And Pressure Relief Valves
Part Component Pneumatic arch Pneumatic spacer Pressure relief valve Inflation valve 1+1 1+1 1+1 Arch-spacer connection valve Pole inserts Arch-arch connections Figure 5.3 - Arch types. INFLATION AND PRESSURE RELIEF VALVES INFLATION VALVE - DISASSEMBLY A - Partially loosen the valve body using the specific tool (with the tube inflated). B - Deflate the tube. C - Fully loosen and remove the valve body and recover the inner locking ring nut through the hole in the tube. INFLATION VALVE - ASSEMBLY D - Insert the ring nut in the hole and grip from the outside of the tube to hold it still. - Page 33 PRESSURE RELIEF VALVE - ASSEMBLY E - Insert the pressure relief valve body in the pressure relief valve hole. F - Position the new pressure relief valve in its seat, tighten with your hands and then with the tool. G - Refit the inflation valve in its seat. H - Now inflate the tube until it is not cylindrical (the internal pressure must be low).
-
Page 34: Section 6 - Safety Instructions
SECTION 6 SAFETY INSTRUCTIONS GENERAL INSTRUCTIONS Ventilate the environment inside the tent using the specific vents on the front panels, the windows and the doors when there are many people inside the tent or after performing activities which may have caused the development of harmful gas. CAUTION! NEVER USE WATER TO PUT OUT A FIRE NEAR ELECTRIC EQUIPMENT. -
Page 35: Section 7 - List Of Spare Parts
SECTION 7 LIST OF SPARE PARTS MANUFACTURER Please address requests for pneumatic tents and spare parts to the manufacturer: Western Shelter Systems 815 Conger St., Eugene OR 97402 www.westernshelter.com 800-971-7201 Specify the following information in your order: The identification (P/N) of the part you need with a short description. -
Page 36: Optional Accessories
PLASTIC WING BOLT PA-SIIWBOLT INFLATION VALVE (COMPLETE) PA-SIIINV-C DESCRIPTION PRESSURE RELIEF VALVE (COMPLETE) PA-SIIPRV-C SPANNER FOR INFLATION VALVE PA-SIIIVSPAN SPANNER FOR PRESSURE RELIEF VALVE PA-SIIPRVSPAN SCREEN FOR WINDOWS PA-SIIWSCREEN SCREEN FOR VENTILATION PA-SIIVSCREEN '' STAKES PA-SIISTAKE '3'' PA-SIIGROPE-W GUY ROPE WHITE L=3 '3'' PA-SIIGROPE-B BLACK ROPE L=3 HAMMER 4.6 lbs PA-SIIHAMMER MANUAL INFLATOR PA-SIIMANINF TENT REPAIR KIT PA-SIIRKIT OPTIONAL ACCESSORIES Inner insulating liner DESCRIPTION FRONT/REAR INSULATING LINER PA-SIIISLE CENTRAL INSULATING L INER PA-SIIISLC Sun Shades... - Page 37 5 ARCH HOSE KIT PA-HOSSII5 TUBES SET FOR PRESSURE MAINTENANCE PA-SIIPMT MASTER BLASTER INFLATOR SO-ELIN Entrance modules and joining corridors DESCRIPTION ENTRANCE MODULE (SPECIFY COLOR) SO-VESII UNIVERSAL CONNECTING CORRIDOR (SPECIFY COLOR) SO-VCSII...
