Molift QuickRaiser 205
General Safety Precautions
Only use accessories and slings that are adjusted
to fit the user, type of disability, size, weight and
type of transfer.
Working pause ratio/Duty Cycle.
Molift Quick Raiser 205 should not be run con-
stantly for more than 2 minutes (with maximum
load), and rest for minimum 18 minutes. Duty
Cycle 10%. (Intermittence according to standard
ISO-EN 10535)

Before use / Daily check

Inspection to be performed daily or before use:
Make sure lifter has no visible damage, defects
or deformations
Make sure lifting arm connection, leg sup-
port, battery box and all detachable parts are
properly connected and secured
Test emergency stop button
Check batterylevel and service indicator
Make sure sling strap does not have visible
damage or frays.
Make sure wheels are rolling freely and lifter is
easy to manouvre

Hand control

The hand control has 4 buttons for lifting and
lowering of lifting arm and leg spread mechanism
in and out.
The hand control has an indicator
light that will illuminate when battery level is
low and the lifter requires charging
Hand control 4 buttons: Art. no. 2910010
Hand control 2 buttons: Art. no. 2910011

How to use Molift Quick Raiser 205

Safe Working Load
The lifter is marked with Safe Working Load (SWL)
If maximum load (SWL) differs
between lifter suspension and
body support unit, then the lowest
maximum load shall always be used
Molift lifters shall only be used to
lift persons. Never use the lifter to
lift or move objects of any kind.
Test run lifters operation functions and make
sure lifter does not make any abnormal
sounds
If there are any faults or defects,
the lift needs to be taken out of
operation and marked "out of
order"
Lifting Arm - Up / Down
NB! The lifter is most unstable in top position.
Legs - In / Out
NB! Spreded legs gives increased stability and
better access to chair or toilet.
9
