THERA-TRAINER TIGO
(
THERA-VITAL / THERA-LIVE)
for control and display unit with 5.7'' and 10.4'' colour screen

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIGO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for THERA-Trainer TIGO

  • Page 1 THERA-TRAINER TIGO THERA-VITAL / THERA-LIVE) for control and display unit with 5.7'' and 10.4'' colour screen...
  • Page 2 THERA-TRAINER TIGO USER MANUAL 11 USING CONTROL AND DISPLAY UNITS 11.1 Control and display unit with 5.7'' colour screen (1) Button Number of revolutions (2) Button Direction of rotation (3) Button Easy entry (4) START button (5) STOP button (6) Switch button Leg/upper body exerciser...
  • Page 3 THERA-TRAINER TIGO USER MANUAL 11.2 Control and display unit with 10.4'' colour screen (1) Button Switch training program (2) Button Number of revolutions (3) Button Direction of rotation (4) Button Easy entry (5) START button (6) STOP button (7) Switch button Leg/upper body exerciser...
  • Page 4 Press START button: Easy entry function is finished.  Press button: THERA-Trainer tigo reverses direction of rotation. Button Direction THERA-Trainer tigo slows down to 0 and resumes movement in opposite of rotation direction with pre-set number of rotations.  Black arrow shows current direction of rotation.
  • Page 5 Press button + briefly: THERA-Trainer tigo increases number of revolutions of revolutions step by step.  Press button - briefly: THERA-Trainer tigo reduces number of revolutions step by step.  Press and hold button: Increase or reduce number of revolutions continuo- usly until maximum or minimum is reached.
  • Page 6 THERA-TRAINER TIGO USER MANUAL 11.3 Display units (1) Display Training program (2) Pulse indicator (3) Performance indicator (4) Distance covered (5) remaining training time (6) Status bar (7) Display Biofeedback The operation of control and display units with 5.7'' colour screen is identical to Note units with 10.4'' colour screen.
  • Page 7 THERA-TRAINER TIGO USER MANUAL Explanation of display units  Status bar Shows e.g. button lock, voice-controlled emergency stop, printer connection for training data, microphone sensitivity.  Hidden during training sessions.  Display Indicates active training program on home screen. Training program ...
