Items Needed
1. Rocket with New Retrofitted Lid
2. Direct Connect Cable
3. USB Extension Cord
4. Polycarbonate Lid Insert
5. US Cellular UM 185 modem
Installing the US Cellular Modem
• On the US Cellular UM 185 modem, slide the lid until
it clicks into an open position and unfold the
USB connector to a 180 degree angle.
• Plug the USB extension cord
into the modem, as shown below.
• Turn the modem face down, and place into the cutout on the
polycarbonate lid insert. Then velcro into place.
I N S T R U C T I O N G U I D E
Inserting the US Cellular
UM 185 USB modem in
1.
NOTE: Do NOT velcro the cords to the modem,
doing so may damage the cords and/or modem.
utility.com
the Rocket Lid
2.
3.
• Plug in the Direct Connect Cable into the back of the
modem, draping the cord toward the USB connector,
as shown below.
4.
5.
Advertisement
Related Manuals for UTILITY Rocket
Summary of Contents for UTILITY Rocket
- Page 1 I N S T R U C T I O N G U I D E Inserting the US Cellular UM 185 USB modem in the Rocket Lid Items Needed 1. Rocket with New Retrofitted Lid 2. Direct Connect Cable 3. USB Extension Cord 4. Polycarbonate Lid Insert 5. US Cellular UM 185 modem Installing the US Cellular Modem • Plug in the Direct Connect Cable into the back of the...
- Page 2 • Close the Hinged Lid Support with both cables extending through the center. Continued • Open the Rocket Lid and slide out the Hinged Lid Support. • Plug the direct connect cable into the Rocket and hand tighten, as shown below.
