- Page 1 Universal Table/Desk for All Sizes of Panel Wall Beds Assembly Instructions ** 5 YEAR WARRANTY ** Designed to Exceed International ISO 9002 Standards for Residential Specifications - Patent Pending -...
-
Page 2: Exploded Assembly
Exploded Assembly Hinges and Hinge Clips to Riser and Bed Face Panel (3pc) 2”x3”Black Hinge (3pc) Hinge Clips (27pcs) Flat Head Self tapping Screw#5x16mm (10pc) #8x1.5” (40mm) Wood Screws (30pcs) 19mm Self tapping Screw Pivot Brackets to Cabinet Panels & Riser and Desk/Table to Upper Brackets... - Page 3 Pre Assembled KIT (2pc) M8x16mm Bolt Upper Bracket (2pc) Black Steel Washer Ø8.5xØ20mm (Left and Right) Legs to Upper Brackets Washers stop friction between Legs, Upper and Lower Brackets (4pc) Black Nylon Washer Ø13xØ30mm Leg (2) Pivot Bracket (Left and Right) Legs to Pivot Brackets (2pc) M6x40mm Bolt (4pcs) Black Steel Washer Ø7.0xØ16.0mm...
-
Page 4: Project Start-Up
Edge-band the two long edges of both the Desk and Riser. NOTE: If the Panel Bed is slightly too heavy too open and close without the Studio Desk/Table mounted, you should add one Spring to the right and to the left to assist in balance. An odd number of Springs right and left may be used to get balance STEP 2: Assemble Desk/Table with Upper Brackets. - Page 5 Drawing #1: Upper Bracket Riser Desk/Table Top Drawing #2: Hinges to Riser The short Hinge leaf attaches to the Riser, the long Hinge leaf attaches to the Bed Face Riser Riser...
- Page 6 STEP 3: Install Pivot Brackets Install the left and right Pivot Brackets as shown in Drawing #3. Mount the Brackets exactly 1.0” (25mm) inside of the Cabinet vertical. The pivot point (standoff) must face outward to allow the Leg to line up with the vertical edge of the Panel. Drawing #3: Pivot Brackets Cabinet Cabinet...
- Page 7 Clips. See Drawing #5. Bring the Studio Desk/Table back up to the Bed Face and seat the long Hinge leaves in the Hinge Clips. Screw the long leaves of the Hinges to the Bed Face. Recheck levelness in all directions.
