RIDE-ON ELECTRIC ATV TOY
Model 03516
ASSEMBLY AND OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
Copyright
by Harbor Freight Tools
®
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for Harbor Freight Tools 03516
Summary of Contents for Harbor Freight Tools 03516
- Page 1 Harbor Freight Tools ® . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions, please call 1-800-444-3353.
-
Page 2: Product Specifications
Check for damaged parts and any other conditions that may affect the operation of this product. Replace or repair damaged or worn parts immediately. SKU 03516 PAGE 2... -
Page 3: Specific Product Warnings And Precautions
NEVER STAND ON THIS PRODUCT. Serious injury could result if the ATV is tipped. ALWAYS KEEP HANDS, FINGERS, AND FEET, AWAY FROM THE MOVING PARTS OF THIS PRODUCT. SKU 03516 PAGE 3... - Page 4 PROPER BATTERY CARE: Battery leakage may occur under extreme usage or temperature conditions. Never allow children to handle the two 6 Volt DC Batteries for this product. If Battery fluid comes in contact with skin, wash with SKU 03516 PAGE 4...
- Page 5 JUSTMENTS, MAINTENANCE, OR CLEANING PROCEDURES. THIS PRODUCT IS EQUIPPED WITH AN AUTOMATIC SHUTDOWN DEVICE. During overload or improper operation, the ATV will automatically shutdown for approximately 15 to 20 minutes. After this period, the ATV may be started again. SKU 03516 PAGE 5...
-
Page 6: Product Features
When unpacking, check to make sure all the parts shown on the Parts List (page 12) are included. If any parts are missing or broken, please call Harbor Freight Tools at the num- ber shown on the cover of this manual as soon as possible. - Page 7 Insert the Front Steering Linkage (part #2) upward through the Front Chassis (part #4) and Front Bumper (part #5). (See Figure D.) Insert a Vibration Muffler (part #6) on each side of the Front Steering Linkage (part #2). (See Figure D.) SKU 03516 PAGE 7...
- Page 8 Insert the Back Rest (part #20) into the two mounting holes located at the rear of the ATV. Then secure the Back Rest to the ATV, using four Screws (part #21). (See Figure E, next page.) SKU 03516 PAGE 8...
- Page 9 Disconnect the Battery Electric Supply Line (part #12) from the Wiring Harness (part #13). (See Figure F, next page.) Plug the 12 Volt DC Adapter Transformer Output Line (part #14) into the Battery Electric Supply Line (part #12). (See Figure F) SKU 03516 PAGE 9...
-
Page 10: Operating Instructions
Insert the Ignition Key (part #22) into the Ignition Switch, and turn the Ignition Key counterclockwise to turn on the ATV. (See Figure C.) Then, step on the Throttle Pedal (part #19) to move the ATV at the pre-selected speed and in the pre-selected direction. SKU 03516 PAGE 10... -
Page 11: Inspection, Maintenance, And Cleaning
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 03516 PAGE 11... -
Page 12: Parts List
Cotter Pin W rench (not shown) Battery Fuse (not shown) Battery Electric Supply Line W iring Harness Some parts are listed and shown for illustration purposes only, and are not avail- able individually as replacement parts. SKU 03516 PAGE 12...
