- Page 1 TESS™ 308 Installation Manual Please read these instructions in full prior to starting your installation Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 1...
-
Page 2: Table Of Contents
4. System Preparation - Fabric fitting if not pre fitted ................6 5. Installation............................7 6. Hirschmann Fitting ..........................12 7. Manual Motor Limits Setting ......................13 8. Radio Motor Limits Setting ....................... 14 9. Maintenance ............................. 16 Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 2... -
Page 3: Important Information About Tess Systems
1. Important information about TESS Systems Guthrie Douglas TESS Systems are technical products that require installation, servicing and maintenance by professionals with the appropriate skills. If in doubt, please contact us for further advice and training. All products are designed, tested, and manufactured in line with relevant EU regulations. General certificates of conformity and declarations of performance are available on our website www.guthriedouglas.com... -
Page 4: Tess 308 System
8. Hem Bar Assembly Fitting Kit to include : 2mm Diameter Aluminium Ferrule Installation Manual Motor Limit Setting Key See page 5 Fixings Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 4... -
Page 5: Fitting Kit
M6 x 10 BOLT PLATE M6 x 8 PAN MOUNTING HEAD BRACKET M6 SHAKE MOUNTING PROOF PLATE MOUNTING M6 WASHER PLATE M6 PLASTIC MOUNTING TOP HAT BRACKET WASHER Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 5... -
Page 6: System Preparation - Fabric Fitting If Not Pre Fitted
4. System Preparation – Fabric fitting if not pre-fitted The fabric to be fitted is to have been manufactured in line with Guthrie Douglas specifications. The fabric must have pockets as shown at each end. Fabric drawing is available on request. -
Page 7: Installation
Install the barrel assembly. Ensure the barrel assembly is level, adjust if necessary by slackening the fixing screw (6) adjusting the tracking plates (7). Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 7... - Page 8 5. Installation Fit the cable retention bracket (1) using the fixings (2) and (5) supplied in the fitting kit in section 3 (page 5). Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 8...
- Page 9 Guide wires are required to be fitted on both end plate assemblies. Insert the guide wire into the cable retention bracket. Ascertain the approximate length required and cut the wire taking care not to cut too short. Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 9...
- Page 10 13mm spanner to tighten the nut (item 4). Once the guide wire is tight, tighten the lock nut (5) to secure. Cut off any excess guide wire. Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 10...
- Page 11 5. Installation Check System Width Check System Draw Check across diagonals to ensure system squareness is correct. Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 11...
-
Page 12: Hirschmann Fitting
6. Hirschmann Fitting Hirschmann Plug The diagram above shows the Hirschmann plug wiring as per Guthrie Douglas (GDE50360). Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 12... -
Page 13: Manual Motor Limits Setting
NOTE: the motors have a built in thermal cut off. If after several minutes of use the motor will not run in either direction, allow the motor to cool down for approximately 20 minutes Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 13... -
Page 14: Radio Motor Limits Setting
1. To operate the motor in stable mode press the programming button for approximately 1 second, the motor will again acknowledge . This is now the master transmitter and can be used to programme additional transmitters. Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 14... - Page 15 2. Complete the operation by pressing the programming key. This will take the motor out of programming and it can then have the programming cancelled to restore it to “factory default” the programming process can then be repeated. Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 15...
-
Page 16: Maintenance
Clean and remove any debris from the system Every 10 Years (additional checks) Check motor operation Depending motor usage and working conditions and consider replacement Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 16... - Page 17 Guthrie Douglas Group Limited 12 Heathcote Way, Heathcote Industrial Estate, Warwick, UK, CV34 6TE E-mail: solar@guthriedouglas.com, Web site: www.gdsolarcontrol.com Tel: +44 (0)1926 310 850, Fax: +44 (0)1926 832 914 Tess 308 Installation Manual – Issue 1 (DR1004, July 2014) Page | 17...
