    OmniView ® Remote IP Device �� � User Manual F1DP101M...

  • Page 2: Table Of Contents

    1. Introduction ... 1 Package Contents ... 1 2. Overview ... 2 Features ... 2 Equipment Requirements ... 4 System Requirements ... 5 Unit Display Diagrams ... 7 Specifications ... 8 3. Hardware Installation ... 9 Pre-Configuration ... 9 Mounting the IP Device (optional) ...10 Connecting the Console to the IP Device ...11 Connecting the KVM Switch or Server to the IP Device Powering Up the Systems ...14...
  • Page 3 Using the Remote IP Device ... 30 Starting a Remote Session Using the Quick-Access Toolbar Mouse Configuration and Settings Keyboard Configuration and Settings Video Configuration and Settings Performance Settings (Bandwidth) Selecting a Server Additional Features Restoring Factory Defaults Frequently Asked Questions ... 45 Troubleshooting ...47 Glossary ...

  • Page 4: Introduction

    For quick and easy installation, please refer to the Quick Installation Guide included in your packaging. We appreciate your business and are confident that you will soon see for yourself why over 1 million Belkin OmniView products are in use worldwide. Package Contents OmniView SMB...

  • Page 5: Overview

    Overview Features • High-Performance Remote Access The IP Device allows you to access and control a KVM switch configuration and all connected servers from any remote console over a TCP/IP connection. The IP Device can also be set up to provide remote access to an individual computer or server.
  • Page 6 Flash upgrades allow you to obtain the latest firmware updates for your IP Device. These firmware updates ensure that the IP Device is compatible with the latest devices and hardware and are free for the life of the IP Device. Visit www.belkin.com for upgrade information and support.

  • Page 7: Equipment Requirements

    Overview Equipment Requirements Cables To connect the IP Device to your KVM switch or individual server, the included PS/2 KVM Cable Kit is required. To connect the IP Device to your local area network, you will need to locate a network cable with an RJ45 connector.

  • Page 8: System Requirements

    ® • Solaris 8.x and above* *Adapters may be required. KVM Switches The IP Device is compatible with the following Belkin KVM Switches: • OmniView Quad-Bus Series • OmniView SMB Series • OmniView PRO2 Series • OmniView SE Plus Series...
  • Page 9 Overview System Requirements Keyboards • PS/2-compatible Mice • PS/2-compatible with 2, 3, 4, or 5 buttons • PS/2-compatible wireless and optical mice Monitors • CRT and LCD (with VGA support) Remote-Console Software The SMB Remote IP Device may be accessed remotely over a TCP/IP connection from computers using the following web browsers and OS platforms: •...

  • Page 10: Unit Display Diagrams

    Overview Unit Display Diagrams Front View Ethernet PS/2 Mouse VGA Monitor Port Console Port Console Port PS/2 Keyboard Console Port Back View Go Local/ Serial-Device Port Reset Button KVM/Server Power Port Jack Power Status LED...

  • Page 11: Specifications

    PS/2 keyboard and mouse console ports. **Typical bandwidth is defined as typical “non-intensive” administrative use at 16-bit color, 1024x768 resolution. Note: Specifications are subject to change without notice. F1DP101M 1 digital or 1 local Aluminum 3.3V DC, 1.3A power adapter...

  • Page 12: Hardware Installation

    Hardware Installation Pre-Configuration ����������� ������� ��������� ����������� ��������� ������ ���������� ����������� (Typical configuration) Where to place the IP Device: The IP Device includes a mounting bracket and is designed for stand-alone or 0U rack-mount installation. Consider the following when deciding where to place the Switch: •...

  • Page 13: Step 1 Mounting The Ip Device (Optional)

    Hardware Installation Step 1 Mounting the IP Device (optional) Note: Before you begin, locate the MAC address and device number on the bottom of the IP Device. You will need these numbers later in the installation process, so it is highly recommended that you record these numbers below before mounting the IP Device to your rack.

  • Page 14: Step 2 Connecting The Console To The Ip Device

    Hardware Installation Step 2 Connecting the Console to the IP Device 2.1 Connect your monitor VGA cable to the monitor port on the front of the IP Device labeled “ 2.2 Connect your keyboard and mouse PS/2 cables to the keyboard and mouse ports on the front of the IP Device.

  • Page 15: Step 3 Connecting The Kvm Switch Or Server To The Ip Device

    Hardware Installation Locate and connect a cable from your local area network to the RJ45 Ethernet port on the back of the IP Device. (Refer to diagram below.) Step 3 Connecting the KVM Switch or Server to the IP Device 3.1 Make sure your KVM switch and all connected servers are powered off.
  • Page 16 Hardware Installation 3.3 Using the other end of the cable kit, connect the VGA and PS/2 cables to the console monitor, keyboard, and mouse ports on your KVM switch or server. (Refer to diagrams below.) Connecting to a KVM Switch �����������...

  • Page 17: Step 4 Powering Up The Systems

    Hardware Installation Step 4 Powering Up the Systems 4.1 Attach the power adapter to the IP Device and connect it to a power source to power up the IP Device. (Refer to diagram below.) ������ 4.2 Power on the KVM switch or server connected to the IP Device. The IP Device emulates both a mouse and a keyboard on each port, and allows your KVM switch or server to boot normally.

  • Page 18: Remote Installation

    Remote Installation Initial Settings The following section provides instructions for setting the IP address for the OmniView SMB Remote IP Device. Step 1 Identifying the IP Address Once your IP Device has been connected to your network and is powered up, a Dynamic Host Configuration Protocol (DHCP) server on your network will automatically assign the IP Device an IP address, gateway address, and subnet mask.

  • Page 19: Logging Into The Web Interface

    Remote Installation Step 2 Logging into the Web Interface To log into the web interface: Open your web browser (Internet Explorer version 6.0 or above is required). If you are using Windows Vista, you must run Internet Explorer in administrator mode. In order to run Internet Explorer in administrator mode, right-click on Internet Explorer and select “Run as Administrator”.
  • Page 20 Remote Installation Click . The web interface will open at the Network-Configuration page (see Fig. 2). Fig. 2 Network-Configuration Page...

  • Page 21: Network Configuration

    Click “Yes” on both warnings. Note: The first security warning only occurs once per client machine. This is when the Belkin root certificate is installed. The second warning can be avoided by adding a line to your Windows “hosts” file (typically at \winnt\system32\ drivers\etc\hosts—edit using Notepad).
  • Page 22 Remote Installation Enable DHCP When this box is checked (default setting), a DHCP server on your network is enabled to assign an IP address to the IP Device. When this box is not checked (recommended), you can assign a static IP address to the IP Device. Set a Static IP If you choose not to use DHCP, uncheck the “Enable DHCP”...

  • Page 23: User Settings

    Remote Installation Step 4 User Settings In the User-Profile page, you can create and edit up to 25 different user accounts. To open the page, click “User Settings” under “Administration” in the far-left menu (see Fig. 3). There are three levels of user access: Administrator An administrator has unrestricted access to all windows and settings and can “take over”...

  • Page 24: View Only

    Remote Installation View Only A “view only” user is only allowed to view the screen of the target server without keyboard and mouse control. Only limited options appear, such as “disconnect”. A View Only icon will appear on the viewer’s local mouse pointer to indicate this status.
  • Page 25 Remote Installation To edit a user: Select the user from the list. Click . You can now change all the available parameters—user name, permission type, and password. Click to save the changes. Note: For security, you should change the password for the default “admin”...

  • Page 26: Step 5 Switch Configuration

    Remote Installation Step 5 Switch Configuration When a KVM switch is connected to the IP Device, you must specify the manufacturer and model of the switch in the “Switch Configuration” section. The Switch-Configuration page allows you to specify the KVM Switches attached to the IP Device.
  • Page 27 Server names left as “UNUSED” cannot be accessed. Installing new Switch-Definition Files (SDFs) If your KVM switch-configuration type is not listed in the drop-down list, contact Belkin Technical Support at (800) 282-2355 to request an updated SDF with the desired KVM-configuration list. To install the SDF: Load the file onto the client computer.

  • Page 28: Step 6 Serial Settings

    Remote Installation Step 6 Serial Settings The SMB Remote IP Device supports one serial device, which can be attached using the included serial cable. The serial device can be accessed remotely via the IP Device’s VT100 serial terminal emulation. If you have a serial device connected to the Switch, such as a power distribution unit (PDU), you must configure the serial (RS232) settings.

  • Page 29: Step 7 Security Settings

    Remote Installation Step 7 Security Settings The Security-Settings page allows you to configure security features for the IP Device. To open the Security-Settings page, click “Settings” under “Security” in the far-left menu (see Fig. 6). Fig. 6 Security-Settings Page You can configure the following security features: Account Blocking Specify the number of invalid login attempts allowed before the user is locked out.

  • Page 30: Ssl Certificate

    Remote Installation Idle Timeout Select the maximum time allowed for inactivity before the user is disconnected from the remote session. Choose “No Timeout” to disable the Idle Timeout feature. By default, the timeout inactivity period is set to 10 minutes. SSL Certificate You can install your company’s own SSL certificate to protect data transferred over the Internet between your servers and remote console.

  • Page 31: Maintenance

    Maintenance Firmware Upgrade You can upgrade the IP Device’s firmware to take advantage of new features or fixes as they become available. Visit www.belkin.com/support to check for firmware updates. To upgrade firmware: Download and save the firmware file on the client computer.

  • Page 32: Restore Factory Settings

    Remote Installation Restore Factory Settings You can restore the IP Device to its original factory settings. This restores the original parameters, resetting all the information added by the administrators, including: network settings, servers, switches, users, and passwords. You also have the option to preserve network settings, as explained below. WARNING! Once data has been reset, it cannot be retrieved.

  • Page 33: Using The Remote Ip Device

    . By default, the user name is “admin” and the password is “SMBremote” (both are case-sensitive). If it is your first time connecting, you will be prompted to install the Belkin certificate and the Microsoft ActiveX control. You must have administrator privileges on your client computer to install the ActiveX control.

  • Page 34: Full-Screen Mode

    Using the Remote IP Device Full-Screen Mode You can work on the target server in full-screen mode, just as if you were connected to the server locally. To work in full-screen mode: Ensure that the client computer has the same screen resolution as the target server.

  • Page 35: Using The Quick-Access Toolbar

    Using the Remote IP Device Using the Quick-Access Toolbar The quick-access toolbar provides an easy method for changing settings and switching servers (see Fig. 12). Fig. 12 Quick-Access Toolbar Icon Function Minimize or maximize the toolbar Disconnect the remote session Configure the mouse and change settings Configure the keyboard and change settings Adjust the video settings...

  • Page 36: Mouse Configuration And Settings

    Using the Remote IP Device Mouse Configuration and Settings Mouse-Pointer Alignment When working remotely at the client computer, two mouse pointers will appear: one for the client computer and one for the target server. The client computer’s mouse pointer will appear on top of the target server’s. The mouse pointers should be synchronized (aligned).

  • Page 37: Manual Settings

    Using the Remote IP Device Manual Settings You must manually synchronize the mouse pointers if: • the mouse setting on the target server was ever changed, or • the operating system on the target server is Windows 2000, Linux, Novell SCO UNIX, or Sun Solaris To manually synchronize mouse pointers: In the quick-access toolbar, click...
  • Page 38 Using the Remote IP Device Follow the instructions and set any relevant sliders to the same values as set in the target server’s mouse properties. Examples: For servers running on Windows XP, go to the Mouse settings in the Control Panel and uncheck “Enhance pointer precision” (see Fig. 14). Fig.

  • Page 39: Advanced-Mouse Emulation

    In the Advanced-Mouse settings, you can set the type of mouse you would like the IP Device to emulate. Note: Belkin recommends that you NOT change the advanced settings unless there is erratic mouse behavior (i.e., if the mouse is making random clicks and jumping arbitrarily around the screen).

  • Page 40: Keyboard Configuration And Settings

    Using the Remote IP Device Keyboard Configuration and Settings You can define and transmit a keyboard sequence directly to the target server, without affecting the client computer. To transmit a keyboard sequence: In the quick-access toolbar, click Select a key sequence to transmit to the target server. For example, if you select the “Ctrl-Alt-Del”...
  • Page 41 Using the Remote IP Device Click “Add Predefined”. A list of sequences will appear. Select the desired sequence and click “OK”. The sequence will appear in the Special-Key-Manager box. Click “OK”. The sequence will now appear in the Keyboard-Key- Sequence list. To record a keyboard sequence: In the quick-access toolbar, click Click “Add/Remove”.

  • Page 42: Video Configuration And Settings

    Using the Remote IP Device Video Configuration and Settings Refresh You may need to refresh the video image when changing the display attributes of a target server. To refresh the video settings: In the quick-access toolbar, click Select “Refresh” or press “Crl+R”. Manual Video Adjust You may want to manually adjust video to fine-tune the target-server video settings, to adapt to a noisy environment or a non-standard VGA signal, or...

  • Page 43: Auto Video Adjust

    Using the Remote IP Device Fig. 18 Manual Video-Adjust Bar Auto Video Adjust To adjust the video automatically: Open Internet Explorer (or similar) in the background. In the quick-access toolbar, click Select “Auto video adjust”. The process will take a few seconds. If the process runs for more than three seconds, there may be an abnormal noise level.

  • Page 44: Performance Settings (Bandwidth)

    Using the Remote IP Device Performance Settings (Bandwidth) You can adjust the bandwidth settings on the IP Device to give you the desired compression and color-support levels for your remote sessions. To change the bandwidth settings: In the quick-access toolbar, click on appear (see Fig.

  • Page 45: Selecting A Server

    Using the Remote IP Device Selecting a Server The quick-access toolbar allows you to easily select and switch to any server connected to the Switch or daisy-chain configuration. To connect to a different server: In the quick-access toolbar, click servers will appear (see Fig. 20). If a serial device is connected to the IP Device, it will also appear on the list.

  • Page 46: Additional Features

    Using the Remote IP Device Additional Features When you right-click From this menu you can access your connected servers. The menu also provides the following features: • Disconnect—Disconnects the remote session. • About—Verifies the current version of software/firmware of your IP Device. •...

  • Page 47: Restoring Factory Defaults

    Using the Remote IP Device Restoring Factory Defaults The “Restore Factory Settings” section on page 29 explains how to restore factory settings from the web interface. When you cannot access the system (you have forgotten the user name, IP address, or password), you can restore factory defaults from the IP Device.

  • Page 48: Frequently Asked Questions

    XP, 2003 Server; Sun; Solaris; Novell; and Linux. Does the Switch support Microsoft IntelliMouse The IP Device supports mice from Microsoft, Logitech Belkin. Please contact Belkin Technical Support for compatibility issues you may experience. What is the maximum video resolution that the...
  • Page 49 Frequently Asked Questions What communication ports does the IP Device use so it can be accessed remotely? Five ports have to be open to remotely connect to the IP Device. Ports 80 and 443 are used for standard web communication. Three consecutive ports are used to send the remote video.

  • Page 50: Troubleshooting

    Troubleshooting Problem: The Remote console login page will not display on my browser. Solution: • Verify that you are using Microsoft Internet Explorer 6.0 or higher. • Verify that the ActiveX plug-in is installed and enabled for the web browser. •...
  • Page 51 Troubleshooting Problem: The video quality is bad and/or grainy. Solution: • Use the quick-access toolbar to refresh the video screen. • Use the quick-access toolbar and select “Automated adjust” under “Manual video adjust”. Refer to page 39. Problem: The video performance and/or mouse performance is slow. Solution: •...

  • Page 52: Glossary

    Glossary The following definitions are used throughout this User Manual. Client Computer: The computer being used to access the Switch remotely over a TCP/IP connection. Console: The all-in-one term for the keyboard, video monitor, and mouse connected to a KVM switch. Console Port: Receptors for the console to connect to the KVM switch.
  • Page 53 Glossary KVM: Literally “Keyboard Video Mouse”, this term refers to technology that allows two or more computers to be controlled by one keyboard, video monitor, and mouse; some switches that use KVM technology enable sharing of other peripherals such as audio speakers, microphones, and printers.

  • Page 54: Information

    Information FCC Statement Declaration of Conformity with FCC Rules We, Belkin International, Inc., of 501 West Walnut Street, Compton CA 90220, declare under our sole responsibility that the products: to which this declaration relates: Comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 55 Information How to get service. To get service for your Belkin product you must take the following steps: 1. Contact Belkin, at 501 W. Walnut St., Compton CA 90220, Attn: Customer Service, or call (800)-223-5546, within 15 days of the Occurrence. Be prepared to provide the following information: a.
  • Page 56 +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax © 2007 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows, Windows Vista, Internet Explorer, Microsoft, NT, IntelliMouse, and ActiveX are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
