Care and Maintenance -
Do not leave canopy extended during heavy snow storms or any extreme weather conditions.
Reasonable care should be taken to remove accumulated dirt and debris in track.
Canopy Tracks may have sharp corners. Always use gloves when handling to prevent cuts.
Lubrication (supplied in kit) of wing wheels and track should be done annually.
Wing and canopy can be removed seasonally to improve longevity.
To keep the Harbor-Time canopy fabric looking clean and bright, wash periodically with a soft brush,
warm water and mild soap. Do not use detergent.
5 year limited manufacturer's warranty on the Harbor-Time canopy fabric.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any Outdoor Living Today
products.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
OLM Retractable Canopy for
12X16 Breeze Pergola
Outdoor Living Today
www.outdoorlivingtoday.com
Page 1
Assembly Manual
by
sales@outdoorlivingtoday.com
Revision #11
March 14th /2018
Advertisement
Related Manuals for OLT 12x16 Breeze Pergola
Summary of Contents for OLT 12x16 Breeze Pergola
- Page 1 Assembly Manual OLM Retractable Canopy for 12X16 Breeze Pergola Outdoor Living Today Revision #11 March 14th /2018 Care and Maintenance - Do not leave canopy extended during heavy snow storms or any extreme weather conditions. Reasonable care should be taken to remove accumulated dirt and debris in track.
-
Page 2: Troubleshooting
Once your pergola and retractable canopy have been correctly installed, do a water test to confirm water is draining properly from the canopy. Please contact us immediately if large amounts of water remain in each fabric fold when extended. The Canopy is designed to hold several gallons of water per fold. -
Page 3: Tools Required
12x16 Breeze Pergola Retractable Canopy Parts List 1 1/4” Brown Wood 1 1/4” Self Tapping Pan 4” Brown Screws - Screws - 14 Pcs. Head Screws - 18 Pcs. - 12 Pcs. A - 1 1/2” x 2 1/2” x 8 1/2”... - Page 4 Installation of the OLM Retractable Canopy couldn’t be easier. Just 4 Easy Steps! 1. Attach lowering cleat and canopy tracks to pergola framing. 2. Lift aluminum wings with canopy and feed wheels into track. 3. Position aluminum wing stops and attach. 4.
- Page 5 5 Cleats Check that pergola is level prior to Counter sunk installing lowering cleats. Install Aligned with Blocking cleats on low side to ensure proper drill holes. canopy water drainage. With a Step Ladder, install Part A - Canopy Lowering Cleats - 5 pcs. (1 1/2” x 2 1/2” x 8 1/2”) with 2 - 4”...
- Page 6 2- 1 1/4” Silver Self Tapping Screws. Overlap and flush against Post. 1 1/4” Silver Self Tapping Screws can be hard to start in the aluminum track. Try pre-drilling track first with 1/8” drill bit. Carefully lift up 91 1/2” long Track and place underneath lowering cleats and against posts. Slide track end against existing track end together using the black connector as a guide.
- Page 7 3- 1 1/4” Silver Self Tapping Screws per side. 1 1/4” Brown Screws .Now attach tracks on the opposite side of pergola following Steps 2 and 3. The only exception is that lowering cleats are not required. Screw tracks into underside of joists or blocking to secure.
- Page 8 Rope Knot on inside Pull Rope on Lead Wing Gap side Before feeding Part C - 133” long Aluminum Wings (8) with Canopy into track, make sure canopy fabric is facing the correct direction. First, locate Lead and Anchor Wings in set.
- Page 9 Continue to feed wings into the track until all wings are installed. 3rd Wing Install Part D - 4 1/4” long Aluminum Wing Stops - 2 Pcs. where track ends and gap exists. Use 2 - 1 1/4” brown screws per stop to install. When removing the wings and canopy in the future, simply remove wing stops and roll wing and canopy out carefully with a helper.
- Page 10 Part F - Canopy Pull Handle Using Part F - Canopy Pull Handle, pull canopy Lead Rope back and forth a few times to lubricate wheels and track. If wing binds, stop and pull foward until wings are straight and start again. When wings and canopy are tracking well, pull canopy to anchor side of pergola to install Part D - Wing Anchor Knob.
- Page 11 Lead Rope Lead wing tight against corner bracket Pull canopy out using pull handle on lead rope. Fully extend canopy until canopy cannot extend further. Follow Step 12 to position and attach wing anchor knob to outside girder. Extend and contract the canopy several times with pull handle.
- Page 12 Congratulations on installing your OLM Retractable Canopy from Outdoor Living Today. Care and Maintenance - Do not leave canopy extended during heavy snow storms or any extreme weather conditions. Reasonable care should be taken to remove accumulated dirt and debris in track. Canopy Tracks may have sharp corners.
