Care and Maintenance -
Do not leave canopy extended during heavy snow storms or any extreme weather conditions.
Reasonable care should be taken to remove accumulated dirt and debris in track.
Canopy Tracks may have sharp corners. Always use gloves when handling to prevent cuts.
Lubrication (supplied in kit) of wing wheels and track should be done annually.
Wing and canopy can be removed seasonally to improve longevity. Check Wheels and Axel to
ensure proper working order. Do not operate if cracked or broken. Call OLT for replacement.
Check Track Screws for wear annually. Remove and replace any screws showing excessive wear.
To keep the Harbor-Time canopy fabric looking clean and bright, wash periodically with a soft brush,
warm water and mild soap. Do not use detergent.
5 year limited manufacturer's warranty on the Harbor-Time canopy fabric.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any Outdoor Living Today
products.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
OLM Retractable Canopy for
12X12 Breeze Pergola
Outdoor Living Today
www.outdoorlivingtoday.com
Page 1
Assembly Manual
by
sales@outdoorlivingtoday.com
Revision 8
August 1st /2017
Advertisement
Related Manuals for OLT OLM Retractable Canopy
Summary of Contents for OLT OLM Retractable Canopy
- Page 1 Wing and canopy can be removed seasonally to improve longevity. Check Wheels and Axel to ensure proper working order. Do not operate if cracked or broken. Call OLT for replacement. Check Track Screws for wear annually. Remove and replace any screws showing excessive wear.
-
Page 2: Parts List
12x12 Breeze Pergola Retractable Canopy Parts List Parts List 1 1/4” Self Tapping Pan Head Screws 4” Brown Screws - 1 1/4” Brown Wood Screws - - 14 Pcs. - 8 Pcs. - 8 Pcs. A - 1 1/2” x 2 1/2” x 8 1/2” Canopy Lowering Cleat - 3 Pcs. - Page 3 Installation of the OLM Retractable Canopy couldn’t be easier. Just 4 Easy Steps! 1. Attach lowering cleat and canopy tracks to pergola framing. 2. Lift aluminum wings with canopy and feed wheels into track. 3. Position aluminum wing stops and attach.
- Page 4 3 Cleats With a Step Ladder, install Part A - Canopy Lowering Cleats - 3 pcs. (1 1/2” x 2 1/2” x 8 1/2”) with 2 - 4” screws. Cleats will lower the canopy on one side and drain water off the fabric so it doesn’t collect excessively.
- Page 5 2 - 1 1/4” screws/cleat. Align and attach second Canopy Track directly underneath lowering cleats as per Step 2. Position track with drilled end flush against post as illustrated above. Use 2 -1 1/4” Silver Self Tapping Screws from 2 - 1 1/4” screws/cleat. track into each lowering cleat.
- Page 6 Rope Knot on inside Anchor Rope on Pull Rope on Lead Wing last wing facing out Gap side Before feeding Part C - 133” long Aluminum Wings (6) with Canopy into track, make sure canopy fabric is facing the correct direction. First, locate Lead and Anchor Wings in set.
- Page 7 Continue to feed wings into the track until all wings are installed. 3rd Wing 6 Wings Both sides Install Part D - 4 1/2” long Aluminum Wing Stops - 2 Pcs. where track ends and gap exists. Use 2 - 1 1/4” brown screws per stop to install. When removing the wings and canopy in the future, simply remove wing stops and roll wing and canopy out carefully with a helper.
- Page 8 Part F - Canopy Pull Handle Using Part F - Canopy Pull Handle, pull canopy Lead Rope back and forth a few times to lubricate wheels and track. If wing binds, stop and pull foward until wings are straight and start again. When wings and canopy are tracking well, pull canopy to anchor side of pergola to install Part E - Wing Anchor Knob.
- Page 9 Lead wing tight against corner bracket Lead Rope Pull canopy out using pull han- dle on lead rope. Fully extend canopy until outside lead wing con- tacts corner bracket or until canopy cannot extend further. Follow Step 10 to position and attach wing anchor knob to outside girder.
- Page 10 Congratulations on installing your OLM Retractable Canopy from Outdoor Living Today. Care and Maintenance - Do not leave canopy extended during heavy snow storms or any extreme weather conditions. Reasonable care should be taken to remove accumulated dirt and debris in track. Canopy Tracks may have sharp corners.
