Hardware Bag - Simplicity 1695299 Illustrated Parts List

Mower Driven Vac Group
REF NO PART NO.
48 1720921SM
49 1921959SM
50 1720918ASM
51 1713588SM
52 1921719SM
53 1919438SM
54 1917356SM
55 1917372SM
56 1700654ASM
57 1935255SM
58 1700669SM
59 1931320SM
60 1930645SM
61 1929000SM
62 1668500SM
63 1727149SM
64 1720613ASM
65 1721023ASM
66 1700259SM
68 1931332SM
69 1660617SM
70 1720927
Footnotes
The above parts group applies to the following Mfg. Nos.:
1695299 - 54" Turbo Blower
Briggs and Stratton Yard Power Products Group
Copyright © 2007 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
3 TAB, Locking (Included in Ref. No. 69)
4 CAPSCREW, Hex Head, 1/4 - 20 x 5/8 (Qty of 2 included in Ref. No. 69)
1 COVER
1 SPACER
1 CAPSCREW, Hex Head, 5/16 - 18 x 2-1/2, G5
1 NUT, Hex Lock ESNA, 5/16 - 18
7 LOCKWASHER, Spring, 5/16 (Qty of 6 included in Ref. No. 69)
7 NUT, Hex, 5/16 - 18 (Qty of 6 included in Ref. No. 69)
1 BRACKET, "C"
1 NUT, Speed, 5/16 - 18
1 KNOB, Plastic
1 BOLT, Carriage, 1/4 - 20 x 1-1/4 (Included in Ref. No. 69)
1 NUT, Hex Two-Way Lock Flange, 3/8 - 16
2 SCREW, Hex Washer Head Taptite, 1/4 - 20 x 3/8 (Included in Ref. No. 69)
1 BRACKET, "L"
1 SPRING, Extension
1 BAFFLE, Front L.H.
1 BAFFLE, Front R.H.
1 DECAL, Danger Thrown Objects
6 BOLT, Carriage, 5/16 - 18 x 3/4 (Included in Ref. No. 69)
1

HARDWARE BAG

1 INSTRUCTION MANUAL (Not shown)
7
TP 400-4530-00-AT-SMA
