- Page 1 RESS Visual Inspection Sweep Instruments Measuring Instruments The Producer Manual Monitor FM7 Pro...
-
Page 3: Delivery Contents
- The video inspection system is not for use in the medical field! - Any kind of reparations on inside of the unit, must be carried out, exclusively by qualified staff! (If required, contact the RESS-customer service) - The connection and disconnection, the respective components of the system, must always... - Page 4 2 The SD card slot is at the top of the 3 12 pin connector for camera-system cable monitor. 4 Charging socket 5 Control keys 6 LCD voltage display 7 On/Off switch 8 Trimmer for basic position of the Rotary-Ball-Camera 9 Joystick control RESS...
- Page 5 If your portable camera head made an indepen- dently movement, without the control stick been touched, then use the two trimmers to bring it into basic position. Also bring the knobs into position, so that the camera head is at rest. 6 RESS...
-
Page 6: Working With The Device
The green light indicates, that the charger is on. If the light is red, the battery is being charged. Charging is completed when the red light switches off. The charger will switch off automatically, so an overcharging is impossible. Charging socket RESS... -
Page 7: Control Buttons
EXIT in the menu and press no.1 or 5. It will switch back to the live image automatically, if there is no selection within 10 seconds. * If you want to save longer video sequences, you must press after 300 seconds the record button again, to trigger further storage. 8 RESS... -
Page 8: Memory Card
1 photo 32 kb (720x576 pixel) 120 second video 42 MB Power supply Lead acid battery 12 V/2,2 Ah Voltage monitoring LCD-display Operating time Approx.165 minutes (depending on the camera head that is being used) Charging time ca. 1 1/2 hours RESS... - Page 12 RESS Visual Inspection Sweep Instruments Measuring Instruments The Producer RESS GmbH & Co. KG Am Hasselbruch 28 D-32107 Bad Salzuflen Germany Tel. ++49 5208/91270 Fax ++49 5208/8030 19.03.2018 info@ress.de www.ress.de...
