- Page 1 INSTRUCTION MANUAL Battery Pack, EC THIS INSTRUCTION MANUAL IS AN ORIGINAL Document ID: 73-H001...
- Page 2 Colours used in illustrations of e.g. cables are only illustrative and might deviate from the actual colour. Without written permission from Nilar AB this manual is not to be copied or transferred for other purposes, neither in entirety nor parts of it.
- Page 3 Installation personnel 6. Installation Operational conditions Installation personnel, 7. Operation operators Advises, schedules Maintenance personnel 8. Maintenance Instructions, references Installation personnel 9. Decommissioning Self-help Operators, installation and 10. Troubleshooting maintenance personnel Document ID: 73-H001. Copyright © Nilar AB. All rights reserved.
-
Page 4: Table Of Contents
Installation of battery pack ..........................17 Series connection (Battery String) ........................21 7. Operation ............................. 26 Charging ................................. 26 Discharging ..............................26 Resistance ..............................26 Self-discharge ..............................26 Cycle life ................................. 27 Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. - Page 5 9. Decommissioning ..........................29 Temporarily decommissioning ........................29 Permanent decommissioning ......................... 29 10. Troubleshooting ..........................30 11. Appendices ............................31 Appendix 1: Circuit diagram ............................31 Appendix 2: Information bulletin, ITgrounding ......................32 Document ID: 73-H001. Copyright © Nilar AB. All rights reserved.
- Page 6 Figure 31: Installation of CANopen connection into CAN1 on IMU ..................18 Figure 32: Installation of Fan connection ........................... 19 Figure 33: Installation of 24VDC power supply connection) ..................... 19 Figure 34: Installation of ambient temperature sensor connection ..................19 Document ID: 73-H001. Copyright © Nilar AB. All rights reserved.
- Page 7 Table 1: Technical specification of battery pack in various sizes @ +20 C................. 5 Table 2: Description of visual signals ............................8 Table 3: Relation between temperature and the recommended maximum storage time at 75% SOC initial capacity ..14 Document ID: 73-H001. Copyright © Nilar AB. All rights reserved.
-
Page 8: Safety Information
Work only with one battery pack terminal at the Keep product surfaces clean and dry. CAUTION! time. • Rupture disc may release electrolyte during abnormal use. We therefore recommend wearing safety glasses. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 1 (32) -
Page 9: Warranty
‘Warranty certificate’ that follows the purchase of this product as a separate document. For an outline of the warranty conditions we refer to the general ‘Terms and conditions’ on the contract. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 2 (32) -
Page 10: Environment
Please contact Nilar AB in order to find your closest representative. When the Nilar battery pack has reached its end of life, Nilar AB takes the full responsibility for the recycling process by retrieving the complete battery packs. -
Page 11: Function Description
Figure 1: Overview of 144V, 120V and 96V battery packs incl. IMU (from left to right) Figure 3: Measurement illustration of 144V battery pack with length incl. and excl. IMU Figure 2: Build-up of a 144V battery pack Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 4 (32) -
Page 12: Figure 4: Parts Of 144V Battery Pack Excl. Imu
Rupture disc (① not displayed) Max. allowed battery pack temperature The Nilar battery pack is fitted with a rupture disc that is Max. allowed activated at a pressure of 6 bar. The rupture disc is battery pack relative located on the rear side of the battery pack. The rupture... -
Page 13: Integrated Monitoring Unit (Imu)
Module (⑤, light and medium grey ●● Positive terminal (+) The 12V module is the building block for all Nilar battery Negative terminal (-) packs. 10 cells are connected in series in a module to create modules with a rated capacity of 10 Ah and nominal voltages of 12V. -
Page 14: Connections Imu
Operation LED (①) The operational LED indicates the status of the IMU as displayed in the following table. Figure 9: Design, negative (-) cable connector, type Phoenix 1774687 Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 7 (32) -
Page 15: Figure 11: Indicated Connection Points Of Imu
4.3.3 Overview - connections Figure 12: Current connection, schematic The following connections/switches are available on the IMU and their function is as explained in the following sections. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 8 (32) -
Page 16: Figure 13: Design Current Connector, Type Phoenix 1984031. With Front-/Outside Visible (Screws On Top)
Connector: Molex 51103 (or corresponding) unique identification (address). This identification is set by the DIP-switch. Figure 17: DIP-switch for address setting Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 9 (32) -
Page 17: Figure 18: Can1 And Can2 Connection, Schematic
Connector: Molex 51103-0400 (or corresponding) Nominal voltage: 12VDC to 24VDC (depending on system setup) Max fan power: 12W Figure 21: Fan connection, schematic Figure 18: CAN1 and CAN2 connection, schematic Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 10 (32) -
Page 18: Figure 22: Design Fan Connector, Type Molex 51103-0400
Figure 24: Design Power in connector, type Phoenix 1934887. With front- /outside visible (screws on top) For a more detailed description of the IMU, please refer to the EDS description (doc. Id: SPN-170063-88-H001) Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 11 (32) -
Page 19: Signals Imu
An internal battery pressure sensor measures the relative pressure in each battery pack. Due to the common gas space in the Nilar bipolar pack design, all the cells in the battery pack have the same pressure. If the pressure is out of the defined range, an alarm will be triggered and communicated to the external battery management system. -
Page 20: Transportation, Lifting And Storage
Please make sure that the battery packs are transported by sea in quantities of over 100 packs are positioned in the correct kg in one transport unit. Nilar battery packs are then way during transportation and defined as dangerous goods, class 9. UN number and storage (see section 6.3 Orientation) -
Page 21: Moving And Lifting
It is advised to always carry the battery packs using these lifting straps, preferably in connection with lifting aids. Figure 25: Battery pack incl. lifting straps Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 14 (32) -
Page 22: Installation
Do not install where liquids, or any other foreign object or substance may enter the battery pack. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 15 (32) -
Page 23: General Conditions On Site
Figure 26: Installation of battery pack, orientation alt. 1 In alternative #1 the terminals are at the upper side (↑) of the battery pack and the IMU is on the front side (→) Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 16 (32) -
Page 24: Installation Of Battery Pack
The detail cut-out indicates the position and direction (←)of the rupture disc outlet, as seen from the opposite side. Figure 28: Position of PCB connectors Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 17 (32) -
Page 25: Figure 29: Before And After Cover Lid Removal
Indicated as blue (●) in the following figure. Figure 31: Installation of CANopen connection into CAN1 on IMU Figure 30: Installation of current sensor cable on IMU Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 18 (32) -
Page 26: Figure 32: Installation Of Fan Connection
24VDC power supply between battery packs in a battery string). Indicated as red (●) in the following figure. Figure 34: Installation of ambient temperature sensor connection Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 19 (32) -
Page 27: Figure 35: Detail View Of Cable Entry On Cover Lid Of Imu
Figure 35: Detail view of Cable entry on cover lid of IMU Figure 37: Installation of negative (-) cable, after connection (IMU connections not displayed) Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 20 (32) -
Page 28: Series Connection (Battery String)
It is of outmost importance that every battery string’s combined voltage is the same in-between the battery strings. Figure 39: Installation of positive (+) cable, after connection (IMU connections not displayed) Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 21 (32) -
Page 29: Figure 40: Battery String Sorted According To Labeling, From Right To Left
CAN2 socket of battery pack ‘B’. Connect the other side of the cable into the CAN2 socket of battery pack ‘B’. Indicated as green (●) in the following figure. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 22 (32) -
Page 30: Figure 43: Installation Of Canopen Communication Cable
IMU of each battery pack and connect the other end on the external fans (see section 6.4.4) Indicated as yellow (●) in the following figure. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 23 (32) -
Page 31: Figure 47: Installation Of Negative (-) Cable (Imu Connections Not Displayed)
‘A’. Connect the negative (-) cable connector of the interpack cable into the negative (-) chassis connector of battery pack ‘B’. Figure 48: Finished installation of negative (-) cable (IMU connections not displayed) Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 24 (32) -
Page 32: Figure 50: Finished Installation Of Interpack Cable Between Battery Pack 'A' And 'B
Plug in the positive (+) cable connector from the BMS into the positive (+) chassis connector of battery pack ‘D’. Indicated as red (●) in the following figures. Figure 52: Installation of positive (+) cable Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 25 (32) -
Page 33: Operation
It is recommended to terminate discharge on a pre-set safety. minimum allowed voltage to optimize performance and Please consult Nilar AB to define the operating window for your life expectation of the battery pack. With proper specific application. settings of the end of discharge voltage (EODV) -
Page 34: Cycle Life
As a user this is experienced as decreasing run time and finally, depending on how end of life is defined, the battery pack is not able to perform as required. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 27 (32) -
Page 35: Maintenance
Personnel involved in the work on or in close vicinity to a battery pack must be competent to carry out such tasks, and must be trained in all necessary special procedures. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 28 (32) -
Page 36: Decommissioning
Nilar representative. Figure 54: WEEE symbol In accordance with the Directive 2006/66/EC ‘Battery directive’, Nilar AB as a producer and its authorised local representatives are obliged to finance all cost arising Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. -
Page 37: Troubleshooting
(see section (troubleshot the external fan). Replace if 6.5.12) necessary. A.4) Replace the IMU circuit board (request separate maintenance instruction from Nilar AB). Document ID: 73-H001. Copyright © Nilar AB. All rights reserved. Page 30 (32) -
Page 38: Appendices
INSTRUCTION MANUAL 11. Appendices Appendix 1: Circuit diagram Document ID: 73-H001. Copyright © Nilar AB. All rights reserved.. Page 31 (32) -
Page 39: Appendix 2: Information Bulletin, Itgrounding
(e.g. wing screws) are not allowed! a unique key. Document ID: 73-H001. Copyright © Nilar AB. All rights reserved.. Page 32 (32) - Page 40 Visit our website at www.nilar.com/contact Nilar AB Nilar AB Nilar Inc. Headquarters and Sales R&D and Production R&D and Sales Stockholmsvägen 116 B Bönavägen 55 10800 E. Bethany Drive, Suite 525 SE-187 30 Täby Box 8020 Aurora, CO 80014 Sweden SE-800 08 Gävle...
