Summary of Contents for hearX hearScope
- Page 1 USER MANUAL...
- Page 2 - Ground Floor, Building 2, Ashlea Gardens Office Park, 180 Garsfontein Road, Ashlea Gardens, Pretoria, 0081, South Africa hearScope v2. HSCP-MN-EN hearScope IFU v1.0 For more information visit www.hearxgroup.com or contact hearX: info@hearxgroup.com ZA: +27 12 030 0268 US: +1 415 212 5500...
- Page 3 Android smartphone (can be user-supplied). The device is supplied with a protective case. The intended use of hearScope™ is to visually inspect the outer ear canal and tympanic membrane under magnification. Imaging of the outer ear canal and tympanic membrane is viewed on the smartphone, using the hearScope™...
-
Page 4: What's In The Box
WHAT’S IN THE BOX? Protective case hearScope™ Smartphone video otoscope with Micro USB cable Reusable ear tips 2x Small, 2x Medium and 2x Large reusable ear tips included with initial purchase. -
Page 5: Setup Instructions
SET UP INSTRUCTIONS • Switch on the smartphone, download and open the hearScope™ application. https:/ /play.google.com/store/apps/details?id=com.hearxgroup.hearscope • Connect the hearScope™ to your smartphone (use the micro USB to USB-C adaptor if required). • Grant your smartphone permission to access the hearScope™. - Page 6 Go to Menu/Tutorial. 1. Open the hearScope™ application on your smartphone. 2. Orientate your hearScope™ right side up by pointing it at an object and rotating the hearScope until the image on the hearScope™ application is the right way up.
- Page 7 5. Select an ear tip and fit it to your hearScope™ so that your thumb fits comfortably on the focus wheel. Note: The first few fits can be tight so push the ear tip onto the hearScope™...
- Page 8 6. Gently insert the ear tip into the ear. Use your thumb to make small focus adjustments as needed. Take caution in not inserting the tip too deeply. 7. View the image on the screen of the smartphone. Use the on screen buttons to capture images, record video, zoom in and out, switch ears and finish the session.
- Page 9 In individuals with fluid draining from the outer ear canal, hearScope™ should be used with caution, with strict infection control protocols in place. hearScope™ should not be used for any purpose other than visually inspecting the outer ear canal and tympanic membrane.
-
Page 10: Safety Precautions
Do not use a single ear tip on more than one patient at a time. • Store the hearScope™ and its parts out of reach of infants, small children and pets. • Avoid exposing the device to any fluid and/or dust. -
Page 11: Storage And Handling
The device and ear tips should be disinfected prior to storage. Avoid exposing the device to any fluid and/or dust. Be careful not to touch the hearScope™ lens. DEVICE MAINTENANCE & CLEANING Before use, check the cables and connectors for signs of wear and/or damage. -
Page 12: Troubleshooting
Faults on the hearScope™ must be reported to the Manufacturer within 60 days of discovering the fault for the warranty to be applicable. This warranty is... -
Page 13: Technical Description
TECHNICAL DESCRIPTION Packaging as shipped (approximate) 200mm x 55mm Dimensions x 125mm Weight ± 220g hearScope™ body Dimensions 135mm x Ø11mm Weight ± 61g Ear Tip (speculum) Dimensions 72mm x Ø11mm Weight ± 2g Camera 2 MP CMOS LED, variable... - Page 14 SYMBOL GLOSSARY Manufacturer name and address Caution/Precaution. CE mark indicating conformity with Health and Safety requirements set out in European Directives. Not for general waste. Device is fragile Keep product dry Consult instructions for use...
