- Page 1 NW-2MP-D-WH NW-4MP-D-WH Dome Cameras Quick start guide Version 1.0.3...
-
Page 2: Table Of Contents
Table of Contents Introduction………………………………………………………………………………………………………..2 CCTV and the law…………………………………………………………………………………………………3 1. Camera description……………………………………………………………………………………..4 2. Camera installation.…………………………………………………………………………………….5 3. Adjusting camera settings...…………………………………………………………………………..6 4. Maintenance……………………………………………………………………………………….……..8 5. Support……………………………………………………………………………………………………9 6. Product compliance………………………………………………………………………………….….9 7. Specifications…………………………………………………………………………………………….9... -
Page 3: Introduction
100m, as this may affect voltage at the camera and long cable runs increase the risk of signal interference. If you need to extend the lines beyond what is supplied call NightWatcher support for further advice. •... -
Page 4: Cctv And The Law
The Data Protection Act (the ‘DPA’) Warning • Please use the standard accessories provided by manufacturer. Help is always at hand! If you have any doubts or problems with your product, contact NightWatcher support for FAQs, help advice. www.nightwatcher.co.uk What’s in the box 1. Camera 2. -
Page 5: Camera Description
1 Camera description All measurements in mm (inch). DC in cable Video output cable... -
Page 6: Camera Installation
Fixing ring Step 1 Install camera bracket. NW-2MP-D-WH and NW-4MP-D-WH ⚫ Unscrew the mounting bracket /camera pedestal at the base of the camera. This can now be used as a template to draw the marks onto the mounting surface before drilling the holes. Remember to thread the cable back through it before tightening the screws ⚫... -
Page 7: Adjusting Camera Settings
⚫ If mounting to stud-wall or similar surface you will need to use specialized expansion plugs for that surface. These are not provided in this kit but are available at all good DIY stores. ⚫ Mounting to false ceilings, ceiling tiles etc. also requires additional materials not provided in this kit. Typically, you would need to use a wooden backing board above the ceiling tile to bolster the ceiling tile and provide a strong surface to support the screws. - Page 8 In the live view screen, right-click anywhere on the screen. The shortcut menu is displayed. Click Main menu>Camera>Encode In this menu you can set the compression, resolution frame rate and bitrate etc. for each camera. Note that max. frame rate may be capped differently for certain channels. Resolution should be set automatically when the camera is detected.
- Page 9 Click Main menu>Camera>Image In this menu you will have the settings for all of the cameras connected to the DVR. To swap cameras pull down the options in channel. Don’t forget to press Apply to save all your changes every time you leave a screen. Viewing multiple cameras at once In the shortcut menu (above) select view 1 and from there select an individual camera or View 4 to get 4 camera views onscreen at the same time.
-
Page 10: Maintenance
5 Support If you have any problems with your installation, please first go to the NightWatcher web site to look at the FAQs. These are updated regularly and are laid out in product families so that they are very... -
Page 11: Product Compliance
Please don’t throw it away with unsorted waste, take it to your local recycling centre (Designated Collection Facility) to be recycled as Waste electrical and electronic product. Check with your local authority for addresses and other recycling advice. 7 Specifications NW-2MP-D-WH Technical Specification Camera Image Sensor 1/2.7"... - Page 12 Focus Control Close Focus Distance 600mm (23.62'') DORI Distance Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
- Page 13 Power Supply 12V DC ±25% Power Consumption Max 3.2W (12V DC, IR on) Environmental Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH * Start up should be done at above -40°C (-40°F) Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH Ingress Protection &...
- Page 14 2.8mm: 25m(83ft) Recognize 125px/m (38px/ft) 2.8mm: 13m(42ft) Identify 250px/m (76px/ft) 2.8mm: 6m(21ft) Pan / Tilt / Rotation Pan/Tilt/Rotation Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° Video Resolution 4MP (2560×1440) Frame Rate 25/30fps@4MP, 25/30fps@1080P, 25/30fps@720P Video Output 1-channel BNC high definition video output / CVBS video output (Can switch) Day/Night...
