Summary of Contents for Gold Medal Super Floss 3038EDX
- Page 1 Part No. 88761EX Revised Aug 2009 Super Floss Instruction Manual Model #3038EDX Cincinnati, OH 45241-4807 USA...
-
Page 3: Installation Instructions
It is Gold Medal Products Company’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety risks and the floss machine’s performance will be sacrificed/reduced. -
Page 4: Controls And Functions
Increases or decreases voltage percentage to the tubular wire heating element. Operating Instructions Gold Medal FLOSSUGAR is the preferred sugar for your new cotton candy machine. Our FLOSSUGAR comes in 8 flavors and can change colors for a large variety of combinations to achieve the best sales. - Page 5 Super Floss INSTALLATION OF FLOSS STABLIZER Whirl Grip Stabilizer Whirl Grip Clip Floss Pan p/n 55005 p/n 43030 p/n 42085 Model 3038EDX...
- Page 6 Super Floss MAKING FLOSS Pick a cone; if it sticks in the stack of cones, twist it off the stack. Hold an inch or two of the pointed end of the cone between two fingers and a thumb. With a light flicking action, roll cone in the web of floss building up in the pan.
-
Page 7: Shutdown Procedure
Super Floss FLOATER ADJUSTMENT In operation, the floss will collect on the FLOSS STABILIZER. If the floss collects “low” on the stabilizer, twist the front (leading) edge of the leather floaters down. You get more lift and the floss will collect higher. Form leather floaters as shown. - Page 8 Super Floss Model 3038EDX...
-
Page 9: Troubleshooting
Super Floss Troubleshooting Excessive Smoke 1. Check heat control setting. After warm up, equipment should make good floss at a reduced setting. Never let the machine operate with the heat so high it produces smoke or if you can smell burned sugar. -
Page 10: Ordering Spare Parts
3. Please include the machine’s model name, serial number, and date of manufacture (located on the machine nameplate) with your order. 4. Address all parts orders to: Parts Department Gold Medal Products Co. 10700 Medallion Drive Cincinnati, Ohio 45241-4807 (800) 543-0862... -
Page 11: Cabinet Assembly
Super Floss CABINET ASSEMBLY Spinner Head Complete Motor Inspection Cover p/n 43025EX p/n 42008NM Shipping Support Pan Support (Remove Before Use) p/n 42049 p/n 43025 Suspension Spring Control Knob p/n 20006 p/n 40793 Rubber Feet p/n 41282 Rubber Feet p/n 47155 Lighted Rocker Switch Digital Meter Cover Handle... - Page 12 Super Floss INSIDE CABINET AND SPINNER HEAD ASSEMBLY Relay Exhaust Blower p/n 55219EX p/n 48037 Terminal Block p/n 42006 Triac p/n 55155 Heat Sink p/n 48673 Note: All Circuit Breaker Heat Control Display 1000 Ohm Pot Assy. phenolic parts, p/n 48714EX p/n 55267EX p/n 55332 including stud...
- Page 13 Super Floss Inspection Cover and Floss Head Assembly (Spinner Head 43025EX) Brush Assembly p/n 42320 Motor Tension Spring p/n 48669EX p/n 2033 10-24 X 2 ¾ Cap Screw p/n 42199 Leather Floater p/n 20010 Spinner cap p/n 43424PMO Floss Band And Heater Assembly p/n 48785EX Model 3038EDX...
- Page 14 Super Floss ELECTRICAL SCHEMATIC EXPORT Model 3038EDX...
-
Page 15: Warranty
Super Floss WARRANTY WE WARRANT to the original purchaser the Gold Medal equipment sold by us to be free from defects in material or workmanship under normal use and service. Our obligation under this warranty shall be limited to the repair or replacement of any...
