- Page 1 SENSORS FOR FOOD AND BIOPHARMA. OPERATING MANUAL Continuous Level Sensor o NSL-F-00 o NSL-F-01 o NSL-F-02 NSL-F 30002 / 1.1 / 2015-04-16 / MU / EU...
-
Page 2: Table Of Contents
NSL-F Series Operating Manual Table of contents Table of contents ....................... 2 Conformity with standards ................3 Safety instructions ................... 3 Special features/advantages ................4 Options/accessories ..................4 Installation and connection ................4 Dimensions ....................14 Wiring diagram ....................17 Repair and maintenance ................. -
Page 3: Conformity With Standards
NSL-F Series Operating Manual Application/intended use Continuous level monitoring in metallic vessels up to 3m in height Ideal for highly adhesive and pasty media Filling level measurement of foamy media Hygienic use for float sensors ... -
Page 4: Special Features/Advantages
NSL-F Series Operating Manual Special features/advantages Installation in tanks and feed vessels from above, below and diagonally (types NSL-F-00 and NSL-F- Lateral installation in tanks by means of an angulated sensor and various clamping systems (type NSL-F-01) ... - Page 5 4...20-mA signal Filling level measurement Filling level height for 4/20-mA signal Filling level zero point/offset "Dry run" warning signal Filling level slope/gain "Failure" error signal Damping/filter “Underdriven/overdriven” signal limit Physical unit "Underflow/overflow"...
- Page 6 NSL-F Series Operating Manual The correlation between the table below and the software is as follows: MPI-200 software: e.g. 4-mA set value display on PC Node Value name Parameter name Signal interface X45a 4 mA setpoint Current loop signal Note:...
- Page 7 NSL-F Series Operating Manual 6.2 Setup using the MPI-200 programming adapter The software structure of the Simple User Interface is similar to that of the PC version. The system is operated using two control buttons to the left and right of the display. The button func-...
- Page 8 NSL-F Series Operating Manual (1) Briefly press the right button. (2) Press and hold the right button, and then select the desired mode (e.g. Setup) or node (e.g. Signal int), leaf through the menu with the right/left button and confirm the selection by pressing and holding the right but- ton.
- Page 9 Access/setup mode (must be set before Parameter/ the change is Node/ Search number Value name parameter name made) module (HTD number) Contrast user interface 2 Setup Display 451020 Backlight On/Off 2 Setup Display 451030 4-mA Setpoint 2 Setup Signal Int 330111 x45a I-Out 20-mA Setpoint...
- Page 10 NSL-F Series Operating Manual Example of setup of 4mA set value to 15mm above rod end: End / next Select Enter search Change Set Access search module / number (ID) parameter number node Node (19) Node (19) Signal Int NSL-F...
- Page 11 NSL-F Series Operating Manual Example of setup of 20mA set value to 60mm: End / next Select Enter search Change Set Access search module / number (ID) parameter number node Node (19) Node (19) Signal Int NSL-F X45a I-Out Signal Int 3.95 mA...
- Page 12 Example of changing mounting orientation from top to bottom: End / next Enter search Change Set Access search number (ID) parameter number Node (19) Node (19) Measure Node (19) Language Access ID-Search Mounting Language English 0 Monitor English Node (19) Measure Access ID-Search...
- Page 13 Example of changing contrast of the display: End / next Select Enter search Change Set Access search module / number (ID) parameter number node Node (19) Node (19) Display NSL-F Display Language Access ID-Search Contrast ID-Search Node English 0 Monitor Nein Display Node (19)
-
Page 14: Dimensions
NSL-F Series Operating Manual Dimensions Rod diameter øD The rod diameter depends 50…199 mm 6 mm on the length (EL) of the rod 200….1500/3000 mm 10 mm (see table). NSL-F-00 with vertical head NSL-F-00/…/S00/… with EL>200 mm NSL-F-00/…/S01/… with EL>200 mm... - Page 15 NSL-F Series Operating Manual NSL-F-00/…/S00/… with EL>200 mm NSL-F-00/…/S01/… with EL>200 mm NSL-F-00/…/Txx/… with EL>200 mm Type øA 50.5 mm 64.0 mm 77.5 mm 91.0 mm NSL-F-00 with horizontal head...
-
Page 16: Declaration Of Conformity
NSL-F Series Operating Manual NSL-F-01 The following figure only contains information on the rod design. The sizes of the head and process connection can be gathered from the drawings for NSL-F-00. Sensor rod: calculation of the total length EL = L1 + (ɑ/360° x 251) + L2... -
Page 17: Wiring Diagram
NSL-F Series Operating Manual Wiring diagram Electrical connection with M12 plug connection 1: Brown + Supply voltage 2: White + Output 4...20 mA 3: Blue - Output 4: Black - Supply voltage Electrical connection with cable gland Repair and maintenance The level sensor described here is maintenance-free and contains components that could be repaired. - Page 18 NSL-F Series Operating Manual Resolution Rod length >500 mm <0.1% of rod length Rod length <500 mm <0.5 mm Accuracy Media with conductivity <1% of rod length >50 µS/cm (beer, milk) Media with conductivity Depending on temperature, tank contour, <50 µS/cm...
- Page 19 NSL-F Series Operating Manual...
- Page 20 Negele Messtechnik GmbH | Raiffeisenweg 7 | 87743 Egg an der Guenz | Germany | Phone: +49 (0) 83 33 . 92 04 – 0 | Fax: +49 (0) 83 33 . 92 04 - 49 Anderson Instrument Company Inc. | 156 Auriesville Road | Fultonville, NY 12072 | Phone: 518-922-5315 | Fax: 518-922-8997...
