- Page 1 SENSORS FOR FOOD AND LIFESCIENCE. OPERATING MANUAL Continuous Level Sensor NSL-F 30002 / 2.0 / 2018-09-21 / YG / EU NSL-F...
-
Page 2: Table Of Contents
NSL-F Series Operating Manual Table of contents Table of contents ..................... 2 Application/intended use ................3 Conformity with standards ................3 Safety instructions ..................3 Special features/advantages ................. 4 Options/accessories ..................4 Installation and connection ................4 Installation of the „Large User Interface“ (LUI) ..........12 Dimensions .................... -
Page 3: Application/Intended Use
NSL-F Series Operating Manual Application/intended use • Continuous level monitoring in metallic vessels up to 3m in height • Ideal for highly adhesive and pasty media • Filling level measurement of foamy media • Hygienic use for float sensors •... -
Page 4: Special Features/Advantages
NSL-F Series Operating Manual Warranty coverage shall not be granted for any damage that can be attributed to improper exe- cution of work. Special features/advantages • Installation in tanks and feed vessels from above, below and diagonally (types NSL-F-00 and NSL-F-02) •... - Page 5 Filling level measurement 4...20-mA signal • Filling level zero point/offset • Filling level height for 4/20-mA signal • Filling level slope/gain • "Dry run" warning signal • Damping/filter • "Failure" error signal • Physical unit • “Underdrive/overdrive” signal limit • "Underflow/overflow"...
- Page 6 NSL-F Series Operating Manual The correlation between the table below and the software is as follows: MPI-200 software: e.g. 4-mA set value display on PC Node Value name Parameter name Signal interface X45a 4 mA setpoint Current loop signal Note:...
- Page 7 NSL-F Series Operating Manual Sensitivity Optimization Measure Dry Run D. Threshold Fine Tuning Measure Dry Run D. 6.2 Setup using the Simple-User- / Large-User-Interface The software structure of the Simple User Interface is similar to that of the PC version.
- Page 8 NSL-F Series Operating Manual (1) Briefly press the right button. (2) Press and hold the right button, and then select the desired mode (e.g. Quick-Setup, Setup), leaf through the menu with the right/left button and confirm the selection by pressing and holding the right button.
- Page 9 NSL-F Series Operating Manual For adjusting parameters directly in the sensor (see chapter 6.2 “Setup using the Simple-User- / Large- User-Interface”) you have to use the ID-codes from the table below. List of ID-codes: Parameter Possibility of adjust- Adjustable values / Units...
- Page 10 NSL-F Series Operating Manual LED1 D-Out Signal Sel 001 to 254 330034 Function State Src., Discrimin., Threshold 331111 Inp.Method Sw.Pnt + Hys, 2Pt MinMax 331131 Switch.Pnt -025.0 % to 125.0 % in 0.1er Steps 331141 Hysteresis 00.0 % to 50.0 % in 0.1er Steps...
- Page 11 NSL-F Series Operating Manual Parameter designation/signal curve mA or % 1: Error signal: Value underflow 2: Underdrive limit 3: 4-mA set value 4: 20-mA set value 5: Overdrive limit 6: Error signal: Value overflow Warning signal: no medium Sensor is not submerged in the Medium Signal can be set between 2.40 ...
-
Page 12: Installation Of The „Large User Interface" (Lui)
NSL-F Series Operating Manual Installation of the „Large User Interface“ (LUI) Remove the plastic cover (continue with step 4), or remove the puck with the mounted small dis- play (continue with step 2) Remove the small display Install the puck in the sensor head... - Page 13 NSL-F Series Operating Manual Attention: The connector of the programming adapter (Fig. 3) must be connected in the correct direc- tion the green spacer must face the cable exit (M12 connector or PG). Retrofitting the display if a small display (SUI) was already installed First the puck with the mounted display needs to be removed using the puck puller tool (Fig.
- Page 14 NSL-F Series Operating Manual...
-
Page 15: Dimensions
NSL-F Series Operating Manual Dimensions... - Page 16 NSL-F Series Operating Manual NSL-F-01 The following figure only contains information on the rod design. The sizes of the head and process con- nection can be gathered from the drawings for NSL-F-00. NSL-F-02 Except for the rod length of 200 mm up to max. 1500 mm, the NSL-F-02 is identical to the NSL-F-00.
- Page 17 NSL-F Series Operating Manual NSL-FR Remote Version...
-
Page 18: Wiring Diagram
NSL-F Series Operating Manual Wiring diagram Electrical connection with 4-PIN M12 plug connection, option “M” Anderson Negele 4-PIN Cordset “M” 1: Brown + Supply voltage 2: White + Output 4...20 mA 3: Blue - Output 4: Black - Supply voltage Electrical connection with 5-PIN M12 plug connection, option “L”... -
Page 19: Technical Data
NSL-F Series Operating Manual Technical data Rod length EL Product-contacting Max. 3000 mm (NSL-F-00) Max. 1500 mm (NSL-F-01 + NSL-F-02) Measurement range 50...199 mm (rod diameter 6 mm) 200...max. EL (rod diameter 10 mm) Process connection Thread CLEANadapt G ½", G1" hygienic Tri-Clamp 1.5", 2", 2.5", 3"... - Page 20 Negele Messtechnik GmbH | Raiffeisenweg 7 | 87743 Egg an der Guenz | Germany | Phone: +49 83 33 . 92 04 – 0 | Fax: +49 83 33 . 92 04 - 49 Anderson Instrument Company Inc. | 156 Auriesville Road | Fultonville, NY 12072 | Phone: +1 518-922-5315 | Fax: +1 518-922-8997...
