Robus R18WLED30-01 Instruction Manual

OYSTER 18W IP44 LED
FITTING, WHITE
R18WLED30-01, R18WLED40-01
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
! Electrical products can cause death or injury, or damage to property. If in any doubt about the installation or
use of this prodcut, consult a competent electrician
Product technical information and specification may change over time without prior notification. For the latest technical
information please visit our web site www.ledgrouprobus.com. au

Specifications

Model No.： R18WLED30-01
Voltage: 100-240V~50/60Hz
18W
Power:
Lumen: 1080lm
CCT: 3000K
CRI: 80
0.9
PF:
Beam Angle: 120
Ta Range: -15
IP Rating: IP44
Class I
Safety Class:
Diameter Ø327mm
Depth: 90mm
Weight: 0.6Kg
3 Year
Warranty:
Complie with: EN55015, EN61547, EN61000-3-2, EN 61000-3-3,
EN 60598-2-1, EN 60598-1, EN 62471, EN 62493
The Installation must be carried out by an electrician
LED Group ROBUS Australia
9/210 Queensport Road North
Murarrie
QLD 4172
Australia
Issue 1 140515
R18WLED40-01
100-240V~50/60Hz
18W
1200lm
4000K
80
0.9
o o
120
o o o
C < Ta < +40 C -15 C < Ta < +40
IP44
Class I
Ø327mm
90mm
0.6Kg
3 Year
Tel: +61 73893 1488
Fax: +61 73112 1927
Email: purchases@ledgrouprobus.com.au
Website: www.ledgrouprobus.com.au
Note:

Installation

1 Ensure mains supply is switched off before commencing
work
2 Remove diffuser by twist and lock arrangement
3 Mark appropriate fixing points on wall or ceiling; check
that fixings will not impinge on concealed cables of pipes
before drilling holes.
4 Introduce supply cables , insert the two screws into plugs
(do not screw fully tighten screw), place luminaire on
o
mounting surface, rotate luminaireand tighten screws.
C
5 Connect supply cable to terminal block: Brown to L, Blue
to N, Green/Yellow to E
6 Attached and rotate diffuser, ensure that it is secure
Instruction manual
ISO 9001:2008
Q UAL IT Y ASSU RE D CO MPANY
Page 1
