Crane Electronics Ltd
The force in torque management
Operators Manual
WRENCHSTAR MULTI
Manual 1230-01 Issue 1
Crane Electronics Ltd
NOTICE
ALL RIGHTS RESERVED. Reproduction of any part of this manual in any form whatsoever,
without the prior permission in writing from Crane Electronics Ltd is forbidden.
Copyright © by Crane Electronics Ltd
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wrenchstar Multi and is the answer not in the manual?

Questions and answers

Related Manuals for Crane Electronics Wrenchstar Multi

Summary of Contents for Crane Electronics Wrenchstar Multi

  • Page 1 Manual 1230-01 Issue 1 Crane Electronics Ltd NOTICE ALL RIGHTS RESERVED. Reproduction of any part of this manual in any form whatsoever, without the prior permission in writing from Crane Electronics Ltd is forbidden. Copyright © by Crane Electronics Ltd...

  • Page 2: Table Of Contents

    Packing List / Spares /Care Features and Dimensions / Overview WrenchStar Multi Specifications Main Functions and Features of WrenchStar Multi / Batteries Warnings / Battery Warnings Charging the WrenchStar Multi / WrenchStar Multi Button Diagnostic Mode / Power on Sequence...

  • Page 3: Ce Marking / Compliance

    Declares that this product has been assessed and complies with the requirements of the relevant CE Directives. Changes or modifications to the Changes or modifications to the WrenchStar Multi not expressly approved by Crane Electronics Ltd not expressly approved by Crane Electronics Ltd could void the user’s authority to operate the equipment.

  • Page 4: Product Disposal / About This Manual

    If you wish to discard this product, please contact your local authorities and ask for the correct way of disposal. ABOUT THIS MANUAL This manual covers the WrenchStar Multi communicating with an IQVu. For information on torque transducers or PC software to be used in conjunction with IQVu, please refer to Corresponding manuals accordingly.

  • Page 5: Packing List / Spares /Care

    Crane Electronics Ltd The force in torque management PACKING LIST The following items are supplied with the WrenchStar Multi dependant on model specification purchased. 1 x WrenchStar Multi 1 x User Manual (USB) 1 x Quick Start Guide (USB) 1 x Calibration Certificate Please ensure all items are present and notify Crane Electronics Ltd immediately of any shortages.

  • Page 6: Features And Dimensions / Overview Wrenchstar Multi

    The WrenchStar Multi contains its own power source which is a Lithium Ion battery pack. * The RF range depends on the environment in which the WrenchStar Multi and IQVu are being used and the figure quoted is for a relatively metal free work space with the IQVu in line of sight of the WrenchStar...

  • Page 7: Specifications

    The Wrench supplies its Torque Range (span), PPR (for angle), serial number, Calibration due date. Reading Storage: The WrenchStar Multi can store up to 200 readings in offline mode. LEDs: The WrenchStar Multi has a: Charge LED used when charging battery pack.

  • Page 8: Main Functions And Features Of Wrenchstar Multi / Batteries

    Serial number is on back. BATTERIES The WrenchStar Multi unit has a battery pack that contains a Lithium Ion battery. From fully discharged the unit will require up to a 4 hour charge to attain maximum capacity. The full capacity of the battery is 2600mAh which yields approx. 10 hours of normal use.

  • Page 9: Warnings / Battery Warnings

    WARNINGS Maintain unit with care. Keep unit clean for better and safer performance. Changes or modifications to the WrenchStar Multi not expressly approved by Crane Electronics Ltd could void the user’s authority to operate the equipment. Always operate WrenchStar Multi with approved battery pack.

  • Page 10: Charging The Wrenchstar Multi / Wrenchstar Multi Button

    If the WrenchStar Multi is ON and the button is held for more than 5s then the WrenchStar Multi will switch OFF. The WrenchStar Multi will switch OFF after 10 minutes of no activity. It can be turned back ON with a press of the button. No activity means no torque messages from the IQVu and no torque pulled.

  • Page 11: Diagnostic Mode / Power On Sequence

    Vibrator turning on and off 2 Tap Number of over torques and largest over torque 2 Tap Start POWER ON SEQUENCE The following information will be displayed when switch ON WrenchStar Multi: Crane logo s/w version 182-vx.x 161-vx.x Span in Nm Recal Date DD/MM/YY...

  • Page 12: Light Ring / Id Heads / Adapter Length Compensation

    The Crane 1-Touch Heads can be programmed with an ID from 1 through to 126, if there is no ID then the WrenchStar Multi will not use the ID system and treat the head as a standard insert head, with a critical compensation length of Zero.

  • Page 13: Battery Charge Status / Wrench Status Led / Vibrator

    • No LED = No charging source present and running off battery power. Battery Charge Status will be available even when the WrenchStar Multi is off. It will only be viewable when connected to a charging source. Wrench Status LED: WRENCH STATUS LED •...

  • Page 14: Iqvu Setup With A Wrenchstar Multi

    IQVu SETUP WITH A WRENCHSTAR MULTI IQVu SETUP WITH A WRENCHSTAR MULTI Before using an IQVu with the WrenchStar Multi with the WrenchStar Multi make sure the WrenchStar Multi is charged. charged. Turn the IQVu on. Press and release the Power Press and release the Power button on top of the IQVu.
  • Page 15 Crane Electronics Ltd The force in torque management After logging in the user is taken to the Home Page menu. To review more icons simply swipe across the screen and select ‘settings’. Use the right arrow to select ‘Settings: 4/9 Connection’.
  • Page 16 IQVu, then all previous pairings will stop working and a previously paired WrenchStar Multi previously paired WrenchStar Multi would need to be re-paired with the IQVu. paired with the IQVu. **The IQVu should be re-booted after set up of a new RF address and channel.

  • Page 17: Pairing The Wrenchstar Multi

    The force in torque management Press button for approx. 2s until the status LED changes to purple. The WrenchStar Multi is now ready to be paired. Place the WrenchStar Multi close to within 30cm of the IQVu as the pairing process occurs over a short distance.

  • Page 18: Loading Jobs

    Select ‘OK’ to return to the ‘Transducers’ screen. Select icon. LOADING JOBS Once the WrenchStar Multi is paired and selected, is paired and selected, you can enter a measurement screen either through surement screen either through ‘Check’ or ‘Jobs’ from the home screen ’...
  • Page 19 Job. When you enter the measurement screen, the job will be When you enter the measurement screen, the job will be transferred to the WrenchStar Multi transferred to the WrenchStar Multi. The WrenchStar Multi can store one subgroup of one job and up one subgroup of one job and up to 200 readings for that subgroup.
  • Page 20 Green = LSL < Value < USL Red (user should stop pulling if they see Red) = USL < Value If the Secondary value goes greater than its USL you will see a Red light on the WrenchStar Multi to warn the user to stop.
  • Page 21 Crane Electronics Ltd The force in torque management Peak plus Angle MoveOn Yield...
  • Page 22 Crane Electronics Ltd The force in torque management...
