- Page 1 DW-V-AXT VIDEO DOOR PHONE VIDEO DW-V-AXT DOOR PHONE www.denwaip.com...
-
Page 2: Table Of Contents
TABLE OF CONTENT Production Overview Production Description Features Configuration Web Login 1.1. Obtaining the IP address 1.2. Login the Web Status Language Network configuration Account Push Button Phone 7.1. Call Feature 7.2. Voice 7.3. Country Ringtone PhoneBook 8.1. Call Log Security 9.1. -
Page 3: Production Overview
Production Overview Production Description The Denwa DW-V-AXT is the video door phone, that you can connect with your Denwa IP Phones for remote unlock control and monitoring. You can operate the indoor handset to com- municate with visitors via voice and video, and unlock the door if you wish. It’s applicable in apartment, villas, Office, building and so on. -
Page 4: Features
Video resolution: 320 x 240, with 20pics per second · Wide angle lens and IR LEDs for night vision Crystal sound quality · Remote door opening · Integrated microphone and speaker · Water-proof outdoor unit: IP55 · Support all the VoIP Phones ·... -
Page 5: Configuration
If the IP address is unknown, press the call button when the door phone is initialing, after a short period of time, the phone will announce its IP. (The Denwa DW-V-AXT in old firmware, use a Static IP by default, and the default IP address is 192.168.1.100) 1.2. Login the Web Open a Web Browser, enter the corresponding IP address. -
Page 6: Status
Configuration Status Item Function Description Status, including product information, network information and Account information, can be viewed from, Status > Basic. Sections Description Product Information To display the device’s information such as Model name, MAC address (IP device’s physical address), Firmware version and Hardware firmware. -
Page 7: Language
Sections Description To display device’s Account information and Registration status (account username, registered server’s address, Account Information Register result). 3. Language Web Language can be configured from, Phone > Time/Lang. Select the desire language from the pull-down list of Type. The default language is English. 4. - Page 8 Sections Description LAN Port To display and configure LAN Port settings. · DHCP: If selected, IP phone will get IP address, Subnet Mask, Default Gateway and DNS server address from DHCP server automatically. · Static IP: If selected, you have to set IP address, Subnet Mask, Default Gateway and DNS server manually.
-
Page 9: Account
Sections Description To display and configure TR069 settings. TR069 · Active: To enable or disable TR069 feature. Version: To select supported TR069 version (version · 1.0 or 1.1). · ACS/CPE: ACS is short for Auto configuration servers as server side, CPE is short for Customer-premise equip- ment as client side devices. - Page 10 To configure your SIP account, go to Account > Basic. Sections Description To display and configure the specific Account settings. SIP Account · Status: To display register result. · Display Name: Which is sent to the other call party for displaying.
- Page 11 Sections Description To display and configure the specific Account settings. SIP Server 2 · Status: To display register result. · Display Name: Which is sent to the other call party for displaying. · Register Name: Allocated by SIP server provider, used for authentication.
- Page 12 Sections Description To display and configure available/unavailable codecs Codecs list. Codec means coder-decoder which is used to transfer analog signal to digital signal or vice versa. Familiar codecs are PCMU(G711U), PCMA(G711A), G722 (wid-bandth codecs), G723,G726,G729 and so To display and configure call-related features. Call ·...
-
Page 13: Push Button
Sections Description Encryption To enable or disabled SRTP feature. · Voice Encryption (SRTP): If enabled, all audio signal (technically speaking it’s RTP streams) will be encrypted for more security. To display NAT-related settings. · UDP Keep Alive message: If enabled, IP phone will send UDP keep-alive message periodically to router to keep NAT port alive. -
Page 14: Phone
Sections Description To configure the destination number you want to contact Encryption with. To select the desired DTMF Code DTMF Code Lock Reset To set the lock reset time Max Call Time To configure the max call time Push to Hang up To enable or disable the Push to Hang up function Phone 7.1. - Page 15 Sections Description To enable or disable Call Waiting. Call Waiting · Call Waiting Enable: If enabled, it allows IP phones to receive a new incoming call when there is already an active call. · Call Waiting Tone: If enabled, it allows IP phones to play the call waiting tone to the waiting callee.
-
Page 16: Voice
Sections Description · Return Code When Refuse: Allows user to assign spe- Others cific code as return code to SIP server when an incoming call is rejected. · Auto Answer Delay: To configure delay time before an incoming call is automatically answered. 7.2. - Page 17 Sections Description Echo Canceller Echo Canceller: To remove acoustic echo from a voice communication in order to improve the voice quality. · VAD (Voice Activity Detection): Allow IP phone to detect the presence or absence of human speech during a call. When detecting period of “silence”, VAD replaces that silence efficiently with special packets that indicate silen- ce is occurring.
-
Page 18: Country Ringtone
Sections Description Fixed: Add the fixed delay to voice packets. You can con- Call Waiting figure the delay time for the static jitter buffer on IP phones. Adaptive: Capable of adapting the changes in the network's delay. The range of the delay time for the dyna- mic jitter buffer added to packets can be also configured on IP phones. -
Page 19: Phonebook
PhoneBook 8.1. Call Log Sections Description To display call history records. Call History Available call history type are All calls, Dialed calls, Recei- ved calls, Missed calls, Forwarded calls. HangUp: To click to hangup ongoing call on the IP phone. Note: For “HangUp”... -
Page 20: Security
Security 9.1. Web Password Modify To modify web passoword, go to Security > Basic Sections Description To modify user’s password. Web Password Modify · Current Password: The current password you used. · New Password: Input new password you intend to use. ·... - Page 21 Sections Description To display or delete Certificate which is used when IP Server phone is connected from any incoming HTTPs request. Certificate Note: The default certificate could not be deleted. To upload a certificate file which will be used as server Web Server Certificate certificate.
-
Page 22: Upgrade
10. Upgrade 10.1. Basic upgrade To upgrade your device, go to Upgrade > Basic Sections Description To select upgrading rom file from local or a remote server Upgrade automatically. Note: Please make sure it’s right file format for right model. To display firmware version, firmware version starts with Firmware version MODEL name. -
Page 23: Advanced Upgrade
10.2. Advanced Upgrade To do the advanced upgrade for your device, go to Upgrade > Advanced. Sections Description To display and configure PNP setting for Auto Provisio- PNP Option ning. · PNP: Plug and Play, once PNP is enabled, the phone will send SIP subscription message to PNP server auto- matically to get Auto Provisioning server’s address. - Page 24 Sections Description To display and configure manual update server’s settings. Manual Update · URL: Auto provisioning server address. Server · User name: Configure if server needs an username to access, otherwise left blank. · Password: Configure if server needs a password to access, otherwise left blank.
- Page 25 Sections Description To display or configure others features from this page. Others Config file: To export or import configure file for IP phone. www.denwaip.com...
