Product Support Manual
Mini B300 ™ ILS
Emergency Position Indicating Radio Beacon
Product No. 2766.6
ETSI Type Approved to ETS 300 152
Y1-03-0167
Rev. B
ACR Electronics, Inc.
5757 Ravenswood Road
Fort Lauderdale, Fl 33312
Tel : +1(954) 981-3333
Fax: +1 (954) 983-5087
www.acrelectronics.com
Email: Info@acrelectronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini B300 2766.6 and is the answer not in the manual?

Questions and answers

Related Manuals for ACR Electronics Mini B300 2766.6

Summary of Contents for ACR Electronics Mini B300 2766.6

  • Page 1 Mini B300 ™ ILS Emergency Position Indicating Radio Beacon Product No. 2766.6 ETSI Type Approved to ETS 300 152 Y1-03-0167 Rev. B ACR Electronics, Inc. 5757 Ravenswood Road Fort Lauderdale, Fl 33312 Tel : +1(954) 981-3333 Fax: +1 (954) 983-5087 www.acrelectronics.com...
  • Page 2 * * * WARNING * * * THIS TRANSMITTER IS AUTHORIZED FOR USE ONLY DURING SITUATIONS OF GRAVE AND IMMINENT DANGER DELIBERATE MISUSE MAY INCUR A SEVERE PENALTY Y1-03-0167 Rev. B...
  • Page 3 (1) year from date of purchase or receipt as a gift. During the warranty period ACR Electronics, Inc. will repair or, at its option, replace at no cost to you for labor, materials or return transportation, provided you obtain a Return Authorization and the return shipping is prepaid to ACR Electronics, Inc., 5757 Ravenswood Road, Fort Lauderdale, FL 33312-...

  • Page 4: Table Of Contents

    PARA TITLE Figure 1 ACR Mini B SECTION 1 INTRODUCTION General Purpose Satellite Detection Authorizations Figure 2 Search and Rescue Satellite Aided Tracking (SARSAT) Characteristics Technical Data SECTION 2 INSTALLATION General SECTION 3 OPERATION General Manual Activation Deactivation Operational Notes SECTION 4 MAINTENANCE General...

  • Page 5: Figure

    FIGURE 1: MINI B 300 ILS H ON EPIRB Y1-03-0167 Rev. B...

  • Page 6: Satellite Detection

    SECTION 1 - INTRODUCTION GENERAL This manual provides installation, operation and maintenance instructions for the MINI B ILS Emergency Position Indicating Radio Beacon (EPIRB - Class B) hereinafter referred to as the Beacon. This section describes the characteristics and details of the Beacon (See Figure 1). You must add this device to your FCC ship station license if you have one.

  • Page 7: Characteristics

    FIGURE 2: SATELLITE DETECTION CHARACTERISTICS The MINI B ILS Beacon is an o-ring sealed battery operated unit. The beacon case, with its external antenna is waterproof. The semiconductor circuits are mounted within the case assembly, which also contains the battery power supply. An "ON-OFF"...

  • Page 8: Technical Data

    TECHNICAL DATA Pertinent technical data is listed below: ITEM Frequency Power Output Operating Life Battery Emission Modulation Frequency Stability Operating Temperatures Activation Size Weight Accessories (Optional) CHARACTERISTICS 121.5 MHz Minimum 75 mW during 24 hours operation 24 hours minimum at -10°, (-14°F) longer in temperate climates Lithium battery, 6V Duracell DL223A, (or equivalent) sold with beacon.

  • Page 9: Manual Activation

    SECTION 2 - INSTALLATION GENERAL The MINI B ILS Beacon has been designed for multi-purpose installation for survival use, personnel, rafts, floats and survival craft. It should be stowed on your persons, where it will be readily available in an emergency, or mounted where easily accessible with the optional MINI ILS Mounting Bracket (P/N 9321).

  • Page 10: Operation

    OPERATIONAL NOTES The EPIRB is designed to float on water but will operate best when held upright out of water. An operational transmission on land should be conducted in an area free of obstructions, which could absorb RF energy and limit radiation patterns. Position the antenna straight up and extend (perpendicular to ground) and not pointing toward the receiving station.

  • Page 11: Periodic Operational Check

    b. Remove old battery and place new battery in battery clip with groove side of battery down and flat side of battery up. Caution: Make sure flat side of battery is up. Otherwise, the polarity of the battery would be reversed and damage to the battery will occur. The battery also poses a possible fire, explosion, or burn hazard when placed in the battery clip upside down.

  • Page 12: Packaging & Transportation

    1. To ensure continued reliability, the unit should be checked for operation at least once every 90 (ninety) days, following the procedure of Section 5.2. 2. Do not use cleaners or petroleum distillates. PACKAGING AND TRANSPORTATION The MINI B ILS contains lithium batteries (solid cathode, total 3.4 grams lithium). The original shipping carton may be used or consult your local transportation authority with regard to applicable regulations for transporting the EPIRB.
  • Page 13 Y1-03-0167 Rev. B...
