Force Flow Heaters
U F
NIVERSAL ORCE FLOW
A standard trim which is used on any semi-
recessed or fully recessed model. Mounted
on sight to allow for infinite mounting depth
adjustment. Simply mark the depth location of
the desired reveal minus 1/2" for the trim
thickness and fasten the side bars centered
with the front edge on the line. (Figure 4
shows sides being mounted to a fully
recessed model wall mount)
The top and bottom bars have pocketed ends
to provide quick and easy alignment. The
protruding ends of the side bar (Figure 2 & 3)
fit snugly in the pockets and provides the
proper alignment for the top/bottom bar to be
fastened to the cabinet. For floor mount units
the bottom bar is not used and the sides are
fastened even with the bottom of the unit and
do not protrude. The collars have been
designed for this so no cutting is required on
the side bars. The top is mounted normally
and the extra protrusion of the side bar does
not affect the mounting.
F 4
IGURE
A V
SSEMBLY IEW
F R
ULLY ECESSED
U
NIT
Rev 3
Installation & Operation Manual
C
OLLARS
F
OR
www.sigmaproducts.com Tel: (905) 453-0446 Fax: (905) 453-0675
F 2
IGURE
S
IDES AND TOP
ALIGNED AND
READY TO BE
FITTED
F 3
IGURE
A
SSEMBLED SIDE
AND TOP
3
