Greiner Vibrograf Magnotest II Operating Manual

Magnotest II
The Instrument MAGNOTEST II measures the magnetism of an object and displays
the amount by means of red lights. The displayed amount is a relative value,
(strong, weak or not at all magnetic. )
Important : Due to the fact that magnetic fields are existing in many places, the
Magnotest II has to be adjusted in case not all red lights are off when
you first put it into operation the very first time.
Control and display :
Connector for
power - transformer
ø 3,5 mm
ON and OFF
switch
Ready light. Lights
up if Magnotest II
is switched on.
Adjust button.
For fine adjustment
of Magnotest II.
(Without an object)
turn the button
to switch off all
red lights.
Testpoint :
The object has to be
put onto this center
point for testing.
Adjust screw.
Only to be used for 1st
use (if necessary) or
change of workplace.
Greiner vibrograf A.G.
Weststrasse 69
4900 Langenthal
Tel. 0041 62 923 44 33
Fax. 0041 62 923 18 46
Operating Manual
MAGNOTEST
Greiner vibrograf
MAGNETISM
ON HIGH
MEDIUM
1/4
LOW
ADJUST
Change of batteries:
Change of batteries:
The batterie box is situated at
The batterie box is situated at
the rear of the Magnotest II.
the rear of the Magnotest II.
- Check polarity -
- Check polarity -
page 1
II
Press and
it will divide
the reading
by 4.
Use when
object has
strong
magnetic
reading
