INSTALLATION, OPERATING
AND MAINTENANCE MANUAL
In accordance with PED
SELF-ACTING DIAPHRAGM VALVES
2.0 NOTES ON POSSIBLE DANGERS..........................2
2.1 Signifi cance of symbols ..........................................2
4.0 DESCRIPTION...........................................................2
4.2 Area of Application...................................................3
4.3 Technical data - remarks.........................................3
4.4 Marking/nameplate...................................................3
Series MAXOMATIC VMXBXERL24C
Contents
5.0 INSTALLATION.............................................................3
5.1 General remarks on installation...................................3
5.2 Assembling additional modules...................................4
6.0 COMMISSIONING.........................................................5
7.0 CARE AND MAINTENANCE.........................................6
8.0 TROUBLESHOOTING...................................................7
9.0 TROUBLESHOOTING TABLE......................................7
11.0 WARRANTY / GUARANTEE......................................8
12.0 LAYOUT AND PARTS LIST.........................................9
