Figure 6: Laying Out And Connecting The Guy Ropes To The - Codan 3048 Installation Handbook

I
NSTALLING THE ANTENNA
I
NSTALLING THE ANTENNA
1
1
Figure 6:
anchor
point
1
1
1
1
22
Tighten the nut
Align the mast so that it lays alongside the star dropper or
anchor point in the installation area.
Laying out and connecting the guy ropes to the
anchor points
anchor
point
erection pole
mast
anchor
point
Rotate both guy assemblies so that one guy rope on each is
facing down.
Loop the guys that are between the ground and the mast
back to the star dropper or anchor point that is alongside the
mast.
Terminate the end of each guy through the thimble on a
turnbuckle and secure with two rope grips, allowing 1 m of
free tail.
Screw each turnbuckle to the centre of its adjustment range.
3048 T
TBD how tight does it have to be?
D A
UNED IPOLE NTENNA
anchor
point
I H
NSTALLATION ANDBOOK
