- Page 1 RADIO COMMUNICATIONS 3048 Tuned Dipole Antenna Still waiting for the model from Lencom Installation Handbook...
- Page 2 Codan Limited. © Copyright 2013 Codan Limited. Codan part number 15-04185-EN Issue 1, October 2013. CODAN™, Envoy™, Easitalk™, and CALM™ are trademarks of Codan Limited. Other brand, product, and company names mentioned in this document are trademarks or registered trademarks of their respective holders.
-
Page 3: Table Of Contents
Installing the head unit and dipoles ... . 25 Raising the mast ..... 28 3048 T UNED... - Page 4 Unit multipliers ......42 About this issue ..... . . 42 Index 3048 T UNED IPOLE...
- Page 5 ......26 Figure 9: Inner, centre and outer dipole elements ... 27 3048 T UNED IPOLE...
- Page 6 IST OF FIGURES This page has been left blank intentionally. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
-
Page 7: List Of Tables
Pinouts for the antenna control connector ..5 Table 2: Contents of the antenna pack ....8 3048 T UNED IPOLE... - Page 8 IST OF TABLES This page has been left blank intentionally. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
-
Page 9: Introduction
There is an index at the end of this handbook to assist you in finding information. This handbook is for installers of the 3048 Tuned Dipole Antenna. It assumes that you have experience in installing RF equipment. This handbook contains the following sections: Overview—provides an overview of the antenna and connectors... - Page 10 NTRODUCTION This page has been left blank intentionally. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
- Page 11 Overview This section contains the following topics: • General on page 4 • Connectors on page 5 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
-
Page 12: Overview
The 3048 Tuned Dipole Antenna is compatible with any Codan HF transceiver that can control a Codan 3042/3046 Antenna Tuner or 3040/9350 Automatic Tuning Whip Antenna. -
Page 13: Connectors
VERVIEW ONNECTORS Connectors Antenna control connector The antenna control connector passes control signals between the Codan HF transceiver and the antenna tuner. Figure 1: Front view of the antenna control connector Table 1: Pinouts for the antenna control connector Pin no. -
Page 14: Rf Connector
RF output terminal The RF output terminal passes RF signals between the antenna and the antenna tuner. Earth stud The earth stud is used to connect the antenna tuner to earth. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 15: Installing The Antenna
Installing the antenna This section contains the following topics: • General on page 8 • Installing the antenna on page 17 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 16: General
If anything is missing or damaged, please contact your nearest Codan office immediately to obtain the correct warranty service procedures. This ensures prompt assistance, minimal turnaround time, and avoids any freight issues. - Page 17 Guy assembly, top (marked 2) Guy assembly, bottom (marked 1) Plastic bag D-shackle Turnbuckle (thimble fitted) M12 x 90 bolt M12 flat washer M12 spring washer M12 nut M8 x 65 bolt M8 flat washer 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
- Page 18 Miscellaneous Wire rope grip Interface unit, with captive 7 m RF and control cables Hub tube and 3048 Tuned Dipole Antenna head unit, with fitted 8 mm galvanised bolt, nut and washers 8 mm hex head nut driver 3048 Tuned Dipole Antenna Installation Handbook...
-
Page 19: Required Tools
The mast and antenna require a certain amount of clear ground during installation, as shown in Figure 2. The base plate for the mast must be oriented correctly to allow the mast to lay on the ground during installation, as shown in Figure 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 20: Figure 2: Footprint Of The Antenna
NSTALLING THE ANTENNA ENERAL Figure 2: Footprint of the antenna anchor point guy ropes mast anchor point anchor point anchor point installation footprint installed footprint 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 21: Typical Layout
13 mm 13 mm (0.5 in) (0.5 in) 220 mm (8.7 in) 270 mm (10.6 in) Typical layout TBD need the model from Lencom. show critical distances between interface unit and transceiver 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 22: Locating The Antenna
An earth plane should be used to provide adequate earthing of the antenna. An earth mat for an antenna mounted on open ground can be supplied by Codan (Codan part number 15-00158). 3048 T... - Page 23 Usually, a counterpoise system is used to provide an efficient earth plane. A radial earth plane for an antenna mounted on the roof-top of a building can be supplied by Codan (Codan part number 15-00159). If an earth plane, such as a counterpoise, cannot be provided for the antenna, an earth wire connected to a suitable earth stake can be used, but with reduced efficiency.
-
Page 24: Cabling
Such holes need only be large enough to allow the end of the cable with the smaller connector to pass through. Removing a connector should be a last resort. Externally, the cable and connectors need to be weatherproofed using self-amalgamating rubber tape. 3048 T UNED IPOLE NTENNA NSTALLATION... -
Page 25: Installing The Antenna
Installation flowchart This flowchart provides a recommended sequence of tasks that describe how to install the 3048 Tuned Dipole Antenna with the 6 m mast that has been designed specifically for this tuner and antenna. NOTE: Interface specifications are provided if you are installing the tuner and antenna on your own mast. -
Page 26: Figure 4: Installation Flowchart
NSTALLING THE ANTENNA NSTALLING THE ANTENNA Figure 4: Installation flowchart 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 27: Installing The Mast
In a rooftop installation, attach an anchor point to the roof using appropriate fasteners. Provide three more anchor points at 90° intervals on the 4 m radius from the centre of the base plate. 3048 T UNED IPOLE NTENNA NSTALLATION... - Page 28 Slide guy assembly 1 over the end of the bottom section of the mast. Slide guy assembly 2 over the end of the top section of the mast. Apply Alminox to the outer end of the bottom section of the mast. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
-
Page 29: Figure 5: Preparing And Connecting The Bottom And Top
Place an M8 flat washer onto the M8 bolt, then thread this through the holes on either side of the mast. Place an M8 flat washer, M8 spring washer, then M8 nut onto the M8 bolt. 3048 T UNED IPOLE NTENNA... -
Page 30: Figure 6: Laying Out And Connecting The Guy Ropes To The
Terminate the end of each guy through the thimble on a turnbuckle and secure with two rope grips, allowing 1 m of free tail. Screw each turnbuckle to the centre of its adjustment range. 3048 T UNED IPOLE NTENNA NSTALLATION... -
Page 31: Figure 7: Connecting The Guy Ropes To The Erection Pole
Figure 7: Connecting the guy ropes to the erection pole D-shackle rope grip erection pole mast Related links: Locating the antenna on page 14 Footprint of the antenna on page 11 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 32: Installing The Interface Unit
TBD include a picture of the installed and earthed interface unit Secure the copper strip to the earth point using the fastener. Roll out the coaxial cable to the top of the mast. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 33: Installing The Head Unit And Dipoles
Remove the M8 bolt, washers and nut from the hub tube of the head unit. Apply Alminox to the outer end of the top section of the mast. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 34: Figure 8: Preparing And Connecting The Top Section Of The Mast And The Hub Tube
M8 bolt, washers and nuts provided. TBD insert picture of the head unit in the installation orientation. show all of the important callouts...strain relief, RF and control connectors, insulator horns 3048 T UNED IPOLE NTENNA NSTALLATION... -
Page 35: Figure 9: Inner, Centre And Outer Dipole Elements
Slide each outer dipole element into a centre dipole element and secure with the compression clamp from the outer dipole element. Apply Alminox conductive grease to the four insulator horns on the hub tube. 3048 T UNED IPOLE NTENNA NSTALLATION... -
Page 36: Raising The Mast
Use a spirit level to check that the mast is vertical, adjusting the guys using the turnbuckle as required to remove slack. Tighten the bolt at the base of the mast..TBD how do you rotate it then to the desired direction of communication? 3048 T UNED IPOLE NTENNA NSTALLATION... -
Page 37: Connecting The Cables From The Interface Unit To The Transceiver
Remove the dust cap from the Power I/P connector. • Connect the external DC power cable. • Seal the connector using self-amalgamating tape. • Connect the bare wires to an appropriate DC power source. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... - Page 38 NSTALLING THE ANTENNA NSTALLING THE ANTENNA This page has been left blank intentionally. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
-
Page 39: Specifications
Specifications This section contains the following topics: • Specifications on page 32 • Interface requirements on page 33 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 40: Specifications
PECIFICATIONS PECIFICATIONS Specifications 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 41: Interface Requirements
PECIFICATIONS NTERFACE REQUIREMENTS Interface requirements 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... - Page 42 PECIFICATIONS NTERFACE REQUIREMENTS 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
- Page 43 Accessories 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
- Page 44 CCESSORIES 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
- Page 45 Compliance This section contains the following topics: • Overview on page 38 • EMC and safety notices on page 38 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK...
-
Page 46: Overview
OMPLIANCE VERVIEW Overview This section describes how to ensure the 3048 Tuned Dipole Antenna complies wi the European R&TTE Directive 1999/5/EC. EMC and safety notices Non-ionising radiation safety To ensure optimal transceiver performance and to avoid exposure to excessive electromagnetic fields, the antenna system must be installed according to the instructions provided. -
Page 47: Standards And Icons
CAUTION: proceed with caution as your actions may lead to loss of data, privacy or signal quality WARNING: your actions may cause harm to yourself or the equipment 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 48: Acronyms And Abbreviations
ETSI European Telecommunications Standards Institute high frequency ICNIRP International Commission on Non-Ionizing Radiation Protection R&TTE radio and telecommunications terminal equipment radio frequency VSWR voltage standing wave ratio 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 49: Units
American wire gauge Capacitance farad Current Frequency hertz Impedance Ω Length metre (inch/feet/yard/mile) (in/ft/yd/mi) Power watt Power ratio decibel Temperature degrees Celsius °C (Fahrenheit) (°F) Time second hour Voltage volt Weight gram (pound) (lb) 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... -
Page 50: Unit Multipliers
Unit Name Multiplier mega 1000000 kilo 1000 milli 0.001 μ micro 0.000001 nano 0.000000001 About this issue This is the first issue of the 3048 Tuned Dipole Antenna Installation Handbook. 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK... - Page 51 RF connector 6 earth stud 6 RF output terminal 6 RF 6 RF output terminal 6 dipole elements installing 25 earth stud 6 head unit installing 25 installation flowchart 17 general 8 3048 T UNED IPOLE NTENNA NSTALLATION ANDBOOK NDEX...
