WES 1000& 2000 – Installation and Hardware Guide Contact Information Helios Global Technologies 1920 Windsor Rd Kelowna BC V1Y 4R5 Website: http://www.heliosglobaltech.com Warranty Information and Technical Support Please inquire with the distributor of your W.E.S. system for any warranty and technical support related issue.
WES 1000& 2000 – Installation and Hardware Guide Contents Contact Information ............................2 Preface ................................3 Purpose ..............................3 Product Overview ..........................3 W.E.S Series ........................... 3 Standard Equipment/Components ....................3 1.2.1 W.E.S Base ..........................4 1.2.2 Signaling transmitter ......................4 Installation ............................
Page 4
WES 1000& 2000 – Installation and Hardware Guide Radio Transceiver ..........................9 Documentation Version ........................10 V 1.3...
1 Product Overview 1.1 W.E.S Series The Helios W.E.S. is a supplemental emergency stop system allowing workers to stop machinery and equipment using a personally carried transmitter. The WES system enables a worker or supervisor to open a relay that can be used to immediately disconnect the power to equipment from where the individual is located or from the unit by activating the stop button.
WES 1000& 2000 – Installation and Hardware Guide 1.2.1 W.E.S Base The W.E.S. base is a polycarbonate enclosure housing status lights, stop button, reset button antenna and mounting points. Internally there is a user replaceable 250V 15A Fuse 1.2.2 Signaling transmitter The signaling transmitter may be one of a handful of transmitters designed for functionality in different environments.
WES 1000& 2000 – Installation and Hardware Guide Fig 2.1 Mounting Flange 2.2.3 Conduit The enclosure has two holes in the bottom to accommodate ¾ conduit fitting. The specific fitting must be appropriate for the environment and location the W.E.S system will be operating in. Installer to determine correct conduit (RMC, GRC, PVC, LFMC, etc…).
WES 1000& 2000 – Installation and Hardware Guide 2.3 Wiring Each E-Stop is labeled on the bottom of the enclosure with the correct input power required to operate the unit. Eg: Fig 2.3 DC Voltage E-Stop Fig 2.4 AC Voltage E-Stop Layout inside a DC voltage 1000 W.E.S.
WES 1000& 2000 – Installation and Hardware Guide Layout inside an AC voltage W.E.S. 2000 Enclosure Fig 2.6- Shown: Internal components W.E.S 2000 AC 2.3.1 Power 2.3.1.1 Supply DC Voltage W.E.S Unit DC 11-30Vdc is to be wired to the terminal block in the bottom right of the enclosure and then secured using a locking tie strap.
WES 1000& 2000 – Installation and Hardware Guide Terminal Block for line voltage is labeled “LINE” and “NEUTRAL”, fix the matching wires under the terminal screws and secure with the screws. Terminal Blocks may also be IN1(+DC/L) & IN2(-DC/L) IN1: Line IN2: Neutral Two ground screws are provided on the right side on the aluminum plate to secure the ground wire.
WES 1000& 2000 – Installation and Hardware Guide 4.2 Removal Removal procedure is reverse of installation with the exception that the cable ties holding the cables will have to be cut and replaced. Specifications 5.1 W.E.S. Base station 1000 Electrical W.E.S 1000 DC version Line Supply Voltage 11-30Vdc...
Page 12
WES 1000& 2000 – Installation and Hardware Guide spread spectrum) Documentation Version Version Date Details April 1, 2015 Initial Document Release April 16, 2015 Minor Updates/Fixes July 17, 2015 Updates to include 1000 and DC specification August 13, 2015 Photos and wiring updates for 1000 and DC version V 1.3...
