- Page 1 RZ2 BioAmp Processor Operator’s Manual...
- Page 2 RZ2 BioAmp Processor Operator’s Manual Copyright © 2008-2013 Tucker-Davis Technologies, Inc. (TDT). All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the express written permission of TDT.
-
Page 3: Power Supply
The RZ2 device chassis houses an integrated zBUS communication interface and power source. Power Supply The RZ2’s power supply is integrated into the device and is shipped from the factory with the desired voltage setting (115 V or 230V) preset. If you need to change the voltage settings for... - Page 4 This manual provides the directions necessary for powering the RZ2 High Performance Processor on and off as well as its communications functionality and User Interface features. Refer to the System 3 Manual provided by TDT for specific instructions on how to program the RZ2 Processor device.
- Page 5 Connecting the RZ2 Interface to your PC Before connections can be made from the RZ2 to your PC, the PCI interface card must be installed inside your PC. For more information refer to Installing the Optibit Interface in the System 3 Installation Guide.
- Page 6 When connecting the RZ2 to any PZ Preamplifier, ensure that the wires are inserted correctly. The RED label on the back of the RZ2 denotes the input for the red colored fiber optic wire. Similarly, another label titled RED is shown on the back of the PZ Preamplifier.
-
Page 7: Safety Notices
➢ Do not attempt to disassemble the power supply or chassis by removing any of the exterior housing of the RZ2. If you experience any issues, contact TDT support immediately. - Page 8 Cleaning the RZ2 Processor Device To clean the device: Remove power from the RZ2 device chassis. Clean the external surfaces and LCD screen of the device with a soft, dry cloth. Do not attempt to disassemble and clean the inside of the device.
- Page 9 RZ2 BioAmp Processor Operator’s Manual RZ2 Technical Specifications Technical specifications for the RZ2 Processor Device. Refer to the RZ2 Technical Specifications in the System 3 Manual for more information. Chassis Height 3U Width Standard 19’’ rack mount Power Supply (Integrated)
