Marshall Excelsior ME980-905 Installation Instructions

Advertisement

READ AND UNDERSTAND ALL INSTRUCTIONS INCLUDED WITH THIS INSTRUCTION
Lanyard
ME980C-6, -8
NOT INCLUDED
WARNING!
Failure to follow these instructions or to properly
install and maintain this equipment could result in
an explosion and/or fire causing property damage
and personal injury or death.
Marshall Excelsior equipment must be installed,
operated, and maintained in accordance with
federal, state, and local codes and MEC
The contents of this publication are for informational purposes only. While every effort has been made to ensure accuracy,
these contents are not to be construed as warranties or guarantees, expressed or implied, regarding the products or services
described herein or for their use or applicability. Marshall Excelsior Co. reserves the right to modify or improve the designs
or specifications of such products at any time without notice. The MEC™ logo is the trademark of Marshall Excelsior Co.
Form #921
Installation Instructions
For:ME980-905, ME980-905-25
and ME980-905-50
MANUAL. RELIEVE ALL PRESSURE FROM SYSTEM BEFORE SERVICING VALVE
Latch End
Figure 1
Marshall Excelsior Company
1506 George Brown Drive Marshall, MI 49068
Phone (269) 789-6700 Fax (269) 781-8340
www.marshallexcelsior.com
!!!WARNING!!!
Remote Release End
instructions. The installation in most states must
also comply with NFPA 58 or ANSI K61.1 standards.
Only personnel trained in the proper procedures,
codes, standards, and regulations of the LP-Gas or
anhydrous ammonia industries should install and
service this equipment
Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ME980-905 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marshall Excelsior ME980-905

  • Page 1 Marshall Excelsior Co. reserves the right to modify or improve the designs or specifications of such products at any time without notice. The MEC™ logo is the trademark of Marshall Excelsior Co.
  • Page 2 Valve Body Latch Pin Latch Body Jam Nut Cable Fitting Cable Guide Plunger Spring Plunger Figure 2 CABLE RELEASE CONNECTIONS Run the inner cable and housing assembly WARNING! to the remote release point. Leave enough slack on each end for a smooth, flowing Remote release cables shall be installed so that path, without sharp bends in the cable, they will close the ME980 valve(s) when pulled...
  • Page 3 Remote Release Release Bracket Figure 4 WARNING! Install the plunger, spring and guide into All open ME980 emergency valve(s) attached to the latch body and TIGHTEN SECURELY. remote release must properly close when the Align the slot in the plunger, insert the latch release cable is pulled.
