- Page 1 Replacement Instructions WPLLD Transducer Replacement Instructions Manual Number 577013-710, Revision A VEEDER-ROOT Environmental Products...
- Page 2 Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this publication.
-
Page 3: Table Of Contents
Warnings and Important Notes ..............2 Damage Claims ..................... 2 Replacing The WPLLD Sensor Checking the Functional Element Orifice (For Red Jacket Pumps) ................. 3 WPLLD Sensor Removal ................. 4 WPLLD Sensor Installation ..............4 Checking STPs for leaks ................6... - Page 4 Contents Figures Figure 1. Disabling the Functional Element ........... Figure 2. Connecting WPLLD Sensor To Pump ........
-
Page 5: Introduction
Introduction This manual covers Transducer Replacement Instructions for Veeder-Root Wireless Pressurized Line Leak Detection (WPLLD) Systems. Safety Symbols The following safety symbols may be used throughout this manual to alert you to important safety hazards and precautions. Explosive Fuels and their vapors are extremely explosive if ignited. -
Page 6: Warnings And Important Notes
4. Do not use this component for other systems aside from the WPLLD. Install console only as described in this manual. 5. The WPLLD must be installed and operated in an indoor location. Damage Claims Thoroughly examine all components and units as soon as received. If damaged, write a complete and detailed description of the damage on the face of the freight bill. -
Page 7: Replacing The Wplld Sensor
1. Read and understand all instructions. 2. Turn OFF power to the console and submersible pumps during installation. 3. Use only Veeder-Root supplied service parts to avoid compromising safety. 4. Wiring must comply with all applicable requirements of the National Electrical Code; federal, state, and local codes; and any other safety codes. -
Page 8: Wplld Sensor Removal
Ensure power to the STP is turned OFF. Disconnect the sensing line from the WPLLD sensor. Remove the capacitor cover bracket from the WPLLD sensor and set it (and pump capacitor cover) aside for reinstallation. Unscrew the WPLLD sensor from the pump. - Page 9 (WPLLD sensors are equipped with a vent screw to equalize internal pressure.) Retighten the vent screw securely to prevent water from entering. (Failure to release internal pressure in the WPLLD sensor at altitudes above 2,000 feet could cause inaccurate pressure readings and false line leak alarms.)
-
Page 10: Checking Stps For Leaks
Guide the two wires from the WPLLD sensor into the notch on the shield, leaving as much slack in the wires as possible above the shield (this will prevent stressing them when the WPLLD sensor is threaded into the pump). - Page 12 Sales Offices Veeder-Root has offices around the world to serve you. Headquarters Veeder-Root Company 125 Powder Forest Drive Simsbury, CT 06070-7684 U.S.A. (860) 651-2700 FAX: (860) 651-2719 England Veeder-Root Environmental Systems Limited Hydrex House, Garden Road Richmond, Surrey TW9 4NR ENGLAND...
