- Page 1 Manual Product Description : Wireless Kitchen Thermometer Customer Name : Maverick Customer Model No. : XR-40, RT-40 Revision History : 2017/12/07 – Change customer model no. and add required FCC & CE Statements XR-40 Manual.docx Page 1 of 12 06-Feb-18...
- Page 2 Battery Low indication: LCD displays “Lo” on most right two digits for 2 seconds and probe temperature reading (3 seconds each)alternatively when the battery low level is detected.E.g. T1(if any) → “Lo” → T2(if any) → “Lo”and then repeat. XR-40 Manual.docx Page 2 of 12 06-Feb-18...
- Page 3 Temperature measurement range:32° Fto 572° F (0˚Cto +300˚C). i. If temperature below 32˚F (0˚C), “LLL” will be displayed. ii. If temperature above 572˚F (300˚C), “HHH” will be displayed. Temperature reading resolution: 1° F (1˚C) XR-40 Manual.docx Page 3 of 12 06-Feb-18...
- Page 4 Storage Environments: Temperature = 14 to140 ° F (-10to60° C) Relative Humidity = 15 to 95% Product dimension (L x W x H mm) = 128x 65 x 34 (without hanger) XR-40 Manual.docx Page 4 of 12 06-Feb-18...
- Page 5 The layout of LCD full segments are shown as below: Mode Probe No. Food Name Food Taste Cyclic Probe Battery Low indication Probe 1 temperature reading & setting Probe 2 temperature reading & setting XR-40 Manual.docx Page 5 of 12 06-Feb-18...
-
Page 6: Power On/Off
In high visibility mode: short press [Light] button the LCD backlit shall be kept ON until power OFF or short press [Light] button again. Unit shall return to normal mode after power OFF. XR-40 Manual.docx Page 6 of 12 06-Feb-18... - Page 7 In Setting Mode, long press 2 seconds of this key any time to confirm the setting of current parameter and the device will exit the Setting Mode. 3. Power: DC 3V (2 x AAA size Battery) XR-40 Manual.docx Page 7 of 12 06-Feb-18...
- Page 8 Pre-alert - If probe temperature higher than set temperature minus 10˚F, pre-alert sound will active (if ALERT enabled), the alert icon will flash. Short press any key to stop alert sound & alert icon stop flashing. XR-40 Manual.docx Page 8 of 12 06-Feb-18...
- Page 9 2 pieces AAA are used for each of the receiver and transmitter, included in the packaging Two 3 feet hybrid probes measure food or barbecue temperatures. 2pcs of clip for probe to attach to grill rack. User manual. D. Type approval XR-40 Manual.docx Page 9 of 12 06-Feb-18...
- Page 10 2) Keep the stainless steel probe sensors and wires away from children. 3) Wash the metal probe tips with hot soapy water and dry thoroughly. Do not immerse the probe in water while cleaning. XR-40 Manual.docx Page 10 of 12 06-Feb-18...
-
Page 11: Limited Ninety Day Warranty
LIMITED NINETY DAY WARRANTY Maverick Industries Inc. warrants the XR-40MAVERICK Barbecue Thermometer to be free of defects in parts, materials and workmanship for a period of 90 days, from date of purchase. Should any repairs or... - Page 12 This warranty is VOID if instructions for use are not followed; for accidental damage; for commercial use; for damage incurred while in transit; or if the XR-40 MAVERICK Barbecue Thermometer has been tampered with. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
