Integrated Power Designs REL-110 SERIES Operating Instructions

INTEGRATED
POWER DESIGNS
INPUT RATING: 100-240VAC, 2 A, 50-60 Hz.
OUTPUT RATING: 110 Watts Maximum Total Continuous Output Power with 300 LFM Forced Air.
80 Watts Maximum Total Continuous Output Power Convection Cooled.
65 Watts Maximum Total Continuous Output Power Convection Cooled with Chassis and Cover.
Model
MODEL LISTING:
REL-110-4001
REL-110-4002
REL-110-4003
REL-110-4004
REL-110-4005
REL-110-4006
REL-110-4007
REL-110-4009
REL-110-4010
REL-110-4011
REL-110-4012
REL-110-3001
REL-110-3002
REL-110-3003
REL-110-3004
REL-110-3005
REL-110-3006
REL-110-3007
REL-110-2001
REL-110-2002
REL-110-2003
REL-110-2004
REL-110-2005
REL-110-2006
REL-110-2007
REL-110-1001
REL-110-1002
REL-110-1003
REL-110-1004
REL-110-1005
REL-110-1006
REL-110-1007
REL-110-1008
NOTES: 1. Total current from Outputs 1 and 2 must not exceed 12 Amps with convection cooling.
2. Total current from Outputs 3 and 4 must not exceed 3 Amps with convection cooling.
3. Rated 8 Amps maximum with convection cooling.
4. Rated 16 Amps maximum with convection cooling.
5. A suffix may be added to the model number to indicate the following optional configurations:
(CH-chassis, CO-cover, IO-isolated outputs, TS-terminal strip).
6. Approved to UL/CSA 60950-1 only.
7. Approved to EN 60950-1 only.
Manufacturer: Integrated Power Designs, Inc.
Manufacturer's Address: 300 Stewart Road, Wilkes-Barre, PA 18706 USA
Declares all models listed above including all options are in compliance with the following European Community Directives:
In addition, all models are Certified to be in compliance with applicable requirements of UL 60950-1:2007, ANSI/AAMI ES60601:2005/(R) 2012, IEC
60950-1/A2:2013 and IEC 60601-1:2005/A1:2012 including all EU national deviations, CAN/CSA-C22.2 No. 60950-1-07, CAN/CSA- C22.2 No. 60601-
1:2014, EN 60950-1:2006/A2:2013 and EN 60601-1:2006/A1:2013.
Steven Thompson- President
BY:
PLACE: Integrated Power Designs
300 Stewart Road, Wilkes-Barre, PA 18706 USA
DATE: January 3, 2017
DRAWING NO: 1080018
REVISION: 33
300 Stewart Road
Wilkes-Barre, PA 18706 USA
Phone: (570) 824-4666
REL-110 SERIES OPERATING INSTRUCTIONS
Output 1
(1)
+3.3VDC/10A
+5VDC/10A
(3)
+5VDC/10A
(3)
+5VDC/10A
(3)
+5VDC/10A
(3)
+5VDC/10A
(3)
+5VDC/10A
(3)
+5VDC/10A
(3)
9VDC/6A
+32VDC/2A
(6)
+5VDC/10A
(3)
+5VDC/10A
(3)
+5VDC/10A
(3)
+8VDC/5A
+9VDC/3A
5VDC/12A
(6)
5VDC/7A
(7)
20V/2.5A
+3.3VDC/10A
+5VDC/10A
(3)
+5VDC/10A
(3)
+12VDC/5A
+15VDC/4A
+18VDC/4A
(7)
+6V/10A
2.5VDC/22A
(4)
3.3VDC/22A
(4)
5VDC/22A
(4)
12VDC/9.2A
15VDC/7.3A
24VDC/4.6A
28VDC/3.9A
48VDC/2.3A

DECLARATION OF CONFORMITY

Low Voltage Directive 2014/35/EU of 26 February 2014
RoHS Directive 2011/65/EU of 8 June 2011
Output 2
(1)
+5VDC/6A
(3)
+3.3VDC/6A
+3.3VDC/6A
-5VDC/6A
-5VDC/6A
+24VDC/2A
+24VDC/2A
+24VDC/2A
24VDC/2A
-32VDC/2A
-9VDC/3A
+12VDC/3A
+15VDC/2A
-8VDC/1A
+24VDC/3A
9.5VDC/1A
15VDC/3.5A
12V/2.5A
+5VDC/6A
(3)
+12VDC/5A
+24VDC/3A
-12VDC/4A
-15VDC/3A
-18VDC/3A
+7.5V/6A
-----
-----
-----
-----
-----
-----
-----
-----
Web: www.ipdpower.com
Email: sales@ipdpower.com
Fax: (570) 824-4843
Output 3 Output 4
(2)
+12VDC/2A -12VDC/2A
+12VDC/2A -12VDC/2A
+15VDC/2A -15VDC/2A
+12VDC/2A -12VDC/2A
+15VDC/2A -15VDC/2A
+12VDC/2A -12VDC/2A
+15VDC/2A -15VDC/2A
+7VDC/2.5A -7VDC/2.5A
12VDC/2A 12VDC/2A
+12VDC/2A -12VDC/2A
+15VDC/2A -15VDC/2A
----- -12VDC/3A
----- -15VDC/2A
----- +30VDC/1A
+13VDC/2A
----- 9.5VDC/1A
----- -15VDC/2A
----- 12V/2.5A
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
EUROPEAN CONTACT:
CompuMess Elektronik GmbH
Lise-Meitner-Strasse 1
85716 Unterschleiβheim
Telephone: (089) 32 15 01-0
