Point of Sale Reader (PR5000)
Hardware Installation Guide
403-002-018 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Blackboard PR5000

Summary of Contents for Blackboard PR5000

  • Page 1 Point of Sale Reader (PR5000) Hardware Installation Guide 403-002-018 Rev A...
  • Page 2 Table 0-1: Revision History Bb Document Part Number Rev. Description Date 403-002-018 ECO10431. Initial Release. PENDING 403-002-018 Rev A...
  • Page 3 Modifications: Any modifications made to this device that are not approved by Blackboard Inc. may void the authority granted to the user by the FCC to operate this equipment.
  • Page 4 Industry Canada Class A emission compliance statement This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 5 Note: The regulatory compliance information above can be viewed on the reader’s display. To view this information on the reader, at the Main Menu, press the Regulatory Information button. 403-002-018 Rev A...

  • Page 6: Table Of Contents

    (PR5000) H LACKBOARD OINT OF EADER ARDWARE NSTALLATION UIDE Overview Features: PR5000 Functional Overview Inputs and Outputs: Functional Overview - Bottom Functional Overview - Top PR5000 Mount Kit PR5000 R NSTALLING THE EADER Reader Installation Overview and Wiring Considerations Wiring and Power Considerations:...

  • Page 7: Lackboard Oint Of

    U I D E VERVIEW The Blackboard Point of Sale (POS) Reader PR5000 is an Android-based reader. When configured, the PR5000 communicates with the Blackboard Transaction System (BbTS), and incorporates both contactless and magnetic stripe reader capabilities. The reader can be set up as either an attended or unattended device.

  • Page 8: Pr5000 Functional Overview

    One USB Type C connector that support USB 2.0 high speed data transfer. • 12V - 15W DC Power Input • Two 2W stereo speakers Functional Overview - Bottom Bottom of the PR5000 Reader Reset Button LEDs (4) Stereo Speakers (2) RJ-45...

  • Page 9: Functional Overview - Top

    P R 5 0 0 0 F U N C T I O N A L V E R V I E W Functional Overview - Top LCD Captive Touchscreen Proximity and Ambient Light Sensor Microphone Camera Magnetic Card Reader Microphone Figure 1-3 Functional Overview - Top 403-002-018 Rev A...

  • Page 10: Pr5000 Mount Kit

    A mount kit is provided to aid in mounting the reader to a wall. Open the packaging, and then verify that all parts are included. If there are any discrepancies, contact your Blackboard Client Manager. Table 1-1: List of parts ITEM NO.

  • Page 11: Installing The Pr5000 R

    • Both the POE switch and PR5000 must be installed within the same building or structure. • A CAT-5 cable must be connected between the POE switch and the port on the PR5000. (RJ-45) Note: For a more details, see: the Blackboard Transact System Implementation Guide.

  • Page 12: Tabletop Installation

    Figure 1-5 PR5000 Tabletop Installation The PR5000 Reader can be placed on a tabletop for events such as a fundraiser or a library book sale. This section includes the instructions for installing the PR5000 Reader on a tabletop. Please review the tabletop installation considerations before continuing.

  • Page 13: Wall Mount Installation

    OUNT NSTALLATION The PR5000 Reader ships with a mount kit. The kit is optional, but simplifies wall installation. Follow the instructions in this section to properly mount your PR5000 Reader to a wall. Please review the wall mount installation considerations before continuing. The Mount Kit is compatible with Video Electronics Standards Association (VESA) 75 mounts (not included).

  • Page 14: Installing The Mount Kit

    Attach the Mount Base or VESA 75 mount to the electrical gang box. For the PR5000 Mount Base, use the 6-32 X 3/4 Truss Head Phillips machine screws (4). For a VESA mount, use the M4 X 6mm Panhead machine screws (4).
  • Page 15 1-8. The remaining Tamper Proof screws will be installed later. Obtain the PR5000 Reader and the PR5000 Mount included (Blackboard Part No. 044-059-120). Place the reader on a tabletop with the front of the reader facing downward. Blackboard recommends using a towel or soft cloth underneath the reader to avoid scratches.

  • Page 16: Connecting Cables

    (Hardware chapter). The reader provides data output through AUX1. A serial connection from AUX1 to third-party hardware is required. Place the PR5000 Reader on the Mount Base by sliding the Mount’s open slots over the loosely attached screws previously installed.

  • Page 17: Technical Specifications

    E C H N I C A L P E C I F I C A T I O N S ECHNICAL PECIFICATIONS Table 1-2: PR5000 Technical Specifications Dimensions: 9.0" x 7.5" x 2.3" Weight: 1.55 lbs. (0.70 kg) Input Power: 12 VDC 1.1 Amp.
