User Manual
DOREL ASIA
MULTIFUNCTION CART
Watch our instructional video
for more information on how to
care for the natural wood top.
DorelLiving.com/Mainstays
MultifunctionCart
THIS INSTRUCTION BOOKLET
CONTAINS
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
_____________________________________
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE RETAILER.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
Model No:
DA7618 (WHITE)
DA7618-DC (WHITE)
DA7618B (BLACK)
DA7618G (GRAY)
UPC CODE:
0-65857-17418-2
0-65857-17425-0
0-65857-17453-3
0-65857-17454-0
NOTE:
IMPORTANT
SAFETY
Lot number:
(LOCATED ON CARTON)
Date of purchase:
NEED HELP!
CALL US FOR ASSISTA
Tel #: 1-800-295-1980
1-800-295-1980
E-Mail: das@dorel.com
DO NOT RETURN PRO
E-MAIL:DAS@DOREL.
charge.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia DA7618
Summary of Contents for Dorel Asia DA7618
- Page 1 DOREL ASIA Model No: MULTIFUNCTION CART DA7618 (WHITE) DA7618-DC (WHITE) DA7618B (BLACK) DA7618G (GRAY) UPC CODE: 0-65857-17418-2 0-65857-17425-0 0-65857-17453-3 0-65857-17454-0 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (LOCATED ON CARTON)
-
Page 2: Customer Service
CUSTOMER SERVICE You can also contact us by writing to the address listed below. Please include the product model number, color and a detailed description of your enquiry. Dorel Living - Customer Service Department 12345 Albert-Hudon Boulevard, Suite 100 Montreal, Quebec Canada, H1G 3L1 NOTES Assemble on a soft surface to prevent damage to the product finish. -
Page 3: Hardware List
MULTIFUNCTION CART HARDWARE LIST ∅1/4" x 36mm ∅4mm x 25mm ∅6mm x 25mm CAM BOLT FLAT HEAD WOOD SCREW WOOD DOWEL 6 PCS 14 PCS 6 PCS ∅6mm x 3mm x 12mm ∅5/32" x 20mm 30mm x 14mm ROUND WOOD SCREW ROUND HEAD BOLT SHELF SUPPORT 5 PCS... -
Page 4: Parts List
MULTIFUNCTION CART PARTS LIST DRAWER FRONT DRAWER BACK LEFT DRAWER SIDE 1 PC 1 PC 1 PC RIGHT DRAWER SIDE BOTTOM RAIL BOTTOM SHELF 1 PC 2 PCS 1 PC FRONT RAIL 1 PC... - Page 5 MULTIFUNCTION CART PARTS LIST BACK PANEL LEFT SIDE PANEL RIGHT SIDE PANEL 1 PC 1 PC 1 PC ADJUSTABLE SHELF TOP PANEL DRAWER BOTTOM 1 PC 1 PC 1 PC LOCKING CASTERS CASTERS 2 PCS 2 PCS...
- Page 6 MULTIFUNCTION CART STEP 1: Attach right and left drawer side (C & D) to drawer front (A) with flat head wood Slide drawer bottom panel (M) into the grooves of the drawer sides (C & D). Attach drawer back (B) to right and left drawer sides (C & D) with flat head wood Use a Phillips head screwdriver (not included) to tighten the screws and bolts.
- Page 7 MULTIFUNCTION CART STEP 2: Attach handle (11) to drawer front (A) with round head bolts (5). Use a Phillips head screwdriver (not included) to tighten the screws and bolts.
- Page 8 MULTIFUNCTION CART STEP 3: Insert cam bolts (1) to top panel (L) with a Philips head screwdriver (not included).
- Page 9 MULTIFUNCTION CART STEP 4: Insert wood dowels (3) into bottom shelf (F). Attach bottom rail (E) to bottom shelf (F) with flat head wood screw (2) using a Phillips head screwdriver (not included).
- Page 10 MULTIFUNCTION CART STEP 5: Attach drawer stopper (9) to front rail (G) with round wood screws (4) using a Phillips head screwdriver (not included).
- Page 11 MULTIFUNCTION CART STEP 6: Insert wood dowels (3) into left and right side panels (I & J) as shown. Attach side panels (I & J) to rails (E & G) and back panel (H) with bolts (7) and Allen key (12) as shown below.
- Page 12 MULTIFUNCTION CART STEP 7: Insert shelf support (6) into the desired location on left and right side panels (I & J).
- Page 13 MULTIFUNCTION CART STEP 8: On a clean surface, place the cart on its side as shown below. Place the adjustable shelf (K) on the shelf supports (6) as shown below. Secure the adjustable shelf (K) to the shelf suppports (6) using round wood screws (4) and a Phillips head screwdriver...
- Page 14 MULTIFUNCTION CART STEP 9: Insert the locking casters & casters (N & O) into the bottom of right and left side panel (I & J) as shown and tighten with wrench (10).
- Page 15 MULTIFUNCTION CART STEP 10: Insert cam lock (8) into side panels (I & J) and back panel (H) as shown. Fasten top panel (L) to the assembled unit by rotating the cam lock 1/2 turn using a Phillips head screwdriver (not included). Read the CARE, CLEANING AND MAINTENANCE section located on page 1 for guidance on how to properly care for the wood top.
- Page 16 MULTIFUNCTION CART STEP 11: Insert the drawer into the unit as shown.
- Page 17 MULTIFUNCTION CART CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Top Panel maximum weight = 30 lbs Drawer maximum weight = 10 lbs...
